Summary of Contents for Holux 236B
-
Page 1: Wireless Gps Receiver
HOLUX GPSlim236B Bluetooth GPS Receiver User’s Manual Wireless GPS Receiver User’s Guide HOLUX Technology Inc. 1F, No. 30, R&D Rd. II, HsinChu City 300, Science-based Industrial Park, Taiwan TEL: 03-6687000 FAX: 03-6687111 Website: www.holux.com Rev.: A All Right Reserved... -
Page 3: Table Of Contents
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual TABLE OF CONTENTS ...2 OVERVIEW ...3 PACKING LIST ...4 MAIN FUNCTIONS ...5 TECHNICAL SPECIFICATION ...6 4.1. ASIC PECIFICATION 4.2. CQUISITION 4.3. ECEIVER CCURACY 4.4..6 IMITATION 4.5..6 OWER UPPLY 4.6. UTPUT AND NTERFACE 4.7. -
Page 4: Overview
Architecture. is a dual-function GPS receiver. Not only transmit satellite information through the PDA or Notebook with Bluetooth interfaces but also is a G-Mouse GPS receiver through a data cable to deliver satellite signal to the device without Bluetooth interface. -
Page 5: Packing List
HOLUX GPSlim236B Bluetooth GPS Receiver User’s Manual 2. Packing List Congratulations on your purchase of the hope it will be useful to you for a long time. Before you begin, make sure that your package includes the following items. If any of these items are missing, please contact your local HOLUX dealer or distributor. -
Page 6: Main Functions
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual 3. Main functions provides a series of functions. It is well suited to system integration and users who use PDA, Notebook PC with Bluetooth device. Built in SiRF Star III Low power consumption chipset. -
Page 7: T Ime ( Averaged )
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual 4. Technical Specification 4.1. Basic Specification Chipset： SiRF Star III chipset Channels： 20 parallel satellite-tracking channels. Frequency： 1575.42 MHZ. Receiver： L1, C/A code. 4.2. Acquisition Time (averaged) Reacquisition： 0.1sec. Cold start： < 42 seconds. -
Page 8: Output And Interface
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual 4.6. Output and Interface Output I. Output protocol Baud Rate： 38400 bps Data bit： 8 Parity： No Stop bit： 1 II. Format. NMEA0183 V2.2： GPGGA (1time/1 sec), GPGSA (1 time/5 sec.), GPGSV (1time /5 sec.), GPRMC (1time /1 sec.), GPVTG (1 time/1 sec), (GLL, or SiRF binary format for optional). -
Page 9: Getting Started
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual 5. Getting Started STEP 1. Charge Battery Please charge battery till LED off for the first time. Power cable plug in Power cable connect to power socket ↓ Charge Battery Battery indicator light:... -
Page 10: Hardware Description
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual GPS Status --- in clear view of the sky without any obstruction for better satellite acquiring. Turn on power ↓ Steady orange Search GPS -- LED on ↓ Orange Position Fixed -- LED blinking 5.1. - Page 11 HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual 2). LED status : SYMBOL COLOR Blue Bluetooth Green Battery Orange 3). Power Switch : a. Power on, Orange b. Power off, Orange 4). External active antenna connector, see Fig.3 Connector type: MMCX.
- Page 12 HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual Table 1 Pin Name VOUT VCHARG 6). Optional accessories, and connector description, see Fig. 5. PC/Noteboo kUSB port USB Cable (GR230-A2) Mini USB USB Cable (GR230-A2) Signal and description Signal ground, Battery charging ground.
-
Page 13: Software Installation
Tap HOLUX GPSlim236B 4. Connect to SPP Slave Select SPP slave ↓ Next ↓ Finish 5. Finish Bluetooth Manager Setup Tap and Hold HOLUX GPSlim236B: SPP slave ↓ Connect ↓ Finish Bluetooth setup (opposite arrow is displayed) → → →... -
Page 14: Installation Of Testing Program
Setup your Pocket PC cradle to Desktop PC UART port. The Microsoft ActiveSync will detect your Pocket PC automatically, as Fig. 7. 3). Double click the GPSViewer.exe on your PC, then Holux GPSViewer.exe program will install automatically, as Fig. 8. - Page 15 HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual Push “Start”→ “Programs”→ “GPSViewer” on PDA, as Fig. 9. 5) The following window is show after executing GPSViewer, as Fig. 10. Setup Baud rate: 38400, then push “Scan” bottom to scan your COM Port (Example theIPAQ 3970 is the output port COM8).
-
Page 16: Optional Accessories
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual Select “GPS Status” to show the satellite diagram like below, as Fig. 14. Optional accessories has many accessories to satisfy customers’ requirement see table 2. After using with the following accessories, it can transmit message with PDA, Note Book easily. -
Page 17: Driver Installation
HOLUX GPSlim236B Wireless Bluetooth GPS Receiver Manual 7. Driver Installation You can use any except GR230-A2 USB cable. The following is the steps of installation GR230-A2 USB cable. 7.1 System Requirement CPU: IBM, Pentium, or other compatible PC. Memory: above 16 MB System: Windows 98/Me/2000/XP 7.2 Installation... -
Page 18: Trouble Shooting
No Signal port at the same time. Weak or no GPS signal when using to HOLUX if the inner Li battery has to be Connect an external antenna, which locate as a open space to your Cold start function. Go outdoor and run GPSViewer Cold start...
