Icom IC-F3 Service Manual page 28

6-2 IC-F4/F4S
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1130007610 S.IC
IC2 1110003490 S.IC
IC3 1110003780 S.IC
IC4 1130008090 S.IC
IC5 1110001810 S.IC
IC6 1180001080 S.IC
IC7 1140005620 S.IC
1130008670 S.IC
IC8 1140006460 S.IC
1140008380 S.IC
IC10 1110003690 S.IC
IC11 1110003500 S.IC
Q1 1560000950 S.FET
Q2 1560000960 S.FET
Q3 1530002620 S.TRANSISTOR
Q4 1530003310 S.TRANSISTOR
Q5 1530003310 S.TRANSISTOR
Q6 1530003310 S.TRANSISTOR
Q7 1530002920 S.TRANSISTOR
Q8 1530002920 S.TRANSISTOR
Q9 1590002160 S.TRANSISTOR
Q11 1530002060 S.TRANSISTOR
Q12 1580000720 S.FET
Q13 1580000680 S.FET
Q15 1520000460 S.TRANSISTOR
Q16 1590001190 S.TRANSISTOR
Q17 1590002530 S.TRANSISTOR
Q18 1520000460 S.TRANSISTOR
Q19 1590001190 S.TRANSISTOR
Q20 1510000580 S.TRANSISTOR
Q21 1510000580 S.TRANSISTOR
Q22 1510000580 S.TRANSISTOR
Q23 1530002060 S.TRANSISTOR
Q25 1530000160 S.TRANSISTOR
Q26 1590000430 S.TRANSISTOR
Q27 1520000460 S.TRANSISTOR
Q28 1530002060 S.TRANSISTOR
Q29 1590001770 S.TRANSISTOR
Q31 1590000660 S.TRANSISTOR
Q33 1590001650 S.TRANSISTOR
Q34 1560000540 S.FET
Q35 1530002060 S.TRANSISTOR
Q36 1530002060 S.TRANSISTOR
Q37 1590000720 S.TRANSISTOR
Q38 1590000430 S.TRANSISTOR
Q400 1530002600 S.TRANSISTOR
Q401 1590001400 S.TRANSISTOR
Q402 1590000430 S.TRANSISTOR
Q403 1530003310 S.TRANSISTOR
Q404 1530002850 S.TRANSISTOR
Q405 1590000430 S.TRANSISTOR
D1 1790000620 S.DIODE
D2 1790000490 S.DIODE
D3 1790000620 S.DIODE
D4 1790000620 S.DIODE
D5 1720000370 S.VARICAP
D7 1720000670 S.VARICAP
D8 1790000620 S.DIODE
D10 1720000370 S.VARICAP
D11 1720000370 S.VARICAP
D12 1720000370 S.VARICAP
D15 1790001280 S.DIODE
D16 1790001200 S.DIODE
D17 1790001200 S.DIODE
D24 1750000130 S.DIODE
D25 1790000670 S.DIODE
D26 1160000060 S.DIODE
D27 1750000130 S.DIODE
D33 1790001280 S.DIODE
D400 1790001210 S.DIODE
D401 1720000370 S.VARICAP
D402 1790001210 S.DIODE
D403 1720000370 S.VARICAP
D404 1720000520 S.VARICAP
D405 1720000360 S.DIODE
[L]: L-band, [ML]: ML-band, [MH]: MH-band, [H1]: H1-band, [H2]: H2-band
N: N-type, W: W-type, e: ETS/CEPT version, u: EIA/TIA version
DESCRIPTION
µPD3140GS-E1 (DS8)
TA31136FN (D,EL)
NJM2902V-TE1
BU4066BCFV-E1
TA7368F (TP1)
S-81250PG-PD-T1
X25080SI-2.7T6 [16 ch]
25LC160T-I/SN [2-BANK]
HD6433875A40H [16 ch]
HD6433875B26H [2-BANK]
M62354GP 75EC
S-80742SL-A6-T1
2SK2595AXTB
2SK2596BXTL
2SC3585 R44-T2B
2SC5107-O (TE85R)
2SC5107-O (TE85R)
2SC5107-O (TE85R)
2SC4226-T2 R25
2SC4226-T2 R25
XP6401-(TX)
2SC4081 T107 R
3SK239AXRTL
3SK241-R(TX)
2SB1132 T100 R
XP6501-(TX).AB
UN911H (TX)
2SB1132 T100 R
XP6501-(TX).AB
2SA1362-GR (TE85R)
2SA1362-GR (TE85R)
2SA1362-GR (TE85R)
2SC4081 T107 R
2SC2712-Y (TE85RTEM)
DTC144EUA T106
2SB1132 T100 R
2SC4081 T107 R
XP1213 (TX)
DTC144TU T107
XP4601 (TX)
2SK880-Y (TE85R)
2SC4081 T107 R
2SC4081 T107 R
DTA144EUA T106
DTC144EUA T106
2SC4215-O (TE85R)
XP1214 (TX)
DTC144EUA T106
2SC5107-O (TE85R)
2SC4116-BL (TE85R)
DTC144EUA T106
MA77 (TX)
HSM88AS-TR
MA77 (TX)
MA77 (TX)
HVU350TRF
HVU17TRF
MA77 (TX)
HVU350TRF
HVU350TRF
HVU350TRF
MA111 (TX)
MA6S121 (TX)
MA6S121 (TX)
DA204U T107
SB07-03C-TB
DAN202U T107
DA204U T107
MA111 (TX) F4 only
1SS375-TL
HVU350TRF
1SS375-TL
HVU350TRF
1T365-01-T8A
HSU88TRF
[MAIN UNIT]
REF ORDER
NO. NO.
D406 1790000620 S.DIODE
FI1 2010002100 XTAL
2010002120 XTAL
FI2 2020001410 CERAMIC
2020001270 CERAMIC
X1 6050009991 XTAL
X2 6050008840 S.XTAL
X3 6070000210 S.DISCRIMINATOR
L1 6200005780 S.COIL
6200005800 S.COIL
L2 6200005770 S.COIL
6200005780 S.COIL
6200005800 S.COIL
L3 6200005770 S.COIL
6200005780 S.COIL
6200005800 S.COIL
L5 6110003230 S.COIL
L6 6200006780 S.COIL
6200006770 S.COIL
L7 6200005680 S.COIL
6200005670 S.COIL
L8 6200005400 S.COIL
6200005380 S.COIL
L9 6200005400 S.COIL
L11 6200003690 S.COIL
6200004110 S.COIL
L12 6200003550 S.COIL
L13 6200003960 S.COIL
L14 6200002450 S.COIL
L15 6200002100 S.COIL
L17 6200002320 S.COIL
L18 6200002320 S.COIL
L19 6200002320 S.COIL
L20 6200004480 S.COIL
L21 6200005460 S.COIL
6200005430 S.COIL
L22 6200004660 S.COIL
L24 6200004480 S.COIL
L25 6200004480 S.COIL
L26 6200003590 S.COIL
L27 6200003590 S.COIL
L400 6200003540 S.COIL
6200005430 S.COIL
L401 6200002100 S.COIL
L402 6200002320 S.COIL
L403 6200004780 S.COIL
L404 6200004780 S.COIL
L405 6200004110 S.COIL
L406 6200004780 S.COIL
L407 6200003550 S.COIL
L409 6200003550 S.COIL
L410 6200003960 S.COIL
L411 6200005400 S.COIL
L412 6200003960 S.COIL
L413 6200005400 S.COIL
6200005370 S.COIL
L414 6200003540 S.COIL
L415 6200007220 S.COIL
L416 6200003540 S.COIL
L417 6200005400 S.COIL
6200005390 S.COIL
6 - 6
DESCRIPTION
MA77 (TX)
N
FL-267 (46.35 MHz)
W
FL-271 (46.35 MHz)
N
CFWM450G
W
CFWM450E
CR-576A (15.3 MHz)
CR-463 (6.8 MHz)
CDBCA450CX24
33CS-Y655LY-03K=P3
[L], [ML], [MH]
33CS-Y655LY-02M=P3
[H1], [H2]
33CS-Y655LY-04K=P3
[L], [ML]
33CS-Y655LY-03K=P3
[MH]
33CS-Y655LY-02M=P3
[H1], [H2]
33CS-Y655LY-04K=P3
[L], [ML]
33CS-Y655LY-03K=P3
[MH]
33CS-Y655LY-02M=P3
[H1], [H2]
LA-515
ELJRE 1N8Z-F [L]
ELJRE 1N5Z-F other
ELJRE 15NG-F [L]
ELJRE 12NG-F other
LL1608-F27NJ [L], [ML], [MH]
LL1608-F18NJ [H1], [H2]
LL1608-F27NJ
MC152-E558ANA-100051=P3
[L], [ML]
MC152-E558ANA-100050
[MH], [H1], [H2]
MLF1608A 4R7K-T
MLF1608A 1R0K-T
LL2012-F15NK
LQN 1A 17NJ04
LQN 1A 8N8J04
LQN 1A 8N8J04
LQN 1A 8N8J04
MLF1608D R82K-T
LL1608-F82NJ [L]
LL1608-F47NJ other
MLF1608A 1R8K-T
MLF1608D R82K-T
MLF1608D R82K-T
EXCCL3225U1
EXCCL3225U1
MLF1608D R22K-T [L], [ML]
LL1608-F47NJ [MH], [H1], [H2]
LQN 1A 17NJ04
LQN 1A 8N8J04
MLF1608A 1R5K-T
MLF1608A 1R5K-T
MC152-E558ANA-100050
MLF1608A 1R5K-T
MLF1608A 4R7K-T
MLF1608A 4R7K-T
MLF1608A 1R0K-T
LL1608-F27NJ
MLF1608A 1R0K-T
LL1608-F27NJ [L]
LL1608-F15NJ [ML]
MLF1608D R22K-T
EXCCL4532U1
MLF1608D R22K-T
LL1608-F27NJ [MH]
LL1608-F22NJ [H1], [H2]
S.=Surface mount
