OPERATOR'S MANUAL
VersaLite™ Electric String Trimmer
UT41002A
Your trimmer has been engineered and manufactured to Homelite's high standard for dependability, ease of
operation, and operator safety. When properly cared for, the trimmer will give you years of rugged, trouble-free
performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a Homelite product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Advertisement
Table of Contents
Related Manuals for Homelite VERSALITE UT41002A
Summary of Contents for Homelite VERSALITE UT41002A
- Page 1 OPERATOR'S MANUAL VersaLite™ Electric String Trimmer UT41002A Your trimmer has been engineered and manufactured to Homelite's high standard for dependability, ease of operation, and operator safety. When properly cared for, the trimmer will give you years of rugged, trouble-free performance.
-
Page 2: Table Of Contents
Customer Service Information ... 18 Your trimmer has many features that make using this product more pleasant and enjoyable. We have given safety, performance, and dependability top priority in the design of this product, making it easy to maintain and operate. -
Page 3: Safety
Maintain a firm grip on both handles while trimming. Keep the trimmer head below waist level. Never cut with the trimmer head over 30 in. (76 cm) or more above the ground. ELECTRICAL SAFETY RULES... -
Page 4: Safety
Inspect the unit’s power connection. Any part that is damaged should be properly repaired or replaced by a Homelite autho- rized service center. Keep the product clean of grass clippings and other materials that may become lodged in the cutting lines. -
Page 5: Symbols
Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool more safely and effectively. SYMBOL NAME Safety Alert Ricochet Eye Protection Bystanders Alert No Blade Class II Construction... -
Page 6: Specifications
MOTOR Motor Type ... 120 V AC Operating RPM ... 7500 Amperage ... 6 amps DRIVE SHAFT AND CUTTING HEAD Drive Shaft ... 1/4 in. Flex Shaft Cutting Head ... Bump Line Release Cutting Path Diameter ... 15 in. (381 mm) Drive Shaft Housing ... -
Page 7: Features
The trimmer includes a grass deflector that helps protect you from flying debris. ERGONOMIC DESIGN The design of the trimmer provides for easy handling. It is designed for comfort and ease of grasp when operating in different positions and at different angles. -
Page 8: Assembly
Follow these steps to remove the attachment from the upper shaft. Release the trigger and allow the trimmer to coast to a stop. Unplug the trimmer. Loosen the locking knob by turning it counterclock- wise. -
Page 9: Attaching The Grass Deflector
EXTENSION CORD RETAINER An extension cord retainer is located on the bottom of the trimmer. This provides strain relief for the cord, preventing unwanted disconnects. Note: To reduce the disconnection of the power cord from the extension cord during operation, use the extension cord retainer described below. -
Page 10: Operation
NOTE: Keep a firm grip with both hands during operation. Place the trimmer on the right side of your body with the engine behind and away from your body. Press the trigger to start the trimmer. - Page 11 If the line is not advanced occasionally, it will wear down to the eyelet. When the trimmer stops, the line tends to relax and may retract into the trimmer head assembly. Should this occur, unplug the trimmer, remove the spool, refeed the line through the eyelets, and reassemble the spool.
- Page 12 CUT OFF BLADE This trimmer is equipped with a cut-off blade on the grass deflector. For best cutting, advance string until it is trimmed to length by the cut-off blade. Advance string whenever you hear the engine running faster than normal.
-
Page 13: Maintenance
SERVICING THE TRIMMER Check all fasteners and tighten as necessary. If any part is damaged or lost, repair it or replace it. Any other service should be performed at a Homelite Authorized Service Dealer. REPLACING THE CUTTING LINE See Figures 13, 13a and 13b. -
Page 14: Replacing The Spool
Insert the lines into the eyelets in the trimmer head. Place the spool on the drive shaft. NOTE: To install the spool, you may need to rotate it slightly. -
Page 15: Troubleshooting
TROUBLESHOOTING SOLUTION 1. Lubricate with Homelite silicone spray. 2. Install more line (Refer to “Replacing the Cutting Line” earlier in this manual). 3. Pull lines while alternately pressing down on and releasing spool retainer. -
Page 16: Accessories
ACCESSORIES REPLACEMENT PARTS String Head (RH Thread) .080 in. (2 mm) ... DA03001A Spool & Line .080 in. (2 mm) ... UP00145 String Refill .080 in. (2 mm); 390 ft. (118 mm) ...D06511 String Refill .080 in. (2 mm); 50 ft. (15 mm) ... D06509A Retaining Cap (RH thread) ... -
Page 17: Warranty
HOMELITE operator's manual. This warranty does not apply to any damage to the HOMELITE product that is the result of improper maintenance or to any... -
Page 18: Customer Service Information
UT41002A CUSTOMER SERVICE INFORMATION For parts or service, contact your nearest Homelite authorized service dealer. Be sure to provide all relevant information when you call or visit. For the location of the authorized service dealer nearest you, please call 1-800-chainsaw (1-800-242-4672) or visit us online at www.homelite.com.
