Part Identification Chart - Pro-Form XP542S User Manual

Key No. Qty. Description
101 1 Console Base
102 1 Optic Disk
103 8 Ground Screw/Choke Screw
104 1 Key Clip
105 2 Fan Screw
106 1 Fan
107 1 Console
108 44 Screw
109 1 Left Tray
110 1 Console Support
111 1 Right Tray
112 1 iFIT.com Wire
113 1 Hood
114 2 Motor Bracket Bolt
115 1 Photo Switch Screw
116 1 Left Handrail

PART IDENTIFICATION CHART

Use the drawings below to identify small parts used during assembly. Note: If a part is not in the parts bag,
check to see if it has been preattached to one of the parts to be assembled.
Internal Star
Washer (77)–4
Key No. Qty.
117
118
119
#
#
#
#
#
#
#
#
*Includes all parts shown in the box
#These parts are not illustrated
If a part is missing, call toll-free 1-888-533-1333.
Latch Screw (46)–2
Console Bolt (76)–4
27
Description
1 Left Top Handgrip
1 Photo Switch Nut
1 Left Bottom Handgrip
1 10" Blue Wire, 2F
1 10" Blue Wire, M/F
1 4" Blue Wire, M/F
1 8" Green Wire, 2 Ring
1 4" Green Wire, M/Ring
1 14" Red Wire, M/F
1 12" Black Wire, M/F
1 User's Manual
1" Tek Screw (40)–6
