POOL AND SPA/HOT TUB HEATERS TR250 & TR400 MODELS
FOR YOUR SAFETY
WARNING: If the information in these instructions
is not followed exactly, a fi re or explosion may result
causing property damage, injury, or death.
Do not store or use gasoline or other fl ammable vapors or
liquids in the vicinity of this or any other appliance.
This product must be installed and serviced by authorized
personnel, qualifi ed in pool/spa heater installation. Im-
proper installation and/or operation can create carbon
monoxide gas and fl ue gases that can cause serious injury,
property damage, or death.
See www.hayward-pool.com/patent for U.S. and
Canadian patent information
OWNER'S MANUAL
WHAT TO DO IF YOU SMELL
GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fi re department.
- Installation and service must be per-
formed by a qualifi ed installer, service
agency, or the gas supplier.
1301150201 REV A 0715

Advertisement

Table of Contents
loading

Related Manuals for Trane TR250

Summary of Contents for Trane TR250

  • Page 1 OWNER’S MANUAL POOL AND SPA/HOT TUB HEATERS TR250 & TR400 MODELS WHAT TO DO IF YOU SMELL FOR YOUR SAFETY GAS: • Do not try to light any appliance. WARNING: If the information in these instructions • Do not touch any electrical switch; do is not followed exactly, a fi...

  • Page 2: Table Of Contents

    CONTENTS Warnings .......................3 Section I. General information ...............7 Section II. Consumer Operation & Maintenance ...........8 Maintaining proper water chemistry...............8 Lighting & Operating instructions label ............10 Temperature adjustment ................11 Temperature Lock-out..................12 Fahrenheit versus Celsius ................12 Winterization ....................12 Spring start-up .....................12 Error codes ....................13 Warranty ......................15...
  • Page 3 SAFETY INFORMATION Basic safety precautions should always be followed, including the following: Failure to follow instructions can cause severe injury and/or death. This is the safety-alert symbol. When you see this symbol on your equipment or in this manual, look for one of the following signal words and be alert to the potential for personal injury.

  • Page 4: Warnings

    NOTES TO THE ELECTRICIAN: Use a solid copper conductor, size 8 or larger. Run a continuous wire from external bonding lug to rein- forcing rod or mesh. Connect a No. 8 AWG solid copper bonding wire to the grounding lug provided on the heater and to all metal parts of swimming pool or spa, and to all electrical equipment, metal piping (except gas piping), and conduit within 5 ft.
  • Page 5 WARNING – Failure to remove pressure test plugs and/or plugs used in winterization of the pool/spa from the suction outlets can result in an increase potential for suction entrapment as described above. WARNING – Failure to keep suction outlet components clear of debris, such as leaves, dirt, hair, paper and other material can result in an increase potential for suction entrapment as described above.
  • Page 6 WARNING – The following “Safety Rules for Hot Tubs” recommended by the U.S. Consumer Product Safety Commission should be observed when using the spa. 1. Spa or hot tub water temperatures should never exceed 104°F [40°C]. A temperature of 100°F [38°C] is considered safe for a healthy adult.

  • Page 7: Section I. General Information

    SECTION I. GENERAL INFORMATION INTRODUCTION: This manual contains instructions for operation and the safe use of the swimming pool/spa/hot tub heat- ers. The manufacturer strongly recommends that the owner read the manual before using the swimming pool/ spa/hot tub heater. If after reviewing the manual any questions remain unanswered, contact the factory or local representative.

  • Page 8: Section Ii. Consumer Operation & Maintenance

    Premature Heat Exchanger Damage or Failure The heat exchanger in your Trane pool heater is made from the highest quality of copper and nickel (Cu- pronickel) materials. The premium materials and the exacting processes used in the manufacture of the heat exchanger is state of the art in pool heater design and manufacture.
  • Page 9 4. CHLORINATOR INSTALLATION Chlorinators must be installed downstream of the heater, and a check valve must be installed between the heater and chlorinator to prevent high chemical concentrations from back fl owing into the heater. Make sure your piping arrangement meets the chlorinator installation requirements shown in the installation manual on page 26. 5.

  • Page 10: Lighting & Operating Instructions Label

    Figure 2: Lighting & Operating Instructions label...

  • Page 11: Temperature Adjustment

    TEMPERATURE ADJUSTMENT This pool heater is equipped with a digital thermostat which allows the user to select the desired water temperature. The heater will then function automatically to maintain the desired temperature. The heater has 3 modes of operation: 1. STANDBY: in this mode, the heater will not function to heat the water. 2.

  • Page 12: Temperature Lock-Out

    TEMPERATURE LOCK-OUT: The digital thermostat in this pool heater allows the user to lock the maximum temperature setting allowed. This feature is useful for preventing unauthorized users from manually adjusting the temperature settings higher than desired. On a new heater, the maximum allowed temperature lock settings are initially set at the factory to 90°F for POOL mode, and 104°F for SPA mode.

  • Page 13: Error Codes

    ERROR CODES: Figure 4 lists the error codes that may be displayed on the heater display board. Contact a qualifi ed service company for assistance. Figure 4: ERROR CODES Code Description Information Internal fault/power-up On initial trial for ignition. Automatic reset is immediate once the gas valve relay error check results are acceptable.
  • Page 14 Figure 4: ERROR CODES (continued) Code Description Information Igniter open error If the control is not in lockout and senses that the igniter circuit is open when the blower is running the control will turn off the blower and go into lockout. Auto- matic restart 2 min after error is corrected.

  • Page 15: Warranty

    POOL HEATER CERTIFICATE OF LIMITED WARRANTY LIMITED HEATER WARRANTY TERMS AND COVERAGE: We warrant our pool heater to be free from defects in workmanship and materials under normal use and service. Pursuant to this warranty and subject to the Conditions and Exceptions indicated below: 1.
  • Page 16 ® MANUFACTURED FOR TRANE BY HAYWARD INDUSTRIES, INC. 2935 Sidco Dr. Nashville, TN 37204 ® Trane and the Trane Logo are registered trademarks of Trane International Inc. © 2015 Hayward Industries, Inc. Printed in U.S.A.
