2 Port USB2.0 PCMCIA Card
Features and Benefits
Fully supports EHCI and OHCI Compliant standards
Compliant with Universal Serial Bus specification revision 2.0
Provides two external Type A USB 2.0 (480Mbps) ports into your system
Supports simultaneous operation of multiple USB 2.0 and USB 1.1 devices
Supports data transfer rates of high-speed (480Mbps), full-speed (12Mbps), and low-speed (1.5Mbps)
Works with a various type of USB devices including hubs, removable drives, digital cameras, scanner, CD-RWs,
PC video cameras, printers, and more...
Note: USB 1.1 devices are limited to USB 1.1 speeds even when they are connected to USB 2.0 host adapter or
USB 2.0 hubs.
Package Contents
1 x USB 2.0 CardBus Adapter
1 x User Manual
System Requirements
Windows 98SE, ME, 2000 and XP 32/64. Vista 32/64, Mac OS 10.2.X, Liinux 2.4.x or later
Available CardBus Type II Slot
Hardware Description
CAUTION:
Use only switching power adapter with following specifications:
Switching power adapter (Optional) DC 5V, 1A
Polarity: Outside negative voltage(-) & Inside positive voltage(+)3.5mm power jack
Hardware Installation
General instructions for installing the card are provided below. Since the design of system may vary, refer to your
system's reference manual for further information, if needed.
1. Power off your notebook computer.
2. Insert the USB 2.0 CardBus Adapter into the Type II PC Card slot of your notebook computer. Make sure it is
inserted all the way in for a solid connection.
RC601
User Manual
