DA1931CT/ / / / TP to Video + Audio Receiver
DA1931CT
DA1931CT
DA1931CT
Welcome!
We greatly appreciate your purchase of the DA1931CT Twisted Pair to Video
+ Audio Receiver. We are sure you will find it reliable and simple to use.
Superior performance for the right price, backed by solid technical and
customer support is what ALTINEX has to offer.
We are committed to providing our customers with
Signal Management Solutions
®
to the most demanding audiovisual
installations at very competitive pricing and we welcome you to join the
ranks of our many satisfied customers throughout the world.
1. Precautions and Safety Warnings
Please read this manual carefully before using your DA1931CT. Keep this
manual handy for future reference. These safety instructions are to ensure
the long life of your DA1931CT and to prevent fire and shock hazards. Please
read them carefully and heed all warnings.
1.1 General
Qualified ALTINEX service personnel or their authorized
representatives must perform all service.
1.2 Installation Precautions
To prevent fire or shock, do not expose this unit to water or moisture.
Do not place the DA1931CT in direct sunlight, near heaters or heat
radiating appliances, or near any liquid. Exposure to direct sunlight,
smoke, or steam can harm internal components.
Handle the DA1931CT carefully. Dropping or jarring can damage the
unit.
Do not pull any cables that are attached to the DA1931CT.
2. Installation Procedures
Step 1.
Determine the settings required for Gain, Sync-On-Green, Horizontal and Vertical Sync Polarity. If necessary to change the factory defaults, open the
unit and set the switches per DIAGRAM 4.
Step 2.
Plug the 9V power adapter into an AC outlet and then connect the other end to the Power input jack on the DA1931CT.
Step 3.
Verify the LED near the top of the unit is illuminated red indicating power is applied.
Step 4.
Connect the CAT-5/6 cable from the video output of the transmitter to the Input on the DA1931CT.
Step 5.
Verify the power LED at the top of the unit changes to green, indicating a sync signal has been detected.
Step 6.
Connect the stereo audio output from the DA1931CT to the receiving audio device.
Step 7.
Connect the receiving monitor to the applicable DA1931CT video output connector, RGBHV/YPbPr, S-Video, or C-Video depending on the input
type to the transmitter.
Step 8.
Verify the picture quality on the receiving monitor is equivalent to the quality as displayed on the local monitor at the transmitter. If the quality of
the image is poor or non existent, it may be necessary to adjust the video equalization on the DA1931CT and/or DA1930CT. See the Operation section
that follows for details.
Note: Some monitors may not display an image at all if the equalization is not within its specific range. Use 2 people when setting up the transmitter
Note:
Note:
Note:
and receiver, one person at each end of the transmission to view the display while adjustments are made.
3. Limited Warranty/Return policies
Please see the ALTINEX website at www.altinex.com for details on warranty and return policies.
400-0199-008
TP to Video + Audio Receiver
TP to Video + Audio Receiver
TP to Video + Audio Receiver
1.3 Cleaning
Clean only with a dry cloth. Never use strong detergents or solvents
such as alcohol or thinner. Do not use a wet cloth or water to clean the
unit. Do not open the unit to clean.
1.4 FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions found herein, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Any changes or modifications to the unit not expressly approved by
ALTINEX, Inc. could void the user's authority to operate the
equipment.
1
User's Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the DA1931CT and is the answer not in the manual?

Questions and answers

Summary of Contents for Altinex DA1931CT

  • Page 1 Verify the picture quality on the receiving monitor is equivalent to the quality as displayed on the local monitor at the transmitter. If the quality of the image is poor or non existent, it may be necessary to adjust the video equalization on the DA1931CT and/or DA1930CT. See the Operation section that follows for details.
  • Page 2 90% non-condensing Twisted Pair VGA through UXGA MTBF (calculations) 40,000 hrs Video Signal Resolutions 480p through 1080i VGA: 640x480@60Hz Table 2. DA1931CT Mechanical 900 ft (274 m) Recommended Max. Cable XGA: 1024x768@60Hz Lengths 700 ft (213 m) Electrical DA1931CT Note: Measurements made using...
  • Page 3 Twisted Pair Video Transmitter, such as the DA1930CT. The DA1931CT is compact and easy to use. The DA1931CT is able to receive one of the video sources such as RGBHV, component video, S-Video, or composite video, along with stereo audio† transmitted over the Twisted Pair cable from the DA1930CT or equivalent transmitter.
  • Page 4 DA1931CT DA1931CT DA1931CT DA1931CT User’s Guide 6. Application Diagrams Diagram 1: Typical Setup 400-0199-008...
  • Page 5 DA1931CT DA1931CT DA1931CT DA1931CT User’s Guide Diagram 2: RJ-45 Pinout Pin Number Pin Number RJ RJ RJ RJ- - - - 45 Output Signals 45 Output Signals Pin Number Pin Number 45 Output Signals 45 Output Signals Orange/White Orange Green/White...
  • Page 6 DA1931CT DA1931CT DA1931CT DA1931CT User’s Guide Diagram 3: Internal View TWISTED PAIR TO VIDEO + AUDIO RECEIVER POWER POWER 2.5mm SUPPLY 9V, 1A OUTPUT RCA JACK C-VIDEO SIGNAL POWER OUTPUT CHROMA DETECT 4-PIN MINI DIN LUMA S-VIDEO PAIR 1 INPUT...
  • Page 7 DA1931CT DA1931CT DA1931CT DA1931CT User’s Guide Diagram 4: DIP-Switch Settings The DA1931CT has an internal Dip-Switch with 6 positions to achieve the following features: Position Description Video Gain (G=1/G=2) Factory Default = OFF (G=2). Sync on Green (ON/OFF) Factory Default = OFF...
  • Page 8: Troubleshooting Guide

    DA1931CT DA1931CT User’s Guide 7. Operation 8.3 No sound The DA1931CT requires only one adjustment to be made for optimal Cause 1: The source has a problem. performance. Video Equalization is required for long cable lengths and Solution: Check the source and make sure that there is a signal present may be adjusted to fine tune the video display.
