The Sharp Shooter II is a professional
metal detector. The concepts and terminology
can be quite unfamiliar if you are new to the hobby.
To understand it quickly and to get the most enjoyment
possible from your detector, we strongly recommend
that you:
1) Turn the Sensitivity knob to a low setting if you get false signals. A
little practice is required to understand when and how you can use the
sensitivity at or near 100%.
2) Do not use indoors. This detector is for outdoor use only. Many
household appliances emit electromagnetic energy, which can
interfere with the detector. If conducting an indoor demonstration,
turn the sensitivity down and keep the searchcoil away from all floors,
walls and metal objects.
3) Do not test by placing coins on the floor. Most floors contain metal.
4) Read this manual.
Most importantly, review the Summary of Operating Modes.
5) Sweep the searchcoil from side-to-side. Coil motion is required in the
motion modes to detect metal.
6) Use 9volt ALKALINE batteries only.
Do not use Heavy Duty batteries.
Do not use normal Zinc-Carbon batteries.
7) Operating Frequency: 6.5 kHz
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sharp Shooter II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bounty Hunter Sharp Shooter II

  • Page 1 OWNER’S MANUAL The Sharp Shooter II is a professional metal detector. The concepts and terminology can be quite unfamiliar if you are new to the hobby. To understand it quickly and to get the most enjoyment possible from your detector, we strongly recommend that you: 1) Turn the Sensitivity knob to a low setting if you get false signals.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS TERMINOLOGY .......3 ASSEMBLY ........4-5 BATTERIES .
  • Page 3: Terminology

    TERMINOLOGY The following terms are used throughout the manual, and are standard terminology among detectorists. ELIMINATION Reference to a metal being "eliminated" means that the detector will not emit a tone, nor light up an LCD indicator, when a specified object passes through the coil’s detection field.
  • Page 4: Assembly

    ASSEMBLY Adjusting the Armrest The armrest may be moved forward backwards removing the single screw and nut, and then repositioning the 2-piece armrest. Users with shorter arms may find the armrest more comfortable in the forward position. In order to move the armrest backwards, plastic plug...
  • Page 5 ASSEMBLY Assembling your Sharp Shooter II Metal Detector is easy and requires no tools. Just follow these steps: Using the supplied bolt and knurled knob, attach the searchcoil to the lower stem. Press the button on the upper end of the lower stem and slide the lower stem into the upper stem.
  • Page 6: Batteries

    The Low Battery indicator light will come on and stay on whenever the batteries need replacing. It should flash momentarily when the Power Switch is turned on. IMPORTANT: Your Sharp Shooter II metal detector requires two 9-Volt ALKALINE batteries. Follow these steps to install the batteries.
  • Page 7: Quick-Start Demo

    QUICK-START DEMO I. SUPPLIES NEEDED • A Nail • Nickel • A small piece of aluminum foil • Dime • A large screwdriver or other large iron object • Quarter • A zinc penny (dated after 1982) II. POSITION THE DETECTOR a.
  • Page 8: Basic Operation

    BASIC OPERATION TURN THE DETECTOR ON Go outdoors to your desired treasure-hunting location. Click the left knob to the on position. Three tones will sound. The detector automatically enters the DISCRMINATION Mode. NO-MOTION ALL METAL MODE To operate in this mode: •...
  • Page 9 BASIC OPERATION APPROXIMATE DISCRIMINATION Mode - continued • Turn the right knob, DISCRIMINATION, DISCRIMINATION to eliminate additional unwanted POSITIONS items from detection as illustrated to right. These positions approximate; objects are found in many shapes and sizes. The detector will emit one of three tones, depending on the type of metal detected.
  • Page 10: Summary Of Operating Modes

    SUMMARY OF OPERATING MODES I. NO-MOTION ALL METAL MODE • Deepest Seeking Mode • No motion is required • All metals will be detected • One tone only • Manual Ground Balance: User must tune and retune with the Retune button. To Operate: 1) Press All Metal button.
  • Page 11: Lcd Target Display

    LCD TARGET DISPLAY - motion modes only Please refer to the display on your detector and reference the TARGET-ID FOIL: Aluminum foil, such as a gum categories below applicable to your wrapper, will register as foil. A small model (not all detectors include all of broken piece of pull tab may also these categories).
  • Page 12: Indicators & Sensitivity Adjustment

    INDICATORS & SENSITIVITY ADJUSTMENT BATTERY INDICATOR: EMI are power lines, both suspended buried, broadcasting The LOW BATT indicator will flash as antennas. Machinery, when the unit is powered on. If the operation, can also produce EMI. indicator comes on and stays on, replace the batteries.
  • Page 13: Audio Target Identification

    AUDIO TARGET-ID -Motion modes only In the DISC, NOTCH or AUTONOTCH PULL TABS: Modes, the detector emits three Pull tabs are the most bothersome distinct tones, which classify metal trash items for detectorist. Most will objects into categories induce a medium tone. Most will be eliminated automatically in the AUTO IRON &...
  • Page 14 IN THE FIELD TECHNIQUES - Motion modes PINPOINTING COIL MOVEMENT Accurate pinpointing takes practice When swinging the coil, be and is best accomplished by careful to keep it level with the “X-ing” the target area. ground about one inch from the surface.
  • Page 15: In The Field Techniques Motion Modes

    IN THE FIELD TECHNIQUES - motion modes Swing searchcoil slowly, rather than a silver or copper object. overlapping each sweep as you If the tone changes at different move forward. It is important to angles, you may have encountered sweep the coil at a consistent speed multiple objects.
  • Page 16: No-Motion Mode

    IN THE FIELD TECHNIQUES - No-motion mode In the No-Motion All Metal Mode, coil sweep technique is not important. Rather, user retuning is critical. The detector does not automatically adjust to changing ground and environmental conditions; the operator is required to make the adjustment. If the detector sounds a constant tone over all areas of the ground, retune the detector by pressing the Retune button.
  • Page 17: Metal Detecting Applications

    OTHER APPLICATIONS: Use your Sharp Shooter II to find property markers, machine parts, and lost keys. Keep your detector in ALL METAL Mode for these tasks. Gold prospecting also requires an ALL METAL Mode.
  • Page 18: Troubleshooting Guide

    TROUBLESHOOTING TROUBLESHOOTING GUIDE SYMPTOM CAUSE SOLUTION Detector chatters • Using detector • Use detector or beeps erratically indoors outdoors only • Using detector near • Move away power lines from power lines • Using 2 detectors in • Keep 2 detectors close proximity at least 30’...
  • Page 19: Warranty

    All rights reserved, including the right to reproduce this book, or parts thereof, in any form, except for the inclusion of brief quotations in a review. Published by First Texas Products, L.L.C. Bounty Hunter® and Pioneer® are registered trademarks of First Texas Products, L.L.C. www.detecting.com First Texas Products, LLC...
  • Page 20: Accessories

    ® Pouch with 2 large pockets & 9” heavy duty digging tool. TP-KIT-W Stereo Headphones Use with Bounty Hunter metal detectors. Lightweight and adjustable with true stereo sound, adjustable volume, 1/4 jack with 1/8 adaptor, 4’ cable. HEAD-W Pin Pointer Pinpoints the exact location of buried metal objects.
