  • Page 1 WIRELESS GUITAR SYSTEM...

  • Page 2: Important Safety Instructions

    WARNING TO PREVENT FIRE OR SHOCK HAZARD. DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE PLUG TO WIDE SLOT AND FULLY INSERT.
  • Page 3 ATTENTION: Pour éviter tout risque d’électrocution ou d’incendie, ne pas exposer cet appareil à la pluie ou à l’humidité. Pour éviter tout risque d’électrocution, ne pas ôter le couvercle ou le dos du boîtier. Cet appareil ne con- tient aucune pièce remplaçable par l'utilisateur. Confiez toutes les réparations à un personnel qualifié. Le signe avec un éclair dans un triangle prévient l’utilisateur de la présence d’une tension dangereuse et non isolée dans l’appareil.
  • Page 4 PRECAUCION: Para reducir el riesgo de incendios o descargas, no permita que este aparato quede expuesto a la lluvia o la humedad. Para reducir el riesgo de descarga eléctrica, nunca quite la tapa ni el chasis. Dentro del aparato no hay piezas susceptibles de ser reparadas por el usuario.
  • Page 5 Copyright 2008, Samson Technologies Corp. Printed December, 2008 v1.2 Samson Technologies Corp. 45 Gilpin Avenue Hauppauge, New York 11788-8816 Phone: 1-800-3-SAMSON (1-800-372-6766) Fax: 631-784-2201 www.samsontech.com...

  • Page 6: Table Of Contents

    Guided Tour - AR300 Receiver / Rear Panel ....6 Guided Tour - AG300 Transmitter ..... 7-8 Setting Up and Using Your AirLine Synth System .

  • Page 7: Introduction

    Channel Scan to help you find the clearest frequency to operate on. Once the AR300 finds the clearest channel, it’s easy to set the AG300 transmitter to the matching channel using the IR SET feature. The convenient, all metal half-rack chassis design features a large backlit LCD display and includes a rackmount kit to install into a standard 19-inch equipment rack.

  • Page 8: Quickstart

    Extend its antennas vertically and spread the tips horizontally outwards. 3. Set the power switch on your AG300 transmitter to the “off” position (away from the arrow) and place a fresh AA battery in it. Then turn the transmitter back on momentarily;...

  • Page 9: Quickstart

    15 dB pad on the transmitter. If not, slowly adjust the GAIN inside the AG300 to the point where the AF Meter occasionally reads “0” during the very loudest passages, then back it off just slightly. Finally, raise the level of your connected amplifier and/or mixer until the desired volume is reached.

  • Page 10: Guided Tour - Ar300 Receiver / Front Panel

    Guided Tour - AR300 Receiver / Front Panel 1. Antennas (A and B) - The antenna mountings allow full rotation for optimum placement. In normal operation, both Antenna A (the antenna on the left) and Antenna B (the antenna on the right) should be placed in a vertical position. Both antennas can be folded inward for convenience when transporting the AR300.
  • Page 11 Guided Tour - AR300 Receiver / Front Panel EDIT Control – This rotary encoder control knob/switch is used to control and set several menu functions and parameters displayed in the LCD display and it is also used to preform the automatic Channel Scan. Power Switch - Use this to turn the AR300 power on and off.

  • Page 12: Guided Tour - Ar300 Receiver / Rear Panel

    Guided Tour - AR300 Receiver / Rear Panel A: Antenna socket - D hole knockout for mounting the antennas to the rear panel using the optional rear antenna kit. B: DC input - Connect the supplied power adapter here, using the strain relief as shown in the illustration below.

  • Page 13: Guided Tour - Ag300 Transmitter

    Channel number that the transmitter is set to. 3: Power / Battery LED - This red LED flashes once when the AG300 is first turned indicating the transmitter has power. It will remain off as long as they battery is a good operating level.
  • Page 14 “Setting Up and Using the AirLine Synth System” section on page 15 in this manual. 10: Gain control - This miniature trimmer is used to fine tune the AG300’s input sensitivity. Use the included screwdriver to make the adjustments.

  • Page 15: Setting Up And Using Your Airline Synth System

    4. Make sure the Power On-Off switch in your AG300 transmitter is set to “Off” and that the MUTE is also to “ON”. Pull back gently on the AG300 battery cover at the ribbing and pry it upwards to remove it. Please use care when opening this cover as undue force can damage it.
  • Page 16 PAD on.) If the AF Meter bars are not all lit, slowly turn the AG300’s Gain control clockwise to the point where the AF Meter reaches ‘‘0” during the very loudest passages, then back it off just slightly;...

  • Page 17: Setting Up And Using Your Airline Synth System

    AG300 transmitter is turned off. To do so, use the provided screwdriver to rotate the Squelch control completely counterclockwise (to the “Min”...

  • Page 18: Ar300 Operation

    320 channel plan. That Absolute Channel number is shown on the AG300 transmitter’s LCD display. The AG300 displays the Absolute Channel number it its LCD for a few seconds, and then the display shuts off to preserve battery power. You can also see the transmitters Absolute Channel number by switching the Mute on.

  • Page 19: Ar300 Operation

    2. Next, turn the EDIT controller until you reach the desired frequency number. 3. Once you have the desired frequency set on the AR300 you’re ready to transmit the infrared channel data to the AG300. Have the transmitter ready in your hand with the Power switch set to off.

  • Page 20: Specifications

    Specifications SYSTEM SPECIFICATIONS Channels 319 channels 25kHz Step Operating Frequency 639.025MHz -646.975MHz (US) 798.025MHz-806MHz (Export) Frequency Type Modulation Type Noise Reduction Type Compander Distance 100 meters line of sight Audio Frequency Response 50Hz - 15KHz (+/- 3dB) Dynamic Range >100dB (IHF-A) AR300 RECEIVER Oscillation System Type of Reception...
  • Page 21 T.H.D. > 2% max (@1kHz, dev. 20kHz) Typical THD less than 1% Dimentions AG300 (45° jack) 113.95mm x 29.8xx x40.2mm (4.5” x 1.17” x 1.6”) L x W x H Weight .108 lb Specifications are subject to change without notice.
  • Page 22 FCC Rules and Regulations Samson wireless systems are type accepted under FCC rules parts 90, 74 and 15. Licensing of Samson equipment is the user’s responsibil- ity and licensability depends on the user’s classification, application and frequency selected. This device complies with RSS-210 of Industry &...
  • Page 24 Samson Technologies Corp. 45 Gilpin Avenue Hauppauge, New York 11788-8816 Phone: 1-800-3-SAMSON (1-800-372-6766) Fax: 631-784-2201 www.samsontech.com...
