www.insigniashowers.com
Last Modified: 05/02/2021
INSTALLATION MANUAL
1100R|1200R
ES Series
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installation.
Replacements Parts:
Inside of your warranty period visit:
https://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts:
Outside of your warranty period visit
https://www.insigniashowers.com/replacement-parts.html
ATTENTION INSTALLERS:
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
These instructions must be
WARRANTY REG NO: _______________________
left with the customer

Advertisement

Table of Contents
loading

Related Manuals for Insignia ES Series

Summary of Contents for Insignia ES Series

  • Page 1 Last Modified: 05/02/2021 INSTALLATION MANUAL 1100R|1200R ES Series 30 Day Technical Support: Call 01908 317512 and request technical support for aiding your installation. Replacements Parts: Inside of your warranty period visit: https://www.insigniashowers.com, click support and make a warranty claim.

  • Page 2: Table Of Contents

    www.insigniashowers.com Last Modified: 05/02/2021 Contents Water Valve Connections Installation Assistance (Video Links) Control Panel Connections Thank you for your purchase Tips for assembly Steam Generator Connections Braided Hose QR Code/Link Signing off your shower Control Panel Operating Instructions Electrical/Pressure/Tool requirements Spare Parts List Box contents Steam Room &...

  • Page 3: Installation Assistance (Video Links)

    Steam Shower Shower Cabin Please note: this build video is for an Insignia Platinum Shower, however 90% of the process is the same for assembly so it should help you on your way! Also note the shower video contains a left hand shower but the assembly...
  • Page 4 Last Modified: 05/02/2021 Thank you for your recent purchase of an Insignia shower. Please read this booklet with great care to ensure you get the best out of your build and have a shower that will last for many years to come! Like everything, in order to obtain a first class product that will serve you well for many years, the effort and correctness put into the assembly will reflect in the quality of your finish.
  • Page 5 TIP 4—Sealing When using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the RubberGum to fail and will not adhere as intended. Rubbergum is immediately waterproof and will gain additional strength over time.
  • Page 6 www.insigniashowers.com Last Modified: 05/02/2021...
  • Page 7 www.insigniashowers.com Last Modified: 05/02/2021 Electrical Requirements Pressure/Water Requirements Tools Required STEAM VERSION We recommend a BAR pressure between 2.5 and 3.4 BAR. If You will require: you have a combi boiler system no problem should be Voltage Rating 220-240AC • •...

  • Page 8: Box Contents

    ST16 16mm Screws VERY IMPORTANT ST20 or WN20 20mm Nut and Bolt or Wing Nut Have you got everything? If not please contact the Insignia directly on 01908 317 512. PRC20 Glass Retaining Clips Remember NEVER book your tradesman until everything has arrived, been checked and is present.
  • Page 9 www.insigniashowers.com Last Modified: 05/02/2021 Step 1 — Level the Tray and connecting the waste Twist to adjust NOTE: FOR STEAM SHOWERS ONLY: Check the Spigot is drilled out prior to fitting. If it isn’t ensure you drill it out!
  • Page 10 www.insigniashowers.com Last Modified: 05/02/2021 Step 2 — Connecting framework Framework securing clips x4 Wider rail on top Internal View Narrow rail at the bottom...
  • Page 11 www.insigniashowers.com Last Modified: 05/02/2021 Step 3 — RubberGum the tray Apply RubberGum to raised sections of the tray and remove backing paper. Step 4 — Fix framework to the tray PRESS FRAME DOWN FIRMLY ONTO THE RUBBERGUM. Please Note 2 Generation showers lower profile curve is not designed to fully follow the tray curve.
  • Page 12 www.insigniashowers.com Last Modified: 05/02/2021 Step 5 — Connecting the back panels ST16 x12 PRESS PANELS DOWN FIRMLY ON TO THE RUBBERGUM. DO NOT SCREW BACK PANELS TO THE TRAY.
  • Page 13 www.insigniashowers.com Last Modified: 05/02/2021 Step 6 — Column Connection ST20 x 12 SW9 x 12 WN20 x 12 Rear View (attach nuts and bolts or wing nuts from rear) Below diagram shows the nut/bolt install ———————— ———————— NOTE: Column features varies between models...
  • Page 14 www.insigniashowers.com Last Modified: 05/02/2021 Step 7 — Fixed Glass Connection ST16 x 4 PRC20 x 4...
  • Page 15 www.insigniashowers.com Last Modified: 05/02/2021 Step 8 — Fitting the glass seals Fit seal inside the shower between the glass and framework 1x 12mm Seal 12mm 1x 7mm Seal Step 9 — Fitting the door stops Internal View — Top Rail ST10 x8 SP072 x8 Internal View —...
  • Page 16 www.insigniashowers.com Last Modified: 05/02/2021 Step 10 — Attaching the Roof Screw from the rear ST16 x6 Step 11 — Fit door handles, seals and magnets...
  • Page 17 www.insigniashowers.com Last Modified: 05/02/2021 Step 12 — Fit top door wheels x 4 Tighten to secure wheels into door runners. DO NOT OVERTIGHTEN Slide cover off Door Step 13 — Fit bottom door wheels x 4 Slide cover off Door Step 14 —...
  • Page 18 www.insigniashowers.com Last Modified: 05/02/2021 Step 15 — Accessory Installation Slide cover off Slide cover off...
  • Page 19 www.insigniashowers.com Last Modified: 05/02/2021 Step 16 — Valve/Water Connections Monsoon Head Hand Shower Jets 2 x Washers located on Cold Water Inlet Hot Water Inlet the back of the valve Connection for steam generator (steam version only)
  • Page 20 www.insigniashowers.com Last Modified: 05/02/2021 Step 17 — Button Control Panel Connections Essential Steam Essential Shower Version Cabin Version Roof Light Speaker Antenna Power Supply Speaker...
  • Page 21 www.insigniashowers.com Last Modified: 05/02/2021 Step 17 — Touch Sensitive Control Panel Connections Steam Shower Shower Cabin Version Version Roof Light Power Supply Speaker Antenna Speaker Power Supply...

  • Page 22: Steam Generator Connections

    Install a static water line from the shower valve (middle feed) to the steam generator. • Purchase Insignia’s WRAS approved braided hoses, however, you may require a male to male connector to connect them together to make them long enough depending on your shower model (screwfix code: 71087) •...

  • Page 23: Signing Off Your Shower

    3. Do not aim the hand shower directly at the joints of your shower as this does not fall under “normal showering conditions”. However, due to Insignia’s unique design of the shower tray, water will only leak back in to the tray so you won’t get flooded.
  • Page 24 www.insigniashowers.com Last Modified: 05/02/2021 Button Control Panel Instructions (steam version only) Button 1 (MEM) Button 8 (LIGHT 2) Press to store a tuned in radio station. Inactive Button 2 (FM/CD) Button 9 (ALARM) Press to activate FM Radio. Press again to activate the Press to mute the audio when listening to the Radio Bluetooth.
  • Page 25 www.insigniashowers.com Last Modified: 05/02/2021 Button Control Panel Instructions (non-steam version only) Buttons 1 & 2 Button 7 Use to scroll for radio stations or skip music tracks Inactive Buttons 3 & 4 Button 8 Use to increase or decrease the volume Press once to activate the lights.
  • Page 26 Press once to turn on the panel. Simply press again to turn it off. When powering down the 03 will automatically start and last for approximately 10 minutes. After this the screen will power off. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel”...
  • Page 27 www.insigniashowers.com Last Modified: 05/02/2021 Touch Sensitive Control Panel Instructions Connecting to Bluetooth Step 2 Step 1 Then simply go on your device and pair To connect a device via up with the shower which should be Bluetooth, press the music shown as “INS”.

  • Page 28: Control Panel Operating Instructions

    When the Bluetooth is activated this will skip to the next song in your playlist. To see our tutorial videos for operating Insignia control panel’s, please search for “Insignia Showers” on YouTube and find our “Insignia Control Panel” Playlist, or you can...
  • Page 29 (non-steam version only) SP156 ES Ozone compatible with the SP217 (steam version only) SP187 Drain Hose (steam version SP154B Touch Sensitive Insignia only) Control Panel (non-steam SP078 INS Ozone compatible with the version only) SP217B (steam version only) SP221...

  • Page 30: Steam Room & Shower Safety Guide

    www.insigniashowers.com Last Modified: 05/02/2021 Steam Room & Shower Safety Guide Never leave children unattended in the shower or bath. Never bath children (under 12) using whirlpool function if fitted. Regulate the temperature of water before showering. Never allow children to use the steam function. This function is for ADULTS ONLY. Always be aware of the steam outlet position.

  • Page 31: Steam Room Usage Guide

    www.insigniashowers.com Last Modified: 05/02/2021 Steam Room Usage Guide To use the steam room, turn the control panel on. (1) Press the steam button (2) and your generator will be fed with water and the heating element will begin to heat the water to create steam. (You should be seeing steam from your outlet in approximately 60-90 seconds) To set the temperature you want the cabin to reach, press the function button (3) once the steam is active.

  • Page 32: Bathroom Electrical Zones

    www.insigniashowers.com Last Modified: 05/02/2021 Bathroom Electrical Zones...
  • Page 33 www.insigniashowers.com Last Modified: 05/02/2021 There are 3 bathroom electrical zones that have been distinguished in the IEE wiring guidelines and these are: Zone 0 is the area inside a bath, basin or shower. It's characterised as 'any area within a bathroom that can hold water'. Any fitting or electrical appliance utilised inside zone 0 must be a maximum of 12 volts (SELV) and completely secured against both partial and total submersion in water (minimum of IPX7) Zone 1 is the region straight above zone 0 to the height of 2.25m from the base of the bath or shower.

  • Page 34: Weee Compliance Statement

    (EEE) have to fulfil certain obligations. Under the WEEE directive Insignia is considered the producer of certain products we supply and in line with the demands of the legislation we are pleased to offer the op- portunity to return these products to us for treatment and recycling.
  • Page 35 www.insigniashowers.com Last Modified: 05/02/2021...
