4. Attach the Center Foot (40) to the Frame (1)
with two M4 x 16mm Round Head Screws (92).
Then, return the elliptical exerciser to the
upright position.
5. Tip: Avoid pinching the Wire Harnesses (64,
65) during this step.
While another person holds the Upright (10)
near the Frame (1), connect the Upper Wire
Harness (65) to the Lower Wire Harness (64).
Then, insert the Upright (10) into the Frame (1).
Attach the Upright with four M8 x 19mm Patch
Screws (86) and four M8 Split Washers (97).
Tip: Start all the Patch Screws before tight-
ening any of them.
4
5
10
97
86
97
1
7
40
92
Avoid pinching the
Wire Harnesses (64, 65)
during this step
65
64
97
86
97
1
