1.3. Description and connections
This equipment let you enjoy your audio and video sets in different rooms than real situation. With high quality of
transmitted signals (FM modulation) and stereo sound you'll get high quality signals where you place the receiver. Is
possible to buy only the receiver (with UHF modulator or without) to have one emitter with several receivers (in this case
the signals of remote control will come from only one receiver).
Front view
Receiver Connections
1.4. Accessories and installation examples
Reserved of technical modifications and/or errors
User's Manual · MULTILINK R LT
Power LED and channel
display.
IR remote control window
LEFT AUDIO (white)
RIGHT AUDIO (red)
VIDEO (yellow)
Connection of power
adapter (9VDC). Use
only the provided one.
Switch on
Transmission channel
selector
