Mobile Media Station
IVA-D900R
DIGITAL VIDEO
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L'USO
Si prega di leggere prima di utilizzare
l'attrezzatura.
• ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa
igenom denna användarhandledning.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Phone 03-9769-0000
ALPINE ELECTRONICS GmbH
Frankfurter Ring 117,
80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
Designed by ALPINE Japan
Printed in Japan (Y)
68-00323Z63-A
EN
DE
FR
ES
IT
SE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVA-D900R and is the answer not in the manual?

Questions and answers

Related Manuals for Alpine IVA-D900R

Summary of Contents for Alpine IVA-D900R

  • Page 1 • ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS FRANCE S.A.R.L. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 1-1-8 Nishi Gotanda, (RCS PONTOISE B 338 101 280) 6-8 Fiveways Boulevarde Keysborough, Shinagawa-ku, 98, Rue de la Belle Etoile, Z.I.

  • Page 2: Table Of Contents

    ENGLISH CD/MP3 Contents Playback ............14 Repeat Play ............. 14 Operating Instructions M.I.X. (Random Play) ........15 Selecting Folders (concerning MP3) ....15 WARNING About MP3 ............15 WARNING ..........4 DVD/Video CD CAUTION ........... 4 Playing DVD/Video CD ......... 16 PRECAUTIONS .........
  • Page 3 Other Useful Features Setting for Automatic Change from DAB to RDS ............. 34 Titling Discs ............ 26 Switching the Display Language of PTY Displaying the Title List ......... 26 (Programme Type) ........34 Setting of Scrolling ......... 27 Switching the incoming calls of the telephone ... 34 Rear Enter Function ........
  • Page 4 Remote Control Turning ON/OFF Traffic News Announcement ..........41 Operating for the IVA-D900R ......54 Setting the Announcement Select Mode ..41 Operating the DVD player/DVD changer Changing the Display Mode ......42 (sold separately) .......... 56 To display the Dynamic Label (Radio Text) ... 42 Operating the Navigation (sold separately) ..

  • Page 5: Operating Instructions

    DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR Failure to do so may cause personal injury or damage to the ATTENTION AWAY FROM SAFELY DRIVING YOUR product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing. VEHICLE.

  • Page 6: Precautions

    Be sure the temperature inside the vehicle is between +45°C Installation Location (+113°F) and 0°C (+32°F) before turning your unit on. Make sure the IVA-D900R will not be installed in a location Moisture Condensation subjected to: You may notice the disc playback sound wavering due to •...

  • Page 7: Discs Playable On This Unit

    DVD player. IVA-D900R. This has been done for the safety of the driver and passengers. Title Input and Audio Processor Adjustments cannot be made if the car is moving.
  • Page 8 Tips for making your own CDs recognized as illegally copied.) The IVA-D900R plays DVD Video, Video CD, Audio CD and has • In the following cases, the disc may not play on this unit: a built in MP3 decoder.

  • Page 9: Getting Started

    Getting Started Press SOURCE/POWER. The display shows the main menu screen. Turn the Rotary encoder and select "DVD PLAYER" from the main menu. Action indicator OPEN/CLOSE TILT • If an optional DVD player or DVD Changer is connected and MUTE FLAT/SLIDE its power is on, the display shows "...

  • Page 10: Turning Power On Or Off

    Initial System Start-Up seconds to turn off the unit. • The IVA-D900R draws minimal current even when its power switch Immediately after installing or applying power to the unit, it should be is turned off. If the switched power (ignition) lead of the IVA- initialized.

  • Page 11: Selecting The Monitor Opening Angle

    Selecting the Monitor Opening Angle Adjusting the Volume/Balance (Between Left and Right)/Fader (Between Front and Rear)/ The monitor opening angle can be set in 2 positions. Defeat Press and hold FLAT/SLIDE for at least 2 seconds while the monitor is being raised. Press the Rotary encoder repeatedly until the Each press changes the monitor angle back or forth.

  • Page 12: Radio

    Manual Storing of Station Presets Radio Tune in a desired radio station you wish to store in the preset memory by manual or automatic seek tuning. Press 7 (PAGE 1/2). Press and hold any one of the Function buttons 1 (P.SET 1) through 6 (P.SET 6) for at least 2 seconds.

  • Page 13: Rds Operation

    Receiving Traffic Information RDS Operation Press T.INFO/ANNC. to turn on the Traffic Information mode. T.INFO/ANNC. When the traffic information station is tuned in, the TP indicator lights up. Traffic information is heard only when it is being broadcast. If traffic information is not being broadcast, the unit is set in the standby mode.

  • Page 14: Receiving Traffic Information While Playing Cd Or Radio

    Receiving Traffic Information While Playing Displaying Radio Text CD or Radio Text messages from a radio station can be displayed. The example explained here is how to receive the traffic information Tune in a radio station that transmits text broadcast during CD playback. messages.

  • Page 15: Cd/Mp3

    If you use an optional CD player, press the eject button on the SOURCE/POWER optional CD player. • The IVA-D900R models include a built-in MP3 unit. You can play CD-ROMs, CD-Rs, and CD-RWs containing MP3 files on this unit. Playback Use the format compliant with ISO9660 level 1 or level 2.

  • Page 16: Random Play)

    M.I.X. (Random Play) About MP3 Press 5 (M.I.X.) in the play or pause mode. CAUTION Except for personal enjoyment, duplicating audio data (including The tracks (files) on the disc will be played back in a random MP3 data) or distributing, transferring, or copying it, whether for sequence.

  • Page 17: Dvd/Video Cd

    Rotary encoder V.SEL SOURCE/POWER Playing DVD/Video CD IVA-D900R has a built-in DVD player. When an optional Alpine DVD/video CD/CD player (or DVD changer) is connected to the IVA- D900R, you can control it from the IVA-D900R. WARNING It is dangerous for the driver to watch the TV/Video...

  • Page 18: To Display The Dvd Mode Screen

    DVD’s instructions for details on to play the disc. The display shows the Function Guide. the features supported. When an optional Alpine DVD player is connected: • Fingerprints on a disc may adversely affect Insert a disc into the DVD/video CD/CD player, the player playback.

  • Page 19: If A Menu Screen Appears

    To check the disc working status during play If a menu screen appears 1 Press V.SEL when your vehicle stops. Each pressing switches the visual source. On DVDs and Video CDs with playback control (PBC), menu screens may appear automatically. If this happens, perform The menu screen of the DVD mode is displayed.

  • Page 20: Fast-Forwarding/Fast-Reversing

    Fast-forwarding/Fast-reversing Slow Motion Playback During playback, press and hold 1 ( g ) (fast- When 3 ( f ) is pressed and held in while in the reverse) or 3 ( f ) (fast-forward). pause mode, the 1/8th speed slow motion playback When pressed for more than 1 second, the disc is mode is set.

  • Page 21: Searching By Title Number (Dvd Only)

    • If the track number is a 2-digit number, playback starts Searching by Title Number (DVD only) automatically even if ENTER is not pressed in step 2. • If the chapter number is a 3-digit number, playback starts automatically even if ENTER is not pressed in step 2. Use this function to easily find positions on the DVD using the •...

  • Page 22: Switching The Subtitles (Subtitle Language) (Dvd Only)

    Switching the Subtitles (Subtitle Language) Displaying the Disc Status for DVD (DVD only) Use the procedure described below to display the status (title number, chapter number, etc.) of the currently playing DVD on the monitor With DVDs on which multiple subtitle languages are recorded, the screen.

  • Page 23: Sound Setting

    MX FM (OFF, FM1 to 3) Sound Setting The medium to high frequencies become more clear, and produces well balanced sound in all the bands. MX DVD (OFF, MOVIE 1 to 2) The dialog portion of the video is reproduced more clearly.

  • Page 24: Setting The Bass Control

    Emphasizes the displayed bass frequency ranges. To correct this, the IVA-D900R is able to delay the audio signal to the speakers closest to the listener. This effectively creates a perception of Setting the bass Level: increased distance for those speakers.

  • Page 25: Bass Focus

    The sound is not balanced because the distance between the Example of Bass Focus Setting listening position and the various speakers is different. 1 After entering corrections for the front (left and right) The difference in distance between the front left speaker and speakers in STEP 15, the time difference is 1.5 ms for the rear right speaker is 1.75 m (68-7/8").

  • Page 26: Time Correction

    Time Correction Subwoofer On and Off Setting item: TIME CORRECTION Press SOURCE/POWER. Setting contents: TIME DN/UP/FRONT-LEFT/FRONT-RIGHT/ The main menu is displayed. REAR-LEFT/REAR-RIGHT Press 4 (A.PROC). Before performing the following procedures, refer to “About the Time Correction” (page 23). The A.PROC (Audio processor) list screen is displayed. Selecting the speaker: Turn the Rotary encoder to select “SUBWOOFER.”...

  • Page 27: Other Useful Features

    • If the memory capacity for Disc titles is full and if you attempt to Other Useful Features title a new disc, the oldest title will be erased to make room for the new one. To delete a title, select the title you want to delete, then select "SPC"...

  • Page 28: Setting Of Scrolling

    • When there is an external interruption, the external interruption icon is prior to the others. • When you watch the built-in DVD in IVA-D900R (front monitor) The rear enter function independently routes different sources to the and in the rear monitor, the On Screen display of the rear monitor front and the rear inside a car.

  • Page 29: Switching Display Modes

    MODE3 In Mode 3 (Cinema), the monitor displays a normal picture by stretching out the picture horizontally and vertically. This mode is good for displaying a cinema type picture at the 16 : 9 ratio. Switching the Visual Source Only Rotary encoder (Simul Function) WIDE/DISP.

  • Page 30: Setup

    • With the DVD screen displayed, pressing and rotating the rotary Setup encoder will adjust the volume level. • Immediately after inputting titles or changing the settings of DVD mode (while the system is inputting the titles or data automatically) do not turn the ignition key (engine key) to OFF.

  • Page 31: Changing The Country Code Setting

    Changing the Country Code Setting Set the rating level of PARENTAL 4 Turn the Rotary encoder to select PARENTAL LEVEL. Setting item: COUNTRY CODE 5 Press 1 (;DN) or 2 (UP:) to select the rating level (1 Setting content: CODE to 8).

  • Page 32: Changing The Digital Output Setting

    Changing the Digital Output Setting Use the following procedure to set the digital audio signal output from the IVA-D900R. Setting item: DIGITAL OUT MODE Setting contents: AUTO / LPCM AUTO: The digital output is switched automatically according to the type of audio signals being played.

  • Page 33: Setting The Digital Output

    Setting the Digital Output GENERAL Setup To connect an audio processor using the optical digital output, set to “ON” by the following procedure. Setting item: OPT.OUT Setting contents: OFF / ON • Afterwards, set ACC to OFF once, then turn it ON again. The setting of Digital Output is decided.

  • Page 34: Setting Automatic Opening/Closing Of The Monitor

    You can display the screen of the preset item by just pressing the Activate the Sound Guide mode. V.SEL button on the IVA-D900R. OFF: Deactivate the Sound Guide mode. The sound guide beep will not be produced when a button on the unit is NAV.: Pressing V.SEL directly switches to the navigation...

  • Page 35: Rds Time Display

    • Use this function when the DAB Receiver Box is connected. Setting content: NORMAL / HI-FI / STABLE The IVA-D900R incorporates the MAX TUNE Pro for the highest Switching the Display Language of PTY (Programme Type) quality tuner audio. Moreover, you can choose between 3 settings to Setting item: PTY LANGUAGE suit your own personal sound preferences and usage.

  • Page 36: System Setup Operation

    The navigation interruption mode is on. Guide of TV mode appears. • Only when an Alpine TV tuner is connected, can you operate the 1) After setting it to ON, press the Rotary encoder to select displayed function guide from this unit.

  • Page 37: Setting Of The Rear Camera

    Setting content: OFF / ON setting of optical digital input switch is decided. If an Alpine Ai-NET Interrupt Box (NVE-K200) is connected to the IVA-D900R, an Auxiliary Source will be allowed to interrupt the current audio source. For example, you can listen to the voice...

  • Page 38: Display Setup Operation

    Adjusting Tint of Picture Display Setup Operation Setting item: TINT Setting content: GRN. / ±0 / RED The Parking Brake must be engaged to access the Display Tint adjustment can be made only in the navigation, DVD, AUX1, mode screen. Attempting to access this screen while driving will display the warning-CAN'T OPERATE WHILE DRIVING.

  • Page 39: Navigation System (Optional)

    If an optional Alpine Navigation System is connected to the IVA- To operate your devices connected to the AUX terminals on the rear D900R, some of its functions can be controlled from the IVA-D900R. panel of IVA-D900R, follow the procedure described below.

  • Page 40: Changer (Optional)

    IVA-D900R if it is Ai-NET compatible. With a CD Changer Turn the Rotary encoder to select a desired connected to the Ai-NET input of the IVA-D900R, the CD Changer changer. will be controllable from the IVA-D900R. The display shows the selected CD changer mode If you connect a changer compatible with MP3, you can play CD- screen.

  • Page 41: Dab Operation (Optional)

    Changing the Service DAB Operation Services are received within the ensemble that you are currently (Optional) receiving. Press 2 (ENS./SERV.) to switch to the Service. T.INFO/ANNC. “SERV.” indicator lights up. While receiving the ensemble, momentarily press ) or 3 ( ), and select the service that you desire.

  • Page 42: Memorizing The Ensemble Automatically

    • When you receive the Secondary Service Component, you Setting the Announcement Select Mode memorize the service, but when you call out this memorized service, the Primary Service Component will be called out. Press RDS/T.TEXT. The display changes to the *RDS/DAB mode screen. Memorizing the Ensemble Automatically * RDS mode screen when DAB is not connected.

  • Page 43: Changing The Display Mode

    • When there is an incoming call while the power of IVA-D900R is OFF, the power of IVA-D900R will turn ON automatically for a hands-free call.

  • Page 44: Telephone Reception

    Input the telephone number using the dial. • The telephone volume can be adjusted from the IVA-D900R. The Press and hold the Rotary encoder for more than volume you set during the call is memorized, and is automatically 2 seconds.

  • Page 45: Calling By The Address Book

    Calling by the address book SMS (Short Message Service) Operation From your vehicle, call from the address book registered in the portable telephone. You can receive messages, show the contents of messages, and send standardized sentences. Press and hold the Rotary encoder for more than When a message is received, an icon is indicated on the display.

  • Page 46: Sending A Standardized Sentence

    Sending a standardized sentence You can select a standardized sentence when you send a mail. Press and hold the Rotary encoder for more than 2 seconds. The Speed Dial display appears. Press 7 (RETURN). The Telephone menu display appears. Press the 6 (SMS WRITE). The Standardized sentences are displayed.

  • Page 47: External Audio Processor (Optional)

    Pro Logic II, DTS and PCM modes.) Storing settings in the memory (page 52) (Storing all the settings and adjustments made on the IVA-D900R (not only the above settings/adjusts) in the memory) In case of combining the Automatic adjustments etc.

  • Page 48: Setting The Speakers

    Set MX Mode of the External Audio Processor Before performing the operations below, set MX (Media Xpander ) mode of the external audio processor to “AUTO.” Check that Defeat mode is off. Press SOURCE/POWER. The main menu is displayed. Press 4 (A.PROC). The A.PROC (Audio processor) list display appears.

  • Page 49: X-Over Adjustment

    Performing Time Correction Manually (TCR)/ Switching the Phase Because of the particular conditions inside the vehicle, there can be major differences in the distances between the various speakers and the listening position. It is possible to calculate the optimum correction values and eliminate the time error at the listening position yourself using this function.

  • Page 50: Graphic Equalizer Adjustments

    Press SOURCE/POWER. Repeat steps 6 to 8 to adjust other frequencies. The main menu is displayed. • When the speaker is set to the “OFF” mode, the graphic equalizer Press 4 (A.PROC). for that speaker cannot be set. Refer to “Setting the A.PROC (Audio processor) list display appears.

  • Page 51: Bass Comp. Setting

    Bass Focus The time difference between the front-rear/left-right speakers, can be adjusted a pair at a time. Audible time correction can be made from 0.10 ms to 20.00 ms in 201 steps (0 to 200). Check that Defeat mode is off. Press SOURCE/POWER.

  • Page 52: Setting Of Dolby 5.1Ch

    • Avoid stopping, pausing, switching the disc, cueing, fast- Press the Function button to select a speaker forwarding or switching the audio channel of this unit while frequency. making this adjustment. The setting is canceled if the Decode mode ∗1 OFF: When no speaker is connected.

  • Page 53: Adjusting The Speaker Levels

    Adjusting the DVD Level The volume (signal level) for Dolby Digital, Dolby PL II, DTS and PCM modes can be set. • Avoid stopping, pausing, switching the disc, cueing, fast- forwarding or switching the audio channel of this unit while making this adjustment.

  • Page 54: Using The Pro Logic Ii Mode

    • Avoid stopping, pausing, switching the disc, cueing, fast- Using the Pro Logic II Mode forwarding or switching the audio channel of this unit while making this adjustment. The setting is canceled if the Decode mode is switched. Pro Logic processing can be conducted on the music signals recorded •...

  • Page 55: Remote Control

    2 A.PROC Button Operating for the IVA-D900R Press the button to call the audio processor list. 3 , Button Set the mode selector switch to “AUDIO” to perform operations on Radio mode: Selects, in ascending order, stations the IVA-D900R.
  • Page 56 Button Point the remote control to the remote control sensor of Radio mode: SEEK (UP) Button the IVA-D900R, and press and hold for at least 2 seconds CD changer mode: to switch the remote control sensor. Press the button to advance to the To switch to the other remote control sensor, press REAR beginning of the next track.

  • Page 57: Operating The Dvd Player/Dvd Changer (Sold Separately)

    2 A.PROC Button Press the button to call the external audio processor - MUTE Button mode. Decreases the volume of IVA-D900R in a moment. Press the button again to cancel. Button Disc No. UP (Only for DVD changer) . VOLUME Button Adjusts the volume of the IVA-D900R.

  • Page 58: Operating The Navigation (Sold Separately)

    Set this switch to the “NAV.” side to operate a connected Alpine navigation system. Operating a sold separately TV monitor • To operate a separately sold Alpine TV monitor, press the mode change switch on the rear of the remote control unit. Operate while (Rear of the Remote Control) the transmission indicator is blinking.

  • Page 59: Battery Replacement

    Notes on Using the Remote Control Battery Replacement Applicable battery: Use two “AAA” sized dry batteries or equivalent. Point the remote control transmitter at the remote control sensor. Opening the battery cover. Push on the cover and slide it as indicated by the arrows then the cover will be removed.

  • Page 60: Information

    In addition, DVDs offer a variety of functions. Information • Multiple audio* (page 20) Movies can be recorded in up to eight languages. The desired language can be selected from the remote control unit. About DVDs • Subtitles function* (page 21) Movies can include subtitles in up to 32 languages.

  • Page 61: Terminology

    * To enjoy DTS surround sound you need the separately sold DTS digital audio processor (PXA-H900/PXA-H700). The DVD video software must also have a DTS sound track. The IVA-D900R has a built-in DTS 2-channel audio decoder. Analog audio outputs are available.

  • Page 62: List Of Language Codes

    List of Language Codes (For details, see page 29.) Abbreviation Code Language Abbreviation Code Language Abbreviation Code Language Afar 7369 Interlingue 8278 Kirundi 6565 6566 Abkhazian 7375 Inupiak 8279 Romanian 6570 Afrikaans 7378 Indonesian 8285 Russian 6577 Amharic 7383 Icelandic 8287 Kinyarwanda 6582...

  • Page 63: List Of Country Codes

    List of Country Codes (For details, see page 30.) Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 6568 Andorra 6877 Dominica 7573 Kiribati 6569 United Arab Emirates 6879 Dominican Republic 7577 Comoros 6570 Afghanistan 6890 Algeria 7578 Saint Kitts and Nevis 6967 Ecuador 7580...
  • Page 64 Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 8069 Peru 8374 Svalbard and Jan Mayen 8487 Taiwan, Province of China 8070 French Polynesia 8375 Slovakia 8490 Tanzania, United Republic of 8071 Papua New Guinea 8376 Sierra Leone 8565 Ukraine 8072 Philippines 8377...

  • Page 65: In Case Of Difficulty

    - Do not use a commercial available lens cleaner disc. Unclear picture display. Consult your nearest ALPINE dealer. • Fluorescent tube is exhausted. Disc playback sound skips without vibration. - Replace the fluorescent tube*.
  • Page 66 - Press c. After the error indication disappears, insert the disc again. If the above-mentioned solution does not solve the problem, consult your nearest ALPINE dealer. MP3 is not played back. • Writing error occurred. The CD format is not compatible.
  • Page 67 2) When the error indication remains after ejecting, press c again. If the error indication still does not turn off after pressing c for a few times, consult your Alpine dealer. (Displayed in the rear monitor) DISC ERROR • Scratched disc, contaminated disc/poor recording/disc incompatible with this unit - Press c.
  • Page 68 - Consult your Alpine dealer. Press the magazine eject button and pull out the magazine. Check the indication. Insert the magazine again. If the magazine cannot be pulled out, consult your Alpine dealer. • Magazine ejection not possible. - Press the magazine eject button. If the magazine does not eject, consult your Alpine dealer.

  • Page 69: Specifications

    GENERAL Specifications Power Requirement 14.4 V DC (11–16 V allowable) MONITOR SECTION Operating temperature +32°F to +113°F Screen Size 7.0" (0°C to + 45°C) 50 W × 4 LCD Type Transparent type TN LCD Maximum Power Output Operation System Low-Temperature p-si TFT active Output Voltage 2,000 mV/10k ohms matrix...

  • Page 70: Installation And Connections

    When connecting the IVA-D900R to the fuse box, make safety-related system), or tanks should NEVER be used for sure the fuse for the intended circuit of the IVA-D900R has the installations or ground connections. Using such parts could appropriate amperage. Failure to do so may result in damage to disable control of the vehicle and cause fire etc.

  • Page 71: Installation

    When your vehicle has the Bracket, mount the long hex Installation bolt onto the rear panel of the IVA-D900R and put the Rubber Cap on the hex bolt. If your vehicle does not have the Mounting Support, reinforce the monitor unit with the Installing the Monitor metal mounting strap (not supplied).
  • Page 72 Installing the Tuner Box Install the tuner on the floor with the supplied flange-head tapping screws (M4 x 14). Caution Do not block the unit’s fan or heat sink, thus Flange-head tapping screws preventing air circulation. If blocked, heat will (M4 x 14) (Included) accumulate inside the unit and may cause a fire.
  • Page 73 • The diagram and the fuse amperage shown above are in the case when IVA-D900R is used individually. • If the switched power (ignition) lead of the IVA-D900R is connected directly to the positive (+) post of the vehicle‘s battery, the IVA-D900R...

  • Page 74: Connections (Iva-D900R Wiring Diagram)

    Connections (IVA-D900R Wiring Diagram) Antenna IVA-D900R <Monitor> ILLM To remote control To the instrument cluster Nothing connects illumination lead interface box (Orange) with this line. " BATTERY BATT (Yellow) (Yellow) (Black) (Black) REMOTE OUT AUX1 (White/Brown) REMOTE OUT AUX2 IVA-D900R...
  • Page 75 • Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.

  • Page 76: System Example

    • * When connecting with PXA-H510 : - Connect the fiber digital input terminal to the DVD. - IVA-D900R and DVA-5205P cannot be connected simultaneously when fiber digital is in use. • When the NVE-N055PS is connected for the Navigation System, use the RGB conversion cable KCE-030N (Sold separately).
  • Page 77 1 RGB Cable (Included Navigation) 2 Remote IN/OUT Terminal 3 RGB Input Terminal Connect this to the RGB output terminal of the Navigation System. 4 System Switch When connecting an equalizer or divider using Ai-NET feature, place this switch in the EQ/DIV position. When no device is connected, leave the switch in the NORM position.
  • Page 78 When Connecting External Equipment To Audio Input terminal IVA-D900R Rear monitor 1 EQ/DIV Tuner BOX (Sold Separately) To Video Input terminal NORM SUB W. PREOUT REAR FRONT To Video Input terminal POWER SUPPLY Ai-NET Rear monitor 2 REMOTE IN/OUT VIDEO...
  • Page 79 CD-TEXT. Der CHA-1214 ist ein Ai-NET-Modell für 12 CDs. Der M-Bus-kompatible CHM-S630 ist ein superkompakter Wechsler für 6 CDs mit CD-R/RW-Wiedergabefunktion. Changeurs de CD Alpine : vous avez le choix! Plus de sélections musicales, plus de souplesse, plus de confort.
  • Page 80 Sollten Sie diese Karte et en l’envoyant à Alpine, vous acceptez voluntario. Si Vd. nos la remite, será it to Alpine, your data will be tabulated vervollständigen, so werden die Daten für que ces informations soient utilisées par...
  • Page 81 J’accepte les termes de cette carte d’information produit Alpine. possiede? 1. Alpine → (No. Modello) Estoy conforme con los términos de la tarjeta de información sobre producto de Alpine. 2. Altro → Nome marca Accetto i termini della scheda informazioni prodotti Alpine.
