Epson PowerLite 1715c Specifications
Projection System
Projection Method
LCD
Driving method
Epson High Temperature Poly-Silicon TFT
Pixel number
786,432 dots x 3 (1024 x 768) LCDs
Native resolution
XGA
Aspect ratio
4:3 (supports 16:9, 5:4)
Pixel arrangement
Stripe
Projection Lens
Type
Manual: zoom / focus
F-number
1.6 – 1.77
f-number
23.7 – 28.5mm
Zoom ratio
1.0:1.2
Lamp
Type
170W UHE
Life*
2000H
(High Brightness)
Screen Size
(Projected distance)
Keystone Correction
Auto Keystone Correction
Brightness
(Typical)
Contrast Ratio
Brightness Uniformity
(Typical)
Color Reproduction
Audio Output
Operating Temperature
Power Supply Voltage
Power Consumption
Dimensions (W x D x H)
Weight
Fan Noise
Effective Scanning Frequency Range
Pixel clock
Horizontal
Vertical
Remote Control
Features
Power, e-zoom, page up/page down, source
selection, color mode, volume, A/V mute,
freeze, resize, menu, help, auto, pointer
Operating angle
Right/Left +/- 30 degrees
Upper/Lower +/- 15 degrees
Operating distance
20 ft (6m)
RGB
Analog RGB I/O
Display performance
Native
1024 x 768
Resize
1600 x 1200, 1280 x 1024, 800 x 600,
640 x 480
Input terminal
Video
Mini D-sub 15 pin
Audio
Stereo mini jack
* Lamp life results will vary depending upon mode selected, environmental conditions, and usage.
Lamp brightness decreases over time.
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Specifications and terms are subject to change without notice. Epson is a registered trademark and Exceed Your Vision and Instant Off are trademarks of Seiko Epson Corporation. PowerLite
and PrivateLine are registered trademarks and Epson Connection and Epson PresentersOnline are service marks of Epson America, Inc. All other product and brand names are trademarks
and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 2006 Epson America, Inc. CPD-22347 12.5K 8/06
Epson original 3LCD technology
Front/rear/ceiling mount
, 3000H
(Low Brightness)
30" to 300" (3.2' to 39.7')
Vertical: +/-30°
2700 lumens
(High Brightness)
2100 lumens
(Low Brightness)
400:1
83%
Full color (16.7 mil)
1W Monaural
41°F to 95°F (5°C to 35°C)
100-240VAC +/-10%, 50/60Hz
244W power on
4W in standby
10.7" x 7.6" x 3.1"
3.7lb
40db
,
(High Brightness)
35db
(Low Brightness)
13.5MHz to 162MHz
15KHz to 92KHz
50Hz to 85Hz
Video I/O
Display performance
NTSC: 560 lines
PAL: 560 lines
(Depends on observation of the multi
burst pattern)
Input signal
NTSC, NTSC4.43, PAL, M-PAL, N-PAL,
PAL60, SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video
Composite Video: RCA
S-Video: Mini DIN;
Component Video: Mini D-sub 15pin
(in common with Analog RGB connector);
Video-RGB: Mini D-sub 15pin (in common
with Analog RGB connector)
USB 2.0 type B display
Audio
Stereo mini jack
Audio signal
500 mVrms/47Kohm
Control I/O
I/O terminal
USB 2.0 connector type B
(for mouse, keyboard and video display)
USB connector type A
(for DSC, USB memory)
Security
Kensington
password protect
Warranty
Two-year limited warranty, two-year international warranty, 90-day lamp
warranty, Epson Road Service Program and Epson PrivateLine dedicated
toll-free support (U.S. and Canada only)
Supplied Accessories
Power cable, remote control with batteries, wireless 802.11 a/b/g module,
computer cable, audio adapter cable, USB A/USB B cable, owners manual,
CD-Rom, EasyMP Software CD-Rom, Start Here Kit, soft carrying case
Product/Accessory Part Numbers
Epson PowerLite 1715c projector
Replacement lamp
Air filter set
Ethernet LAN Module
Samsonite wheeled soft case w/laptop
Samsonite soft shoulder case
ATA molded hardshell case
Ceiling mount
Suspension adapter
False ceiling plate
Security bracket/cabling for gyro lock mounts
Adjustable ceiling channel
Component video cable
S-Video cable
Distribution amplifier
50" portable screen
60" portable pop-up screen
80" portable pop-up screen
83.6" class room style pull-down screen
High-Resolution Document Imager (ELPDC05)
Kensington security lock
Support–The Epson Connection
SM
Pre-Sales Support U.S. and Canada
Automated Technical Support
Internet Web Site
SM
®
-style lock provision,
V11H228020
V13H010L38
V13H134A08
V12H005M02
ELPKS35-S
ELPKS43
ELPKS42
ELPMBUNI
ELPMBAPL
ELPMBFCP
ELPMBSEC
ELPMBACC
ELPKC19
ELPSV01
ELPDA01
ELPSC06
ELPSC07
ELPSC08
ELPSC09
V12H162020
ELPSL01
800-463-7766
800-922-8911
www.epson.com
presentersonline.com
Printed on Recycled Paper
