Socket Bluetooth GPS Nav Kit Quick Start Manual page 4

Power Jack
The power jack lets you connect to either a DC (included) or AC power
charger to recharge the internal battery. AC chargers are available
separately from Socket at www.socketcom.com/shop/default.asp.
The AC and DC adapters from most recent Pocket PCs from Casio,
Compaq, Dell, Fujitsu, HP and Toshiba are also compatible. Please note
that the DC adapter rating is 5V, 1A, positive pole center.
Bluetooth
status LED status LED
Power
switch
Bluetooth Status LED (Blue)
Blinking — Bluetooth radio is on and transmitting.
GPS Status LED (Green)
Blinking — GPS position is fixed.
Steady light — GPS position not fixed.
Battery Status LED (Red/Yellow)
Red — Running on battery power, which will be used up within
approximately five minutes. Charge immediately.
Yellow — Connected to power charger. Battery is only partially full.
LED off — If connected to power charger, battery is fully charged.
If not connected to power charger, device is running on battery
power, and battery has adequate power supply.
4
GPS
(blue) (green)
Battery
status LED
(red/yellow)
Power
jack
