Remote heat pump

Advertisement

RHA48B2A
Remote Heat Pump

Specifications

Cooling Capacity, BTUH (Nominal)
Compressor
R.L. Amps
L.R. Amps
Condenser Fan Motor
Horsepower
R.L. Amps
L.R. Amps
Liquid Line, Inches O.D.
Suction Line, Inches O.D.
Refrigerant Charge (oz)
Power Supply
Min Circuit Ampacity
Max Overcurrent Device
Electric Conduit Size (in)
Power Supply
Low Voltage
Approximate Shipping Weight (Lbs)
NOTE: It is important to electrically connect the unit and
properly size fuses/circuit breakers and wires in accor-
dance with all national and/or local electrical codes. Use
copper wire only.

Heat Pump Performance Data

For ARI Performance Data: See the ARI Directory, Product Data Booklet (PDB), or the product Service Manual.
65
60
T
33
32
Amps
24.5 22.6 21.2 19.9 19.2 18.8 17.7 16.8 16.0 15.3 14.6 14.2 14.0 13.3 12.4 11.7 10.7
HI PR
266
255
LO PR
71
66
Above information is for nominal CFM and 70° F indoor dry bulb.
All pressures are PSIG. All temperatures are °F.
Amps are outdoor unit amps.
Low pressure is measured at the gauge port. High pressure is measured at the liquid service valve.
June 1998
Heating Air Conditioning
48,000
24.6
131
1/4
1.7
3.3
3/8
7/8
181
208/230-60-1
32.4
50
1/2 or 3/4
1/2
170
RHA48B2A / BBA60A2A / CCA57FCC
Outdoor Ambient Temperature (° F)
55
50
47
45
40
30
28
27
26
24
245
234
229
224
216
62
56
53
51
47
Fayetteville, TN 37334
®
Specification Sheet
Due to policy of continual product improvement, the right
is reserved to change specifications and design without
notice.

Standard Features

• Bi-Flow Liquid Line Drier (Shipped Loose)
• Front Seating Valves
• 5 Minute Anti-Short Cycle Protection
• Time-Temperature Defrost System
• Low RPM (825) Condenser Fan
• Scroll Compressor
• Accumulator

Accessories

• Pressure Control Kit (PCK02A)
Automatic Reset High Pressure Switch
Time Delay
• Fossil Fuel Kit (FFK03A)
• Compressor Sound Blanket (CSB07A)
• Ambient Temperature Kit (ATK05)
• Low Ambient Control (LAC03A)
When mix matching with restrictor orifice indoor coil, use
restrictor orifice part number B1443805 or 11076312,
0.084" diameter.
NOTE: Defrost control compressor run time is factory set
at 90 minutes.
35
30
25
20
17
22
22
20
19
18
207
198
189
182
177
42
38
34
30
28
Amana
15
10
5
0
-5
17
15
13
12
10
174
168
161
155
149
27
23
19
16
14
-10
8
9.6
144
11
20209806
