Insignia H88-842 Assembly & Fitting Instructions
Insignia H88-842 Assembly & Fitting Instructions

Insignia H88-842 Assembly & Fitting Instructions

Steam shower

Advertisement

Model: H88-842/3/5
Important-Please check your model against the
amendments at the back of this booklet before attempting
Installation (PLEASE NOTE photos may vary from your
model number as these instructions cover all H88 models)
Assembly & Fitting Instructions
For the latest fitting instructions please visit www.insigniarange.co.uk
Contents
Introduction
Staring the Installation
Sealing the shower
Troubleshooting, Help & FAQ's
Amendments - Important !!
For the latest fitting instructions please visit www.insigniarange.co.uk
3
6
7
11
25
28
30
31
32
35
36
37

Advertisement

loading
Need help?

Need help?

Do you have a question about the H88-842 and is the answer not in the manual?

Questions and answers

Summary of Contents for Insignia H88-842

  • Page 1: Table Of Contents

    Contents Introduction Tools Required What’s in the boxes Model: H88-842/3/5 Staring the Installation Important—Please check your model against the Sealing the shower amendments at the back of this booklet before attempting Installation (PLEASE NOTE photos may vary from your Water Connections...
  • Page 2 ASSEMBLY AND SIMPLE PLUMBING Thank you for your recent purchase of an Insignia steam shower. Please read this booklet with great care to ensure you get the THIS PRODUCT BUILD IS RATED SUITABLE FOR DIY PURPOSES PROVIDING THE best out of your build and have a shower that will last for many...
  • Page 3: Tools Required

    REMEMBER: Tools required These showers are designed to be free standing and movable from their location should you have need to replace anything. AL- WAYS USE Flexible braided water inlet pipes at least a metre long 2 People (not central heating plastic type! ) from Scissors house supply to the shower and again flexible waste pipe to join Silicone Gun...
  • Page 4: What's In The Boxes

    What’s In The Boxes? Please check with pictures, some of the items have been assem- bled by ourselves in order for ease of recognition as to what they are and can be used as reference in later construction Box 1—Shower tray box 1 x Tray 2 x Curved rails for the top &...
  • Page 5 Box 3 Box 4 Centre column. Please note yours may not be built as picture 4 x glass panels. with overhead shower attached and hand shower. These are 2 x straight columns in aluminium. placed on the item in picture to show where they fit. 2 x straight anti splash door trims Glass rack and fittings (if supplied) 2 x fixed glass panel flexi seals...
  • Page 6 VERY IMPORTANT Tray Feet Have you got everything? If not please contact your supplying deal- er now. Remember NEVER book your tradesman until everything has arrived, been checked and is present. No replacement / miss- ing parts can obtained free of charge during or after build only within the timescale permitted (48 hours after delivery) and always BEFORE build.
  • Page 7 When you are happy you have correct angles and the feet are ad- just correctly to the position required. Place tray into a more work- able position away from the walls and giving clear working dis- tance. For OFFSET SHOWER Take either one of the tinted glass panels (Shiny side inside cabin) and the column with controls fitted offer onto tray and align panel to column.
  • Page 8 Did you notice the water anti leak seals? These are fold- ed to tuck in-between the column and glass panel neatly. Do not fold half of it outside!! If you think about this, any other way will cause extensive leaks. You will channel the water out of the show- er of course! Why not carefully silicone along the joint as you make it! It will add rigidity and improve even better sealing quali- ties...
  • Page 9 Happy with this? Good! Now repeat with other column and other end and again with curve marked “Top” You now have a fully built front supporting frame. Silicone under bottom waterproof seals and offer the newly built frame to the end of glass panels. Taking one column and the curved runner marked “bottom”...
  • Page 10 Assemble glass rack (if supplied) Assemble the hand shower and the overhead shower You will now have a build as below Now screw or bolt according to whatever fixture is supplied, the complete shower to the tray where holes supplied. For the latest fitting instructions please visit www.insigniarange.co.uk For the latest fitting instructions please visit www.insigniarange.co.uk...
  • Page 11 With all now complete as the above picture you need to fit the glass front fixed panels. Taking one of these, easy to identify because they are flat with no holes in. Fit the sealing trim to one long side of the glass. Note. The sealing trim may be in one length so carefully measure and cut ac- cordingly.
  • Page 12 NOTE BUTTONS ON PICTURE ABOVE With both front fixed glasses firmly in place now it is time to take both doors. Check you have them round the correct way. Hold both together and make sure magnets attract not repel. Fix the wheels and door handles accordingly.
  • Page 13: Water Connections

    NOW AT THE REAR OF THE SHOWER Finally seal round the bottom of each tray Shower Water Connections with a bead of silicone You have three (depending on model) features fitted within the shower, all are connected via the rubber reinforced pipes supplied at the rear of the shower.
  • Page 14 Pressure Requirements from your house supply. VERY IMPORTANT We recommend a bar pressure between 2 and 3 bar. If you have a Do not twist flexi braided hoses. This will shorten the lifespan and combi boiler system no problem should be experienced. If you greatly affect flow.
  • Page 15: Testing For Leaks

    Your completed shower should now look like this: TESTING FOR WATER LEAKS LEAVING SHOWER 24 HOURS AFTER BUILD ALLOWING SEALENT TO CURE HAVE YOU BUILT THIS CORRECTLY? FIND OUT NOW. With all connections tight, the waste and hoses checked, jets fully sealed, your shower still around18 inches from its designated final resting point and the silicone sealer fully cured (hence leaving for 24 hours at min) Switch on the overhead shower NOT massage jets...
  • Page 16: Safety

    28 days from the day this product was delivered to you. For Always be aware of the steam outlet pod position. Never use in cost and enabling kindly contact Insignia on 0844 800 3069. close proximity to the person using it.
  • Page 17 And for the smaller items Please note you are not covered for consequential or incidental just contact Insignia on 0844 800 3069 for on the spot advice and damage however caused relating to any product part failure. This help.
  • Page 18: Spare Part

    24 hour service in place. So you need something and out of warranty just identify it from the instructions to build, call Insignia on 0844 800 3069, tell them, pay by card over the telephone and en- deavour to despatch same day.
  • Page 19 Amendments It may be apparent that you have the latest model which is a “click clack” style build. It is important to recognise this as when it comes to building the shower, once you have the tray in place you need to build the front glass frame first than click the rear panels in to...

This manual is also suitable for:

H88-845H88-843
