Amana RHA60B2A Specification Sheet

RHA60B2A
Remote Heat Pump
Specifications
Cooling Capacity, BTUH (Nominal)
Compressor
R.L. Amps
L.R. Amps
Condenser Fan Motor
Horsepower
R.L. Amps
L.R. Amps
Liquid Line, Inches O.D.
Suction Line, Inches O.D.
Refrigerant Charge (oz)
Power Supply
Min Circuit Ampacity
Max Overcurrent Device
Electric Conduit Size (in)
Power Supply
Low Voltage
Approximate Shipping Weight (Lbs)
NOTE: It is important to electrically connect the unit and
properly size fuses/circuit breakers and wires in accor-
dance with all national and/or local electrical codes. Use
copper wire only.
Heat Pump Performance Data
For ARI Performance Data: See the ARI Directory, Product Data Booklet (PDB), or the product Service Manual.
65 60
T 34 32
Amps 23.6 21.9 20.4 19.2 18.5 18.1 17.1 16.2 15.5 14.8 14.1 13.7 13.5 12.8 11.9 11.2 10.3
HI PR 252 241
LO PR 69 64
Above information is for nominal CFM and 70° F indoor dry bulb.
All pressures are PSIG. All temperatures are °F.
Amps are outdoor unit amps.
Low pressure is measured at the gauge port. High pressure is measured at the liquid service valve.
June 1998
Heating Air Conditioning
60,000
28.8
169
1/4
1.7
3.3
3/8
1 1/8
167
208/230-60-1
37.7
60
1/2 or 3/4
1/2
180
RHA60B2A / BBA60A2A / CCA60FCC
Outdoor Ambient Temperature (° F)
55 50 47 45 40
31 29 27 26 25
232 222 217 212 204
60 55 52 50 46
Fayetteville, TN 37334
®
Specification Sheet
Due to policy of continual product improvement, the right
is reserved to change specifications and design without
notice.
Standard Features
• Bi-Flow Liquid Line Drier (Shipped Loose)
• Front Seating Valves
• 5 Minute Anti-Short Cycle Protection
• Time-Temperature Defrost System
• Low RPM (825) Condenser Fan
• Scroll Compressor
• Accumulator
Accessories
• Pressure Control Kit (PCK02A)
Automatic Reset High Pressure Switch
Time Delay
• Fossil Fuel Kit (FFK03A)
• Compressor Sound Blanket (CSB09A)
• Ambient Temperature Kit (ATK05)
• Low Ambient Control (LAC03A)
Unit is rated for 1 1/8" suction line. Factory connection is
7/8". Installer will need to supply 7/8" to 1 1/8" adapters for
suction line connections.
restrictor orifice indoor coils, use restrictor orifice part
number B1443827 or 11076323, 0.090" diameter.
NOTE: Defrost control compressor run time is factory set
at 90 minutes.
