Basic Unit With Plenum,
Model P
Unit
Size
04
06
08
11
3
11
A
1'-8
/
"
2'-6
/
" 3'-2
/
"
16
16
16
B
1'-8
1
/
"
2'-6"
3'-2
1
/
"
2
2
C
1'-8
5
/
" 2'-5
13
/
" 3'-2
5
/
"
16
16
16
D
1'-10
3
/
" 2'-7
11
/
" 3'-4
3
/
"
16
16
16
1
3
1
E
2'-4
/
"
3'-1
/
"
3'-10
/
"
4
4
4
74
Dimensions
and Weights
Note:
1. The condensate drain connection is always on the right hand side of the unit as shown.
5
2. Coil connections are
/
" OD sweat.
8
CS - Cooling coil supply
CR - Cooling coil return
HS - Heating coil supply
HR - Heating coil return
3. All duct collar dimensions are to the outside of the collar.
Basic Series
With Plenum
UNT-PRC001-EN
