SERIAL PCI Express Card 4 Ports

Features and Benefits

Features
Bus
Connectors

System Requirements


Windows® XP/Vista/7 (32/64 bit)

PCI Express-enabled system with an available PCI Express slot

Package Contents


1 x PCIe Serial Card 4 Ports

1 x Bracket with two DB9 male serial ports

1 x Driver CD

1 x User Manual

Hardware Installation

1. Turn off the power to your computer.
2. Unplug the power cord and remove your computer's cover.
3. Remove the slot bracket from an available PCIe slot.
4. To install the card, carefully align the card's bus connector with the selected PCIe slot on
the motherboard. Push the board down firmly.
5. Replace the slot bracket's holding screw to secure the card.
6. Replace the computer cover and reconnect the power cord.
RC-305E

Compliant with PCI Express Base Specification 1.1

Supports 4 x UART serial port

Built-in 16C450/550 compatible UART

On chip 256 byte FIFOs in transmit and receive path of each
serial port

Data transfer rate up to 230400bps

PCI-Express x1

4 x DB9 male serial connectors
1
User Manual
