Summary of Contents for Advantech X10D
- Page 1 User Manual X10D Rugged Tablet PC...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 4: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. -
Page 5: Table Of Contents
......1 Introduction ....................2 1.1.1 Product Features ................2 1.1.2 Package Contents................. 2 1.1.3 Optional Accessories ..............2 Exploring the X10D ................... 3 1.2.1 Front View..................3 1.2.2 Right View..................4 1.2.3 Left View with Telephone Jack ............. 4 1.2.4 Left View with 3G SIM Card Slot (Optional)........ - Page 6 X10D User Manual...
-
Page 7: Chapter 1 General Information
Chapter General Information... -
Page 8: Introduction
This user manual outlines all you need to know to set up and use your X10D. If you have any further questions or queries, contact our technical support team. -
Page 9: Exploring The X10D
Exploring the X10D 1.2.1 Front View Component Microphone Touch-sensitive display (responds to stylus or finger) Power button Number / Tab / Esc buttons 4-Way navigation button with integrated enter button Function buttons Brightness / volume button Keyboard button Status LEDs:... -
Page 10: Right View
Left View with Telephone Jack 1.2.4 Left View with 3G SIM Card Slot (Optional) Component PC card slot (PCMCIA) CompactFlash card slot Headphone jack Microphone jack Telephone line jack/3G SIM card slot (optional) RJ-45 jack (for network cables) DC-in jack X10D User Manual... -
Page 11: Rear View
1.2.5 Rear View Component Stylus Battery compartment cover 1.2.6 Bottom View Component Docking connector X10D User Manual... -
Page 12: Specifications
One DC-In jack One docking connector Rechargeable Li-ion smart battery, 11.1V , Main Battery 5200mAh, 3S2P Universal AC 100V~240V , 50~60Hz input; 19V , Power Adapter 3.16A output, 60W Physical 310 x 236 x 42mm, approx. 2.9Kg X10D User Manual... -
Page 13: Getting Started
Insert the battery and secure the battery compartment door with the screws provided. Note! The arrow markings on the battery indicate the direction in which it should be inserted. Repeat the above steps in reverse to remove the battery . X10D User Manual... -
Page 14: Connecting The Power
1.4.2 Connecting the Power Before you can use your X10D, you must fully charge the battery . Connect the power adapter and leave to charge for a minimum of 4 hours before use. 1.4.3 Setup with Windows XP Professional Embedded When you first turn on the X10D, the following setup screens will appear. - Page 15 Enter the 25-digit product key to validate your copy of Windows. T ap Next. Enter a name to identify your X10D. This the name by which it will be recognized on all connected networks. Y ou can also enter a description if required. T ap Next to continue.
- Page 16 Enter an administrator password and re-confirm. T ap Next to continue. Choose whether or not to make the X10D part of a domain. If so, enter the domain name (ask your system administrator for details). T ap Next to continue.
- Page 17 Y ou can now configure your internet connection. T ap Yes, help me connect to the Internet to run the Internet Configuration Wizard. T ap Next to continue. Enter the names of other users of your X10D. Y ou can add up to five users. T ap Next to continue.
- Page 18 In the unlikely event the system should crash, do the following to reboot your system: Press the power button to turn on the X10D. During boot- up, PRESS UP KEY TO RUN RESTORE... is displayed. Press the up arrow button.
-
Page 19: Expansion Cards
Y ou can insert a Compact Flash memory card to store data, which needs to be later transferred to another machine, or to simply expand the storage capacity of the X10D. Y ou can use Compact Flash cards up to 2GB in size. - Page 20 Remove the card and close the memory card compartment cover. Inserting a PCMCIA Card Y ou can also insert a PCMCIA card to store and transfer data between computers with compatible PC card capabilities. Open the memory card compartment cover. X10D User Manual...
- Page 21 Insert the PCMCIA card, until it clicks into place. Close the memory card compartment cover. X10D User Manual...
- Page 22 Removing a PCMCIA Card Open the memory card compartment cover. Press the PCMCIA card switch inwards until the card pops out. Remove the card. Close the memory card compartment cover. X10D User Manual...
- Page 23 Open the left side cover where 3G SIM card slot is located. Make sure the system is off and push the SIM card into the slot with the metallic part facing up and the clipped corner facing outward until it clicks into place. Close the cover. X10D User Manual...
-
Page 24: Making Connections
Y ou can connect the X10D to an external monitor for enhanced viewing. Connect one end of a VGA cable to the VGA port on the right side of the X10D. Connect the other end to the VGA port on the monitor. - Page 25 Y ou can connect to either a home or work network using the RJ-45 port. Connect one end of the network cable to the RJ-45 port on the left side of the X10D and the other to your network hub or wall socket.
- Page 26 Connecting to a Telephone Line If you are accessing the Internet via a regular telephone line, you can connect the X10D using the telephone jack on the left side of the X10D. Connecting Headphones Y ou can connect a pair of headphones using the headphone jack on the left side of the X10D.
- Page 27 Connecting a Microphone The X10D features and in-built microphone, but you can connect an external micro- phone if needed. Connect the microphone to the microphone jack on the left side of the X10D as shown. Turning On Press and hold the power button to turn on the X10D.
-
Page 28: Controlling The X10D
The X10D is equipped with touchscreen technology , for ease of use when you are on the go. Simply use the pen to select icons and run applications. Remove the pen from its holder at the rear of the X10D and you are ready to go. Calibrating the T ouchscreen T o calibrate the touch screen, tap Start >... - Page 29 Check Plot calibration data to enable touch panel linearity compari- son graph. The blue lines show linearity before calibration and black lines show linearity after calibration. T ouch the points as displayed on screen using the pen. X10D User Manual...
- Page 30 The control panel buttons are located on the right of the touch screen. See below for a description of each button and its function. Button Name Function Power Press to power on and off the X10D Numbers Press to enter numbers Arrows Press to move up, down, left, right Enter...
- Page 31 Once you have assigned a function to one of the buttons, you can change it at a later date by tapping on the Tray icon in the system tray . Select Function Key Setting from the menu and follow the procedure above from step 2 to make any changes. X10D User Manual...
- Page 32 Press the right arrow to increase the volume, or the left arrow to decrease the vol- ume. Y ou can also adjust the screen brightness through the Tray . T ap the Tray icon in the system tray , and select Volume Adjustment. Move the slider to make adjustments. X10D User Manual...
-
Page 33: Chapter 2 Installation
Chapter Installation... -
Page 34: General Installation
Contact a wireless service provider for more information. The X10D comes pre-loaded with WLAN module, you can send and receive signals to a WiFi network then synchronize files. A wireless network can be added either when the network is detected or by manually entering settings information. - Page 35 Enter the required WEP key and reenter the key forconfirmation and then tap Connect. The wireless connection is negotiated and you see the following screen. The wireless connection icon in the notification area shows a connected status when- ever a wireless connection is present. X10D User Manual...
-
Page 36: Configuring A New Wireless Network
T ap Next to continue setup. Enter the name of your network and select whether to assign a secure network key automatically or manually (we recommend you allow the system to do this automatically).T ap Next to continue. X10D User Manual... - Page 37 USB flash drive to transfer settings). T ap Next to continue. (Skip to step 8 if you decide to configure each computer manually .) Insert your USB flash drive into a free USB slot and select the drive name from the drop-down list.T ap Next to continue. X10D User Manual...
- Page 38 All your current network settings are copied to your USB flash disk. T ap Next to continue. Setup is complete. T ap Print Network Settings to print a list of settings if you are configuring each computer manually . T ap Finish to complete the wizard. X10D User Manual...
- Page 39 Wireless Network Setup Wizard from the prompt that appears when you insert the disk into other computers. The network settings are transferred automatically . Bluetooth Connections The X10D comes with built-in Bluetooth functionality that allows you to connect and communicate with other Bluetooth-enabled devices. Setting Up Bluetooth Follow these instructions to set up a Bluetooth connection.
- Page 40 Select the My device is set up and ready to be found checkbox and tap Next. The Wizard searches for and displays other Bluetooth devices within range. T ap the device to connect to and tap Next. Y ou are prompted for a passkey . Select your option and tap Next. X10D User Manual...
- Page 41 X10D. GPRS Connection (optional) GPRS function is optional with X10D. It allows you to make 3G connection to the inter- net. See “Inserting 3G SIM Card (optional)” on page 17 for installation instruction. T ap Start > All Programs > Sierra Wireless > 3G Watcher > 3G Watcher to run the 3G software.
- Page 42 SIM card after you turn the power off GPS Connection (optional) GPS function comes optional with X10D. It allows you to view your GPS positions. Dif- ferent countries have different GPS positioning programs. You can download any GPS positioning program from website and install into this unit.
- Page 43 T ap Open GPS to start GPS. When satellites are detected, their positions are shown on the map. X10D User Manual...
- Page 44 X10D User Manual...
-
Page 45: Chapter 3 Operating The Lcd Display
Chapter Operating the LCD Display... -
Page 46: Osd User Controls
Checking Battery Status As it is likely you will be using your X10D when out and about, it is important that you monitor the battery status regularly , to ensure you do not run out of power at a criticall moment. - Page 47 Never Minimal Power Management 5 minutes 15 minutes 5 minutes Max Battery 1 minute 3 minutes 2 minutes Y ou can also access further power options through the Control Panel. Click Start >Control Panel > Power Options. X10D User Manual...
-
Page 48: Maintenance
3.2.3 Cleaning the X10D Turn off the X10D and unplug the power cord. Wipe the screen and exterior with a soft, damp cloth moistened only with water. Do not use liquid or aerosol cleaners on the screen, as these will discolor the finish and damage the screen. - Page 49 Appendix Accessories...
-
Page 50: Appendix A Accessories
A detachable handstrap and shoulder strap are provided to carry your T ablet PC securely and safely . Y ou can use the supplied handstrap and shoulder strap separately or together to carry the X10D when you are outside your home or office. When using the handstrap and shoulder strap separately: ... - Page 51 When using the handstrap and shoulder strap together: Attach the handstrap and shoulder bag to the rear of your tablet PC using four screws as shown. (Two long screws to the upper screw holes, and two short screws to the lower screwholes.) X10D User Manual...
- Page 52 Place the tablet PC on the tray with the retaining side arms clipped securely to the four rubber bumpers of the tablet PC. Vesa Mount Vesa mount can be used with a variety of alternate mounting solutions. Install the vesa mount by screwing on the screws as shown. X10D User Manual...
- Page 53 You can use the supplied PC docking stand to dock the tablet PC when you are at your home or office desk. When docked, you can charge power to and transfer data from your tablet PC to another PC. Attach the X10D to the PC docking stand as shown. X10D User Manual...
- Page 54 Connect USB connectors to these ports. Serial Ports Connect serial cables to these ports. DC-IN Connect the AC adapter to this port. Connecting Power to the Docking Connect the AC power adapter to the docking and the mains as shown below. X10D User Manual...
- Page 55 Desk Docking Specifications Feature Description Product Name X10D Tablet PC Docking Model Number By request External I/O Interfaces Two USB 2.0 host connectors (Or Factory Option: Four USB) Two RS-232/422/485 (Or Factory Option: extra two RS-232) One DC-in Power Adapter Universal AC 90V ~ 265V, 47~63Hz input;...
- Page 56 Attach the 3 points of tablet PC to the holster as shown. X10D User Manual...
- Page 57 X10D User Manual...
- Page 58 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2011...
