Meter Description
1. Laser pointer beam
2. IR Sensor
3. Measurement Trigger
4. Battery and Switch Compartment
5. LCD Display
6. Push-buttons
7. Handle Grip
8. Temperature Units (ºC/ºF) Switch
9. Test Lock ON/OFF Switch
10. Alarm ON/OFF Switch
Note: There is a tripod mount on the bottom of the handle
4
1
2
3
8
9
10
3
Model 42540A V2.1 January 2006
5
6
6
7
