Ryobi RLT2500QF Operator's Manual

STOPPING

Install the spring over the
Stop
To stop the motor, simply Switch spindle. Insert each end of
depress the stop switch the cutting line through the
until the motor comes to a eyelets in the cutting head
complete stop. Fig 13 Assembly and lower the
spool while feeding the line
ADJUSTING TRIMMING as illustrated in Fig 20.
Fig 13
LINE LENGTH
Once the spool is in place,
Your trimmer is equipped
apply pressure on the spool
with a Bump Feed Cutting
compressing the spring.
Head that allows the oper-
Pull each end of the line
ator to release more trim-
sharply to unlock the line
ming line without stopping
from the slots. Continue to
the motor.
apply pressure to the spool
To release additional line,
until the knob can be
lightly tap the trimming
threaded clockwise onto the
head on the ground while
Fig 14 spindle. Tighten the knob
operating the trimmer at
securely. Fig 21.
high speed. Fig 14
Fig 15

QUICK FIT SYSTEM

If excess line is released,
Your Ryobi trimmer is
a blade in the guard will
equipped with a Quick Fit
automatically cut the line
Blade
System, which enables
to the proper length. Fig 15
optional attachments to be
NOTE: Always keep the
connected to your trimmer.
trimming line fully extend-
Ask your Ryobi retailer for a
ed. Line release becomes
list of available optional attach-
more difficult as cutting line
ments.
becomes shorter.
To replace the cutting head
CAUTION: Do not remove or alter the line cut-
with an optional attachment,
ting blade on the guard. Excessive line length
loosen the knob anticlock-
will cause clutch to overheat and may result in
wise. Fig 22
serious personal injury.
Depress the release button
and remove the cutting head
REPLACING
shaft. Fig 23
EXHAUSTED CUT-
Depress release button, and
TING LINE
insert shaft of optional add on
Remove bump head
attachment. Fig 24
knob by turning anti-
When the shaft clicks into
clockwise. Remove place, tighten the knob.
spool and spring from
Fig 16 AIR FILTER It is recommended that the air filter is cleaned
spindle. Fig 16.
on a regular basis.To clean the air filter, depress the air fil-
ter cover latch and remove the cover. Fig 25.
Fig 17
Cut 2 x 2.2m lengths of Remove and wash the filter with soap and water.
cutting line and insert one Allow to completely air dry before replacing the filter.
After replacing the filter secure the air filter cover.
end of each line into the
two spool holes as illus-
trated in Fig 17 .
Wind cutting lines
Fig 18
clockwise as illustrated in
Fig 18, with each line sepa-
rated by the spool divider.
STORAGE If the trimmer will be stored for an extended
Wind to within
period of time, use the following storage procedure:
15 cm of the end of the
1. Drain all fuel from the fuel tank into a container.
line.
2. Start the motor and allow it to run until it stalls. This
ensures that all the fuel has been drained from the carbure-
tor.
Lock each end of the cut-
Spool
3. Allow the motor to cool. Remove the spark plug and put
ting line into the slots
Divider approximately 30ml of any high quality oil or 2 stroke oil
on opposite sides of the
into the cylinder. Pull the starter rope slowly to distribute
spool as illustrated in
the oil. Reinstall the spark plug. Leave the spark plug wire
Fig 19 off for storage.
Slots
Fig 19
4. Inspect for any damaged or loose parts. Repair or replace
any damaged parts and tighten loose screws, nuts or bolts.
Page 5
Fig 20
Subject to the guarantee condition below, this Ryobi tool
(hereinafter called "the product") is guaranteed by Ryobi
Fig 21
(hereinafter called "the Company") to be free from
defects in material or workmanship for a period of 12
months from the date of original purchase covering both
parts and labour. Under the terms of this guarantee, the
repair or replacement of any part shall be the opinion of
the Company or its authorised agent. Should service
become necessary during the guarantee period, the
owner should contact the Authorised Ryobi Retailer
from whom the Product was purchased, or the nearest
Company Branch Office. In order to obtain guarantee
Fig 22
service, the owner must present the sales docket and
Guarantee Certificate to confirm date of purchase. This
product is sold by the dealer or agent as principal and
the dealer has no authority from the Company to give
any additional guarantee on the Company's behalf
except as herein contained or herein referred to.
Guarantee Conditions
Release Button Fig 23
This guarantee only applies provided that the Product
has been used in accordance with the manufacturer's
recommendations under normal use and reasonable
care (in the opinion of the Company) and such guarantee
does not cover damage, malfunction or failure resulting
from misuse, neglect, abuse, or used for a purpose for
Fig 24
MELBOURNE: 960 Stud Road, Rowville, Vic, 3178,
Phone: (03) 9764 8655
HOBART: All Enquiries Phone: 1300 361 505
BRISBANE: All Enquiries Phone: 1300 361 505
Fig 25
SHOULD BE RETAINED BY THE CUSTOMER AT ALL TIMES
For your record and to assist in establishing date of purchase (necessary for in-guarantee service)
please keep your purchase docket and this form completed with the following particulars.
PURCHASED FROM _______________________________________________________
ADDRESS OF DEALER _____________________________________________________
DATE _________________MODEL NO ___________SERIAL NO ___________________
Present This Form With Your Purchase Docket When Guarantee Service Is Required
RYOBI TECHNOLOGIES AUSTRALIA PTY. LTD.
GUARANTEE
which it was not-designed or is not suited; and no
repairs, alterations or modifications have been attempt-
ed by other than an Authorised Service Agent. This guar-
antee will not apply if the tool is damaged by accident or
if repairs arise from normal wear and tear.
The Company accepts no additional liability pursuant to
this guarantee for the costs of travelling or transporta-
tion of the Product or parts to and from the service deal-
er or agent - which costs are not included in this guar-
antee.
Certain legislation, including the Trade Practices Act,
1974 (as amended) and other state and territorial laws
give rights to the buyer and impose liability on the sell-
er in certain circumstances. Nothing herein shall have
the effect of excluding, restricting or modifying any con-
dition, guarantee, right or liability imposed, to the extent
only that such exclusion, restriction or modification
would render any term herein void.
RYOBI TECHNOLOGIES AUSTRALIA PTY. LTD.
A.C.N. 002 277 509 Incorporated in N.S.W.
SYDNEY: 359-361 Horsley Road, Milperra, N.S.W.
2214, Phone: (02) 9772 2444
email: info@ryobi.aust.com
PERTH: 33-35 Sorbonne Crescent, Canning Vale,
WA, 6155, Phone: (08) 9455 7775
ADELAIDE: All Enquiries Phone: 1300 361 505
TOWNSVILLE: All Enquiries Phone: 1300 361 505
RYOBI TECHNOLOGIES NEW ZEALAND LIMITED
Auckland: 503 Mt Wellington Highway,
Mt Wellington, NZ, Phone: (09) 573 0230
email: info@ryobi.co.nz
THIS GUARANTEE FORM
OWNER'S OPERATING MANUAL
TRIMMERS
RLT2500QF
RYT2500QF
RST2500QF

SPECIFICATION

RLT2500QF RYT2500QF
Motor 25cc 2 Stroke 25cc 2 Stroke
Ignition Electronic Electronic
Carburetor Diaphragm, all position Diaphragm, all position
Cutting Head Twin line bump feed Twin line bump feed
Cutting Line 2.5 mm 2.5 mm
Width Of Cut 43 cm 46 cm
Steel Blade
Weight 4.9 kg 5.3 kg
THANK YOU FOR BUYING A RYOBI TRIMMER.
Your new Trimmer has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation,
and operator safety. Properly cared for, it will give you years of rugged, trouble free performance.
CAUTION: Carefully read through this entire owner's manual before using your new Trimmer.
Pay close attention to the Rules for Safe Operation, Warnings and Cautions. If you use your Trimmer properly and
only for what it is intended, you will enjoy years of safe, reliable service.
Thank You again for buying Ryobi tools.
RST2500QF
25cc 2 Stroke
Electronic
Diaphragm, all position
Twin line bump feed
2.5 mm
46 cm
Yes
6.0 kg
