- Page 1 SPECIAL APPLICATION MANUAL PART NUMBER: 400-0210-001 PE1004CF CAT-5 RECEIVER CARD FOR PIONEER PLASMA EXPANSION USER’S GUIDE...
-
Page 2: Table Of Contents
DIAGRAM 4: SWITCH SETTINGS ...7 INSTALLING YOUR PE1004CF... 8 OPERATION... 8 RS-232 CONTROL...8 DESCRIPTION OF COMMANDS ...8 SUMMARY OF COMMANDS ...11 TROUBLESHOOTING GUIDE ... 11 NO DISPLAY...11 NO SOUND...11 ALTINEX POLICY ... 12 LIMITED WARRANTY/RETURN POLICY ...12 CONTACT INFORMATION ...12 400-0210-001 SPECIAL APPLICATION Page... -
Page 3: Precautions / Safety Warnings
Any changes or modifications to the unit not expressly approved by ALTINEX, Inc. could void the user’s authority to operate the equipment. cause undesired... -
Page 4: About Your Pe1004Cf
The PE1004CF CAT-5 Receiver Card is designed to receive RGBHV/YPbPr video and audio signals over twisted pair (CAT-5) type cable. The encoded CAT-5 signals are Altinex Standard Audio+ Video signals from a compatible transmitter such as the Altinex DA1930CT. The PE1004CF installs directly into the plasma monitor and converts the signals into Pioneer compatible inputs. -
Page 5: Description Of Pe1004Cf
DESCRIPTION OF PE1004CF APPLICATION DIAGRAMS DIAGRAM 1: INPUT SELECTION Selecting plasma Input 3 displays PE1004CF CAT-5 #1 Input image on the plasma Input 3. Selecting plasma Input 4 displays PE1004CF CAT-5 #2 Input image on the plasma Input 4. Selecting plasma Input 5 displays PE1004CF CAT-5 #3 Input image on the plasma Input 5. In order to force an input on the PE1004CF to a specific expansion input on the plasma monitor, it is necessary to select the desired plasma monitor input number first. -
Page 6: Diagram 2: Typical Setup
SPECIAL APPLICATION DIAGRAM 2: TYPICAL SETUP TYPICAL APPLICATION DA1930CT PE1004CF DA1930CT DA1931CT DA1930CT 400-0210-001... -
Page 7: Diagram 3: Internal View
DIAGRAM 3: INTERNAL VIEW RS232 3P TB EDGE CONNECTOR BUS CONTROL VIDEO INPUT 1 PAIRS 1,2,3 of UTP VIDEO INPUT 2 CAT5 PAIRS 1,2,3 RJ45 of UTP VIDEO VIDEO INPUT 3 PAIRS 1,2,3 of UTP INPUT4 15P HD RGBHV/ Y,Pb,Pr EDGE CONNECTOR POWER... -
Page 8: Diagram 4: Switch Settings
SPECIAL APPLICATION DIAGRAM 4: SWITCH SETTINGS VIDEO EQUALIZATION HARDWARE CONTROL POWER UP DEFAULT EQUALIZATION Install the jumper for default input. Set SW2 to the HW position for hardware equalization. In this case, CAT-5 Input #1. Set SW2 to the SW position for software equalization. 400-0210-001... -
Page 9: Installing Your Pe1004Cf
INSTALLING YOUR PE1004CF Step 1. Use ESD safety precautions and always wear a ground strap when handling the PE1004CF expansion card. Step 2. Prepare the card per the drawing in Diagram 4. Set SW2 for either hardware or software equalization control and set the power up default input. - Page 10 1. [SIDn] This command sets the ID number of the unit. The default unit ID is zero. Command Format: [SIDn] = Unit ID (n = # from 0 to 99) Example: Send the command [SID1] to the system. The unit ID is now one, and “C1” must be included at the end of each command line, as in “[VERC1]”, for only the unit with ID1 to respond.
- Page 11 7. [IN] This command is used to select the PE1004CF input that will be directed to the plasma display’s active expansion input. Command Format: [INnCi] n = Input Number (n = 1, 2, 3 or 4) Ci = Unit ID (i = # from 0 to 99) Example: Output the PE1004C’s CAT-5 #2 input to the plasma display input number 3.
-
Page 12: Summary Of Commands
Cause 2. Cause 2: The wrong input is selected. Solution: Select corresponds to the audio input. If no sound is present, see Cause 3. present, call Altinex source video input that... -
Page 13: Altinex Policy
If there is still no sound, see Solution 2 Solution 2: Set the volume of the destination amplifier to a reasonable level. If there is still no sound, call ALTINEX at (714) 990-2300. 400-0210-001 SPECIAL APPLICATION ALTINEX POLICY 9.1 LIMITED WARRANTY/RETURN POLICY...
