MULTI-TASKER™
MANUAL PART NUMBER: 400-0374-001
MT103-123
CAT-5 TO VGA + AUDIO RECEIVER
FOR MULTI-TASKER™
USER'S GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTI-TASKER MT103-123 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altinex MULTI-TASKER MT103-123

  • Page 1 MULTI-TASKER™ MANUAL PART NUMBER: 400-0374-001 MT103-123 CAT-5 TO VGA + AUDIO RECEIVER FOR MULTI-TASKER™ USER’S GUIDE...
  • Page 2: Table Of Contents

    VIDEO EQUALIZATION........16 TROUBLESHOOTING GUIDE......16 LED IS NOT RED..........16 LED IS NOT GREEN......... 17 NO SOUND ............17 NO REMOTE IMAGE........17 RECEIVING DISPLAY QUALITY IS POOR ..17 ALTINEX POLICY..........18 LIMITED WARRANTY/RETURN POLICY..18 CONTACT INFORMATION ......18...
  • Page 3: Precautions / Safety Warnings

    Any changes or modifications to the unit not To prevent fire or shock, do not expose this unit expressly approved by ALTINEX, Inc. could void to rain or moisture. Do not place the MT103-123 the user’s authority to operate the equipment.
  • Page 4: About Your Mt103-123

    S-Video 4 Pin Mini DIN (RJ-45) type cable when used together with an Composite Video Female RCA ALTINEX Twisted pair Video Transmitter, such as Stereo Audio 5 Pin Terminal Block and MT103-122 or DA1930CT. 3.5mm Stereo Jack The MT103-123 is easy to use and requires only one...
  • Page 5: Product Description

    MULTI-TASKER™ PRODUCT DESCRIPTION...
  • Page 6: Application Diagram

    MULTI-TASKER™ APPLICATION DIAGRAM DIAGRAM 1: TYPICAL CONFIGURATION...
  • Page 7: Diagram 2: Rj-45 Pinout

    MULTI-TASKER™ DIAGRAM 2: RJ-45 PINOUT Pin Number RJ-45 Output Signals Orange/White Orange Green/White Blue Blue/White Green Brown/White Brown Table 1 Standard 568B Wiring Color Code...
  • Page 8: Diagram 3: Internal View

    MULTI-TASKER™ DIAGRAM 3: INTERNAL VIEW MT103-123 CAT-5 Video+Audio Receiver...
  • Page 9: Diagram 4: Dip Switch Settings

    MULTI-TASKER™ DIAGRAM 4: DIP SWITCH SETTINGS Position Description GAIN and SYNC OPTIONS The MT103-123 has an internal Video Gain ON=1 x1, OFF=x2 Dip-Switch with 6 positions to Factory Default = x1. achieve the following features: Sync on Green (ON/OFF) Factory Default = OFF 3, 4 VSync Polarity (Positive/Negative) 3 OFF, 4 ON...
  • Page 10: Installing Your Mt103-123

    MULTI-TASKER™ INSTALLING YOUR MT103-123 OPERATION Step 1. Determine the settings required for Gain, The MT103-123 requires only one adjustment to be Sync On Green, Horizontal Sync Polarity made for optimal performance. Video Equalization and Vertical Sync Polarity. If necessary to is required for long cable lengths and may be change the factory defaults, open the unit adjusted to fine tune the video display.
  • Page 11 MULTI-TASKER™ The Card ID is an assigned value. It is equal to 2. [C] the enclosure slot number in which the card is This command receives the status of the card. installed. The value can range from 1 to 4 up to 1 Command Format: [CnUi] to 20 depending on the enclosure.
  • Page 12 MULTI-TASKER™ Example: Feedback Prefix Definitions: +MT = Card Number Send the command [?C10] to receive the +VR = Firmware Version feedback for the MT103-123 in slot #10. Each +ON = On/Off Control status field begins with a ' +' and ends with the +EQ = Equalization card slot number (ex: C10).
  • Page 13 MULTI-TASKER™ SET EQUALIZATION Upon completion, the system will display the results. If there are no problems, the system will Command Format: [EQ=mCnUi] display the following: = Equalization (m=# from 0 to 50) MEMORY IS GOOD Cn = Card ID (n = slot # from 1 to max slots) Otherwise, failures will be listed.
  • Page 14 MULTI-TASKER™ Command Format: [WRCn…GkUi] Example: Cn = Card ID (n = slot # from 1 to max slots) The cards in slots 1, 2 and 19 are part of group 5 Gk = Group number (k = # from 1-8) in Unit ID 1.
  • Page 15: Summary Of Commands

    MULTI-TASKER™ NOTE: In MTSetup™, send the command [VER] 7.3 SUMMARY OF COMMANDS from the Terminal Window. The system will respond Card Commands with feedback similar to the following: [VER] Receives software version [690-0122-015 690-0123-004 690-0124-018] Receives status of the card Check the last three digits against the numbers above to determine if the MENU MODE option is [CnS]...
  • Page 16 MULTI-TASKER™ The system will interrogate the enclosure and 7.4.4 MT103-123 MENUS return a list of cards installed and their slot Following are the menus available to the locations. MT103-123. The first menu is the Main Menu Example: 8 (Slot 8): MT103-123 only.
  • Page 17: Adjustments

    The MT103-123 requires only one adjustment to be The card cage may require service. made for optimal performance. The adjustment is for Call ALTINEX at (714) 990-2300. If Video Equalization for long cable lengths. the other slots do not work and the 7.5.1 VIDEO EQUALIZATION...
  • Page 18: Led Is Not Green

    Cause 3. Cause 3: receiving device problem. Solution: Make sure the receiving device has power and is turned ON. If there is still no sound, please call Altinex at (714) 990-2300. 8.4 NO REMOTE IMAGE...
  • Page 19: Altinex Policy

    MULTI-TASKER™ ALTINEX POLICY 9.1 LIMITED WARRANTY/RETURN POLICY Please Altinex website www.altinex.com for details on warranty and return policy. 9.2 CONTACT INFORMATION ALTINEX, INC 592 Apollo street Brea, CA 92821 USA TEL: 714 990-2300 TOLL FREE: 1-800-ALTINEX WEB: www.altinex.com E-MAIL: solutions@altinex.com...
