Icom IC-F3 Service Manual page 27

[MAIN UNIT]
REF ORDER
NO. NO.
J2 6450001680 CONNECTOR
J3 6450001690 CONNECTOR
J4 6450000870 CONNECTOR
J5 6510018430 S.CONNECTOR
J6 6510007080 CONNECTOR
J7 6910010850 CONNECTOR
DS1 5030001460 LCD
DS2 5010000160 S.LED
DS3 5010000160 S.LED
DS4 5040002190 S.LED
MC1 7700002160 MICROPHONE
S1 2230000900 S.SWITCH
SP1 2510000960 SPEAKER
W1 7030003860 S.JUMPER
W2 7030003860 S.JUMPER
W7 7030003860 S.JUMPER
W8 7030003860 S.JUMPER
W10 7030003860 S.JUMPER
WS1 8600035801 M.OTHER
EP1 0910048456 PCB
EP2 8930042590 LCD CONTACT
[VR BOARD]
REF ORDER
NO. NO.
R1 7210002950 VARIABLE
EP1 0910048462 PCB
DESCRIPTION
HSJ1122-010010
HSJ1456-01-220
HEC2711-01-020
AXN330C038P
PI28A-02M
IMSA-9230B-1-05Z080-T
LM-1462B
LNJ310M6URA
LNJ310M6URA
LNJ808R8ERA
KUC3523-040245
JPM1990-2013R
K036NA500-26
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V [2-BANK]
ERJ3GE JPW V [16 ch]
ERJ3GE JPW V
FX1922 P01MA-1
B 4929F
SRCN-1922-SP-N-W
DESCRIPTION
RV-312 (RK0971110)
B 4930B
S.=Surface mount
6 - 5
