Owners Guide
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING
1. Do not store spare liquid propane
cylinder within 10 feet (3m) of this
appliance.
2. Do not store or use gasoline or other
flammable liquids or vapors within 25
feet (8m) of this appliance.
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for future
use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting"
Instructions section of this manual
Liquid Propane Gas
®
®
Y
OU MUST READ THIS
BEFORE OPERATING YOUR GAS GRILL
A041.f
B005.d
C003.e
D005.f
O
G
WNERS
UIDE
55145 03/29/01
Advertisement
Table of Contents
Related Manuals for Weber Genesis Silver-C LP 032301
Summary of Contents for Weber Genesis Silver-C LP 032301
- Page 1 Owners Guide DANGER If you smell gas: Liquid Propane Gas 1. Shut off gas to the appliance. 2. Extinguish any open flames. 3. Open lid 4. If odor continues, keep away from the appliance and immediately call your gas ® ®...
-
Page 2: Warranty
Improper assembly may be dangerous. Please carefully follow the assembly instructions in this manual. After a period of storage, and/or nonuse, the Weber Gas Barbecue should be checked for gas leaks and burner obstructions before use. See instructions in this manual for correct procedures. - Page 3 The charges must be prepaid. Weber will return parts to the phone number is on the warning decal, which is purchaser, freight or postage prepaid.
-
Page 4: Table Of Contents
Contents Danger & Warnings ........ A-2 Warranty ..........A-3 General Instructions ....... A-5 Exploded View ........A-6 Parts List ..........A-9 Assembly Instructions ......B-1 Installing Features ........C-1 Cast Iron Cooking Grate Care ....C-D Operating ..........D-1 Lighting ........... D-1 Manual Lighting ........ -
Page 5: General Instructions
The gas must be turned OFF at the LP cylinder Your Weber Gas Barbecue is a portable outdoor when the Weber Gas Barbecue is not in use. cooking appliance. With the Weber Gas Barbecue you When the Weber Gas Barbecue is stored indoors,... - Page 6 Genesis Silver-C LP 032301...
- Page 7 Hinge Pin Hair Pin Cotter Left Endcap Thermometer Shroud Right Endcap Handle Burner Control Knobs Warm-Up ™ Basket Control Panel Warming Rack Ignitor Button Cooking Grates Control Panel Hardware Flavorizer ® Bars Side Burner Cooking Box Crossover tube 1/4-20 keps nut Front and Back Burners Slide Out Bottom Tray Center Burner...
- Page 8 ® of Weber-Stephen Products Co., 200 East Daniels Road, Palatine, IL, 60067-6266, U.S.A. This product is covered by one or more United States patents and patents in other nations globally. Printed in the U.S.A.
- Page 9 You will need: Left Frame - 1 Screwdriver Phillips screwdriver Right Frame - 1 Hammer Wheel Frame - 1 7/16 open-end or an adjustable wrench Pliers Caster Frame - 1 Block of wood Frame Connectors - 2 Lid - 1 Sideburner - 1 Work Surface - 1 Cooking Box - 1...
- Page 10 Warming Rack - 1 Burner Control Knobs - 3 Warm-Up Basket - 1 Hinge Pins (1/4 x 1 1/2 inch clevis pin) - 2 Flavorizer Bars - 5 2 inch bolts (1/4 x 20 x 2 inch bolts) - 5 Cylinder Panel - 1 1 3/4 inch bolts (1/4 x 20 x 1 3/4 inch bolts) - 2 Front Panel - 1...
-
Page 11: Assembly Instructions
Tap one hubcap onto the end Note - Work on carpeted area (on grass or one of the of the axle rod. Slide one wheel onto the axle, WEBER boxes) to protect the finish during frame assembly. - Page 12 Continue frame assembly Add back panel You will need: caster frame and wheel frame. You will need: frame assembly, back panel, two 1/2 Place the caster frame onto the tabs of the left frame, inch bolts, two nylon washers, and a 7/16 or adjustable so that the swing table locking bracket (1) is to the rear.
- Page 13 Add cooking box (assembly) You will need: frame assembly, cooking box Your Weber Gas Grill manifold assembly, consisting of (assembly), 2 inch bolt, nylon washer, keps nut, pliers gas manifold, valves, hose, regulator and gas burners and a 7/16 inch or adjustable wrench.
- Page 14 Install manifold brackets Slide the cylinder panel up until notch at bottom of The manifold brackets(2) are already in place on the panel fits over the cross brace(1). Add nylon washer to manifold between the valves. bolt and insert through the hole in the wheel frame at Place your hand underneath the manifold.
- Page 15 Install igniter Install the slide out bottom tray Note - The igniter wires are already attached to the You will need: the slide out bottom tray(1), catch pan Gas Catcher Ignition Chamber and the igniter. This holder(2), catch pan and one disposable drip pan. was done to factory test the ignition system.
- Page 16 Install Lid Install control panel and burner control knobs You will need: lid, two hair pin cotters(1) and two hinge You will need: control panel, two Phillips screws/ pins(2). washers, a Phillips screwdriver, and burner control Place lid on top of the cooking box. Align the hinges at knobs.
-
Page 17: Installing Features
Installing Features Install the right trim piece with tool holders Install the left end trim piece and swing-up work You will need: Right trim piece with tool holders surface Push the Right trim piece into the frame as shown(1), You will need: End trim piece, swing-up work surface, swing-up work surface rod, two 1/2 inch bolts, two making sure that the tabs on the underside of the trim piece are snapped into the slots in the frame.(2) - Page 18 3.) Insert one end of the swing-up work surface rod 5.) Add a washer to each bolt and insert it through the into the hole in the frame. hole in the frame and the hole in the trim piece on both sides.
- Page 19 Install the work surface Set the side burner in place in the frame. The side You will need: work surface. burner locking clip on the right should latch under the Place the work surface, so that the front and back right trim piece.
- Page 20 Install Flavorizer® Bars and Cooking Grates You will need: Warm-Up Basket You will need: five Flavorizer Bars and two cooking Insert one end of the Weber Warm-Up Basket into the grates. hole at the right side of the inside of the lid, and the Place the Flavorizer Bars side by side in the cooking other end into the slot at the left side of the lid.
- Page 21 Install the thermometer Install the bottom shelf You will need: Thermometer. You will need: Bottom shelf. Insert the thermometer into its holder on the right side Set the bottom shelf in place between the two frame of the lid. connectors underneath the cooking box.
- Page 22 1) Turn the LP cylinder so the opening of the valve is either to the front, side or rear of the Weber Gas Barbecue. Lift and hook the cylinder onto the fuel...
- Page 23 3) Manifold to side burner hose connection. you should recheck all fittings for leaks before using 4) Side burner hose to side burner connection. your Weber Gas Barbecue. Shipping and handling may 5) Valves to manifold connections. loosen or damage a gas fitting.
-
Page 24: Operating
WARNING: Do not lean over the open barbecue. the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber Keep your face and body at least one foot away authorized replacement hose. Contact the... -
Page 25: Manual Lighting
3) Turn the cylinder on by turning the cylinder valve Manual Lighting counterclockwise. 4) Strike a match and put the flame into the DANGER matchlight hole in the front of the cooking box. Failure to open the lid while igniting the WARNING: Do not lean over open barbecue. -
Page 26: Lighting The Side Burner
Lighting the Side Burner Lighting the side burner if the main burners are lit. 1) Open the side burner lid. 2) Push down and turn the side burner control to HI. The side burner has a separate ignition system from 3) Press the side burner igniter button several times so the main cooking box. -
Page 27: Cooking
The control settings: High (H), Medium (M), the slide out bottom tray are free from debris that Low (L), or Off (O) are described in your Weber might obstruct the flow of combustion or ventilation air. I The Spider /Insect Screens should also be checked cookbook. -
Page 28: Refilling The Liquid Propane Cylinder
NEVER store a spare LP Cylinder under or near this barbecue. NEVER fill the tank beyond 80% full. Your Weber gas grill is equipped with a cylinder supply system designed for vapor withdrawal. WARNING: Only use this grill outdoors in a well- ventilated area. - Page 29 6) Turn on the cylinder valve. 1) Turn the LP cylinder so the opening of the valve is either to the front, side or rear of the Weber Gas Barbecue. Lift and hook the cylinder onto the fuel gauge.
- Page 30 I The LP cylinder and connections supplied with your pressure, inside a cylinder, LP gas is a liquid. As the Weber Gas Barbecue have been designed and tested pressure is released, the liquid readily vaporizes and to meet government, American Gas Association, and becomes gas.
-
Page 31: Annual Maintenance
The burners have been flame tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber Gas Barbecue. Shipping and handling may have loosened or damaged a gas fitting. WARNING: Perform these leak checks even if your barbecue was dealer- or store-assembled. -
Page 32: General Maintenance
The Weber Gas Barbecue burners have been factory Weber Spider /Insect screens set for the correct air and gas mixture. The correct Your Weber Gas Barbecue, as well as any outdoor gas flame pattern is shown. appliance, is a target for spiders and other insects. -
Page 33: Replacing Main Burners
Replacing Main Burners 6) Lift and twist the burner assembly slightly, to separate the crossover tube(1) from the burners. 1) Your Weber Gas Barbecue must be OFF and cool. Remove the burners from the cooking box. 2) Turn gas OFF at source. -
Page 34: Crossover Ignition System Operations
Crossover® Ignition System Operations If the Crossover Ignition System fails to ignite the Left burner, light the Left burner with a match. If the Left burner lights with a match, then check the Crossover Ignition System. I Check that both the white(1) and black(2) ignition wires are attached properly. -
Page 35: Troubleshooting
Troubleshooting Problem Check Cure Clean Spider/Insect Screens. (See Burners burn with a yellow or Inspect Spider/Insect Screens for orange flame, in conjunction with possible obstructions. (Blockage of Section “Annual Maintenance”) the smell of gas. holes.) The excess flow safety device, To reset the excess flow safety Burners do not light. -
Page 36: Side Burner Troubleshooting
Side Burner Troubleshooting WARNING: Before attempting any troubleshooting steps, all gas controls and supply valves should be in the OFF position. Problem Check Cure Side Burner does not light. Is gas supply off? Turn supply on. Is the fuel hose bent or kinked? Flame is low in HIGH position.
