Page 1: Table Of Contents
Contents Introduction Electrical Requirements Tools Required Model: 8004a / 8002a What’s in the boxes Staring the Installation Connecting The Shower Accessories 23 Assembly & Fitting Instructions Electric Connections Water Connections Product Testing Testing for Leaks Safety Warranty Information Spare Part Frequently asked Questions For the latest fitting instructions please visit www.insigniarange.co.uk... - Page 2 ASSEMBLY AND SIMPLE PLUMBING Thank you for your recent purchase of an Insignia steam shower. Please read this booklet with great care to ensure you get the THIS PRODUCT BUILD IS RATED SUITABLE FOR DIY PURPOSES PROVIDING THE best out of your build and have a shower that will last for many...
-
Page 3: Electrical Requirements
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF!!! REMEMBER: These showers are designed to be free standing and movable Note for electrician. This product comes with 13 amp plug(s) fitted from their location should you have need to replace anything. AL- with RCD unit. We leave the way you prefer to connect this to your- WAYS USE Flexible braided water inlet pipes at least a metre long self due to continued additions to current regulations. -
Page 4: What's In The Boxes
What’s In The Boxes? Please check with pictures, some of the items have been assem- bled by ourselves in order for ease of recognition as to what they are and can be used as reference in later construction Shower tray with electric box + steam Generator attached to the underside Roof section Shower waste (part of fitting kit if purchased) - Page 5 Glass pack Rear glasses x2 and 2 x top and bottom curve supports 2 x curved doors 1 x door handle pack Lengths of glass seal trim 2 x magnet trim 2 x front upright columns 2 x corner columns 2 x door seals Centre control column, grab handle and back...
- Page 6 VERY IMPORTANT Tray Feet Have you got everything? If not please contact your supplying dealer now. Remember NEVER book your tradesman until every- thing has arrived, been checked and is present. No replacement / missing parts can obtained free of charge during or after build only within the timescale permitted (48 hours after delivery) and always BEFORE build.
- Page 7 When you are happy the tray is set up correctly you can now move this out to a better working position. Careful not to trap skirt light fitting if fitted Taking now the left hand (as you look from the front) rear wall shiny side inwards, it will have the holes for the foot massage and rack please check against original picture at the start of instruc- tions.
- Page 8 Moving on to the top and bottom curved rails and the two upright Column showing “UP” aluminium columns. Columns fit on each end of the exposed rear panel glasses and will form the front part of the shower support. Take one column and the bottom curved rail, at the bottom of each upright you will see two slots, screw the upright to the curve with screws supplied through slots.
- Page 9 When this stage is complete repeat the same assembly with the second glass and again firmly press into the other channel. Now take the 2 x front columns with grey plastic clips attached and lights. Press one into the opposite end of the glass panel you have just fixed and over the seal.
- Page 10 You now need to fix the two front columns into place. Align the pre drilled holes and screw into place as the picture below shows: Offering up the top rail to slot into clips Screwing top curved rail Picture shows top fixing repeat both sides and at the bottom as into place well Now your assembly is almost complete.
- Page 11 Top door wheels in place note cam adjustment 2 x bottom wheels in runner Now taking the complete roof section make sure the overhead rain shower is tight and offer over the structure to fit inside frame sup- port. When in place screw through pre drilled holes. Place over shower frame Magnets fitted to doors to attract each other For the latest fitting instructions please visit www.insigniarange.co.uk...
- Page 12 Align in place for snug fit Screw into place You now need to fit all internal items supplied inside the shower cabin. Typically these are as follows: Hand shower riser bar, flexi hose and actual hand shower Press rear seat back rest on knobs supplied Foot spa and hose Assemble chrome rack All of which are self explanatory but picture on the overleaf can...
- Page 13 Congratulations nearly finished, you are now ready to couple water hoses! Taking the back rest, unscrew the 4 x small jets in centre column. This is undertaken by twisting off the chrome fascia on the front of each. These have a cross head finish. Push the back rest onto the column firmly over the jets and screw fascias back tightly using the slot in each to finally but gently secure.
-
Page 14: Electric Connections
Electric Connections. Seal where shown in red on assembly! - Not after At this stage you will need to connect the following. These are all 12V and considered “safe” for DIY connection as each is labelled and low voltage. NEVER CONNECT TO MAINS AT THIS STAGE Overhead light * Led rear panel lights* Ozone (if fitted) * Speaker * fan * Aerial (unfold if fitted) * C.D Telephone (if required most do not bother!) external jacks if required NOTE! If you purchased the... -
Page 15: Water Connections
Shower Water Connections Going to the rear of the shower, you now have hoses coming from the water diverter valve, these are marked as to their location. Connect each to their respective positions. NOTE Check each con- nection has a seal in before tightening fully. Please note overhead shower shows arrow to left, in fact this goes vertical. - Page 16 Connecting the steam generator What Should I Know About Steam Room Safety? Please visit the following link: http://www.insigniarange.co.uk/instructions/ Fitted at the bottom of the shower rear you will find the steam Steam_Safety_Please_Read.pdf generator which will look similar to the picture below. Connect white insulated hose to the shower steam pod.
- Page 17 Pressure Requirements from your house supply. with a washing machine or dishwasher, it is highly recommended accessible water valve taps are installed to turn off the shower We recommend a bar pressure between 2 and 3 bar. If you have a when not In use.
- Page 18 1. On/Off Switch TESTING PRODUCT. 2. Radio frequency 3. Volume setting With the shower still not fully positioned as you will require it. 4. Steam Unit operation—Press this button to active the steam Complete the following tests: function. If no water is present the unit will not function for safety reasons.
-
Page 19: Testing For Leaks
Your completed shower should now look like this: TESTING FOR WATER LEAKS LEAVING SHOWER 24 HOURS AFTER BUILD ALLOWING SEALENT TO CURE HAVE YOU BUILT THIS CORRECTLY? FIND OUT NOW. With all connections tight, the waste and hoses checked, jets fully sealed, your shower still around18 inches from its designated final resting point and the silicone sealer fully cured (hence leaving for 24 hours at min) Switch on the overhead shower NOT massage jets... -
Page 20: Safety
28 days from the day this product was delivered to you. For Always be aware of the steam outlet pod position. Never use in cost and enabling kindly contact Insignia on 0844 800 3069. close proximity to the person using it. - Page 21 And for the smaller items Please note you are not covered for consequential or incidental just contact Insignia on 0844 800 3069 for on the spot advice and damage however caused relating to any product part failure. This help.
-
Page 22: Spare Part
Returned Goods FAQs What water pressure is required to operate you showers correctly and what Your attention is drawn to the terms and conditions. Any returned about your baths and basin taps? Item must be accompanied by a return form. Using our customer 2.5 bar is what we consider optimum pressure for all. - Page 23 After build check 100% for leaks and cure at the time. When high failure rate, we could go on. With Insignia we guarantee only the latest cured he should never have needed to come back. Sorry for bad news! technology is used, even if a customer has ordered from our advertising some- thing we have deleted, we upgrade free of charge before delivery.
- Page 24 I am a big guy, will the shower trays or baths you sell support my weight. cleaning, use a mild non abrasive cleaner and avoid No problem unless you are massive in which case you would probably not fit in detergents, disinfectants or cleaning products that come in an aerosol can.
- Page 25 delivery. If out of warranty you will be contacted and advised of cost first. Pay- Only a matter of minutes, no need to take taps off the bath or shower and cost ment can be made instantly over the telephone to avoid delay. is minimal.
- Page 26 Whatever is missing has been sucked into the system, if small it would get fired out of the jets but if a large section it will jam the pump. This is what has hap- pened to you. You now need a tradesman to remove the cover of the pump and the remove the offending item from the impeller.
