  • Page 1 POINT OF SALE SIMPLIFIED ION Short Range Barcode Scanner User’s Guide...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 System Information 1.1 About this manual 1.2 How to set up the parameter 1.3 How to set up the parameter - II Chapter 2 System Setup 2.1 Interface selection 2.1.1 Keyboard emulation parameters setting 2.1.2 RS-232 communication setting 2.2 Scanning mode selection 2.3 Beeper tone selection 2.4 String Options (Prefix &...

  • Page 3: Chapter 1 System Information

    Chapter System Informa on 1.1 About this manual This User's Guide provides detailed programming instruc ons. Barcode scanners are factory programmed for the most common communica on se ngs. If you need to change these se ngs, programming is accomplished by scanning the bar codes in this guide.

  • Page 4: How To Set Up The Parameter

    1.3 How to set up the parameter - II Generally, you will only need to scan one barcode for most parameters. You will hear two beeps when you successfully set the new values. In some cases, when using special parameters you may need to read more than one barcode.

  • Page 5: Chapter 2 System Setup

    Chapter 2 System setup 2.1 Interface selec on The scanner is designed to switch easily from interfaces. No configuration is required for USB interface. Simply plug the scanner in and you are ready to scan. Start configura on End configura on ITEM OPTION KEYBOARD...

  • Page 6: Keyboard Emulation Parameters Setting

    2.1.1 Keyboard emulation parameters setting Start configuration End configuration ITEM OPTION *IBM AT IBM XT IBM PS/2 30-80 Device Selection for keyboard IBM 5550 Interface PS/2 25，30 NEC 9801 Reserved 1 Reserved 2 - 6 -...
  • Page 7 Start configuration End configuration ITEM OPTION * USA ITALIAN SPANISH FRENCH Language for Keyboard Interface GERMAN JAPANESE Multi-Language Support Reserved 1 - 7 -...
  • Page 8 Start configura on End configura on ITEM OPTION * Disable Func on Key Enable Emulate External Keyboard * Disable Enable * Disable ALT Mode Enable NOTE : Emulate External Keyboard Scan the “Enable” barcode if you do not have an external keyboard. After scanning the Enable barcode, you will need to restart your computer.
  • Page 9 Start configuration End configuration ITEM OPTION * Disable Caps Lock Enable * Disable Num Lock Enable Inter Character Delay (Default：00) Ref: Appendix（00—64H） - 9 -...
  • Page 10 Start configuration End configuration ITEM OPTION None * CR Terminator CR + LF Block transmission delay (Default：00) Ref: Appendix（00—0AH） Keyboard Speed (Default 00: high clock rate) Ref: Appendix（00—08H） - 10 -...

  • Page 11: Rs-232 Communication Setting

    2.1.2 RS-232 communication setting Start configuration End configuration ITEM OPTION 1200bps 2400bps 4800bps Baud Rate * 9600bps 19200bps 38400bps 7 Bits Data Bits * 8 Bits - 11 -...
  • Page 12 Start configuration End configuration ITEM OPTION * 1 Stop Bits Stop Bits 2 Stop Bits * NONE Parity EVEN Mark Space - 12 -...
  • Page 13 Start configura on End configura on ITEM OPTION Inter-character delay (Default 00) Ref: Appendix 00—64H Block transmission delay (Default 00) Ref: Appendix (00-0AH) Response delay (Default 00) Ref: Appendix (00-0AH) * None RTS/CTS Handshaking ACK/NAK Xon/Xoff - 13 -...
  • Page 14 Start configuration End configuration ITEM OPTION None * CR+LF Terminator For RS-232 STX/ETX - 14 -...
  • Page 15 Start configuration End configuration ITEM OPTION * None RTS/CTS Handshaking ACK/NAK Xon/Xoff - 15 -...

  • Page 16: Scanning Mode Selection

    2.2 Scanning mode selection Start configuration End configuration ITEM OPTION * Trigger On/Good Read Off Trigger On/Off Continuous/Trigger Off Continuous/Testing Reading Mode Continuous/Trigger on Continuous /Auto power on Flash Flash / Auto Power On - 16 -...

  • Page 17: Beeper Tone Selection

    2.3 Beeper tone selection Start configuration End configuration ITEM OPTION Beep Tone (Default：09H) Ref: Appendix (00-10H) Beep Sound Duration (Default：05H) Ref: Appendix (00-10H) * Enable Power On Beeper Disable * ON Beeper - 17 -...

  • Page 18: String Options (Prefix & Suffix)

    2.4 String Op ons (Prefix & Suffix) This sec on describes the altera ons which can be made to the format of the transmi ed data string. A prefix and suffix, 10 characters maximum, may be included in front of or at the end of a scanned barcode. Format {Prefix} {Code ID} {Bar Code} {Suffix} How to set up a prefix?

  • Page 19: Setup Insertion

    Setup Insertion This section describes how to setup the insertion of output. G1 Insertion G1Character Insertion Group Character Position Selection (01) G2 Insertion G2 Character Insertion Group Character Position Selection (02) Insertion Group Insertion Group Selection (01) Selection (02) Insertion Groups (01) (02) can be applied to many di erent barcode symbologies. UPC-A Code 128 UPC-E...
  • Page 20 Example: To insert character “A” before the third digit(3) Final Output will be: 12A3456789 How to set up a character you want to insert Scan Start Configura on barcode Scan “G1 Inser on character” Scan “4” and “1” from FULL ASCII Table Scan Confirm configura on barcode Scan End configura on barcode How to set up posi on you wish to place the character...
  • Page 21 Start configuration End configuration Confirm configuration ITEM OPTION Preamble (Default：00) Ref: Appendix Postamble (Default：00) Ref: Appendix G1 Insertion character (Default：00) Ref: Appendix G2 Insertion character (Default：00) Ref: Appendix G1 Character Position to be inserted (Default：00) Ref: Appendix G2 Character Position to be inserted (Default：00) Ref: Appendix - 21 -...
  • Page 22 Start configuration End configuration ITEM OPTION *Disable Bar Code ID Enable * Read 1 Time Accuracy Read 2 Times Reading Bar equals high Bar equals low Code Type Code Type UPC-A Interleaved 25 UPC-E Industrial 25 EAN-13 Matrix 25 EAN-8 China Postal Code Code 39 MSI/Plessey...

  • Page 23: Chapter 3 Barcode Parameters Setting

    Chapter 3 Barcode parameters se ng How to set up a Code ID? (1) Scan Start configura on bar code Go to the ASCII Table and scan the barcodes that represent the characters you want inserted. (3) Scan Confirm configura on bar code (4) Scan End configura on bar code Start configura on End configura on...
  • Page 24 Start configuration End configuration ITEM OPTION * Disable UPC-A Expand to EAN-13 Enable Disable Check Digit Send * Enable * Disable Truncate Leading Zero Enable Truncate Leading (Default:00) Ref: Appendix (00-0DH) Truncate Ending (Default:00) Ref: Appendix (00-0DH) Insert group selection Ref: Appendix（00—02H）...
  • Page 25 Start configuration End configuration ITEM OPTION * NONE 2 digits Supplement digits 5 digits 2 or 5digits Auto-discriminate Supplement - 25 -...

  • Page 26: Upc-E

    3.2 UPC-E Start configuration End configuration ITEM OPTION Disable Read * Enable Code ID setting (Default : G) Ref: Appendix (20-7EH) - 26 -...
  • Page 27 Start configuration End configuration ITEM OPTION * Disable UPC-E Expand to UPC-A Enable Disable Check Digit Send * Enable Truncate Leading (Default:00) Ref: Appendix (00-08H) Truncate Ending (Default:00) Ref: Appendix (00-08H) Insert group selection (Default:00) Ref: Appendix (00-02H) - 27 -...
  • Page 28 Start configuration End configuration ITEM OPTION * Disable Truncate Leading Zero Enable * None 2 digits Supplement digits 5 digits 2 or 5 digits Auto-discriminate Supplement - 28 -...

  • Page 29: Ean-13

    3.3 EAN-13 Start configuration End configuration ITEM OPTION Disable Read * Enable Code ID setting (Default : H) Ref: Appendix (20-7EH) Disable Check Digit Send * Enable Truncate Leading (Default : 00 ) Ref: Appendix (00-0DH) Truncate Ending (Default : 00 ) Ref: Appendix (00-0DH) - 29 -...
  • Page 30 Start configuration End configuration ITEM OPTION * None 2 digits Supplement digits 5 digits 2 or 5 digits Auto-discriminate Supplement * Disable ISBN/ISSN Conversion Enable Insert group selection (Default : 00 ) Ref: Appendix (00-02H) - 30 -...

  • Page 31: Ean-8

    3.4 EAN-8 Start configuration End configuration ITEM OPTION Disable Read * Enable Code ID setting (Default : I) Ref: Appendix (20-7EH) Disable Check Digit Send * Enable Truncate Leading (Default : 00) Ref: Appendix (00-08H) - 31 -...
  • Page 32 Start configuration End configuration ITEM OPTION Truncate Ending (Default : 00) Ref: Appendix (00-08H) * None 2 digits Supplement digits 5 digits 2 or 5 digits Auto-discriminate Supplement Insert group selection (Default : 00) Ref: Appendix (00-02H) - 32 -...

  • Page 33: Code39

    3.5 Code39 Start configuration End configuration ITEM OPTION Disable Read * Enable Code ID setting (Default : J) Ref: Appendix (20-7EH) * Disable Check-sum verification Enable Disable Check-sum transmission * Enable - 33 -...
  • Page 34 Start configuration End configuration ITEM OPTION * Disable Append Enable Min. code length (Default: 00) Ref: Appendix (00-32H) Max. code length (Default: 32H) Ref: Appendix (00-32H) Format * Standard Code39 Code 39 Full ASCII - 34 -...
  • Page 35 Start configuration End configuration ITEM OPTION * Disable Transmit Start/End Character Enable Truncate Leading (Default: 00) Ref: Appendix (00-32H) Truncate Ending (Default: 00) Ref: Appendix (00-32H) Insert group selection (Default: 00) Ref: Appendix (00-02H) - 35 -...

  • Page 36: Codabar

    3.6 Codabar Start configuration End configuration ITEM OPTION Disable Read * Enable Code ID setting (Default : K) Ref: Appendix (20-7EH) - 36 -...
  • Page 37 Start configuration End configuration ITEM OPTION Disable Check-sum verification * Enable * Disable Check-sum transmission Enable * Disable Append Enable Truncate Leading (Default:00) Ref: Appendix (00-7EH) - 37 -...
  • Page 38 Start configuration End configuration ITEM OPTION Truncate Ending (Default:00) Ref: Appendix (00-7EH) * ABCD/ABCD Start/End type abcd/abcd abcd/tn*e * Disable Start/End transmission Enable Min. code length (Default: 05) Ref: Appendix (00-3CH) - 38 -...
  • Page 39 Start configuration End configuration ITEM OPTION Max. code length (Default: 3CH) Ref: Appendix (00-3CH) Insert group selection (Default: 00) Ref: Appendix (00-02H) - 39 -...

  • Page 40: Code93

    3.7 Code93 Start configuration End configuration ITEM OPTION Disable Read * Enable Code ID setting (Default : L) Ref: Appendix (20-7EH) Disable Check-sum verification * Enable - 40 -...
  • Page 41 Start configuration End configuration ITEM OPTION * Disable Check-sum transmission Enable Min. code length (Default: 00) Ref: Appendix (0-50H) Max. code length (Default: 50H) Ref: Appendix (0-50H) Truncate Leading (Default: 00) Ref: Appendix (00-7EH) Truncate Ending (Default: 00) Ref: Appendix (00-7EH) Insert group selection Ref: Appendix (00-02H) - 41 -...

  • Page 42: Code128

    3.8 Code 128 Start configuration End configuration ITEM OPTION Disable Read * Enable Code ID setting (Default : M) Ref: Appendix (20-7EH) Disable Check-sum verification * Enable - 42 -...
  • Page 43 Start configuration End configuration ITEM OPTION * Disable Check-sum transmission Enable * Disable FNC2 Append Enable * Disable UCC/EAN128 Enable * Disable FNC1 transmission Enable - 43 -...
  • Page 44 Start configuration End configuration ITEM OPTION Truncate Leading (Default: 00) Ref: Appendix (00-7FH) Truncate Ending (Default: 00) Ref: Appendix (00-7FH) Min. code length (Default: 00) Ref: Appendix (00-7FH) Max. code length (Default: 7FH) Ref: Appendix (00-7FH) Insert group selection (Default: 00) Ref: Appendix (00-02H) - 44 -...

  • Page 45: Interleaved2 Of

    3.9 Interleaved 2 of 5 Start configuration End configuration ITEM OPTION * Disable Read Enable Code ID setting (Default : N) Ref: Appendix (20-7EH) Disable Check-sum verification *Enable Disable Check-sum transmission * Enable - 45 -...
  • Page 46 Start configuration End configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-7EH) Truncate Ending (Default : 00) Ref: Appendix (00-7EH) Min. code length (Default : 00) Ref: Appendix (00-7FH) Max. code length (Default : 7FH) Ref: Appendix (00-7FH) Insert group selection (Default : 00) Ref: Appendix (00-02H)

  • Page 47: Industrial 2Of

    3.10 Industrial 2 of 5 Start configuration End configuration ITEM OPTICON * Disable Read Enable Code ID setting (Default : O) Ref: Appendix (20-7EH) Min. code length (Default : 00) Ref: Appendix (00-32H) Max. code length (Default : 32H) Ref: Appendix (00-32H) - 47 -...
  • Page 48 Start configuration End configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-32H) Truncate Ending (Default : 00) Ref: Appendix (00-32H) * Disable Check-sum verification Enable Disable Check-sum transmission * Enable Insert group selection (Default : 00) Ref: Appendix (00-02H) - 48 -...

  • Page 49: Matrix 2 Of

    3.11 Matrix 2 of 5 Start configuration End configuration ITEM OPTION * Disable Read Enable Code ID setting (Default : P) Ref: Appendix (20-7EH) * Disable Check-sum verification Enable - 49 -...
  • Page 50 Start configuration End configuration ITEM OPTION Disable Check-sum transmission * Enable Truncate Leading (Default : 00) Ref: Appendix (00-50H) Truncate Ending (Default : 00) Ref: Appendix (00-50H) Min. code length (Default : 0B) Ref: Appendix (00-50H) Max. code length (Default : 50H) Ref: Appendix (00-50H) Insert group selection (Default : 00)

  • Page 51: China Postage

    3.12 CHINA POSTAL CODE Start configuration End configuration ITEM OPTION * Disable Read Enable Code ID setting (Default : Q) Ref: Appendix (20-7EH) * Disable Check-sum verification Enable Disable Check-sum transmission * Enable - 51 -...
  • Page 52 Start configuration End configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-50H) Truncate Ending (Default : 00) Ref: Appendix (00-50H) Min.code length (Default : 00) Ref: Appendix (00-50H) Max.code length (Default : 50H) Ref: Appendix (00-50H) Insert group selection (Default : 00) Ref: Appendix (00-02H) - 52 -...

  • Page 53: Msi/Plessey

    3.13 MSI/Plessey Start configuration End configuration ITEM OPTION * Disable Read Enable Code ID setting (Default : R) Ref: Appendix (20-7EH) * Disable MOD 10 Check-sum verification MOD 10/10 MOD 11/10 - 53 -...
  • Page 54 Start configuration End configuration ITEM OPTION Disable Check-sum transmission * Enable Truncate Leading (Default : 00) Ref: Appendix (00-3CH) Truncate Ending (Default : 00) Ref: Appendix (00-3CH) Min. code length (Default : 00) Ref: Appendix (00-3CH) Max. code length (Default : 3CH) Ref: Appendix (00-3CH) Insert group selection (Default : 00)
  • Page 55 3.14 CODE 32 (Italian Pharma-Code) Start configuration End configuration ITEM OPTION * Disable Read Enable Code ID Setting (Default:S) Ref: Appendix (20-7EH) Disable Check-sum verification * Enable Disable Check-sum transmission * Enable - 55 -...
  • Page 56 Start configuration End configuration ITEM OPTION Truncate Leading (Default : 00) Ref: Appendix (00-0AH) Truncate Ending (Default : 00) Ref: Appendix (00-0AH) Insert group selection (Default : 00) Ref: Appendix (00-02H) - 56 -...

  • Page 57: Code

    3.15 CODE 11 Start configuration End configuration ITEM OPTION * Disable Read Enable Code ID setting (Default:T) Ref: Appendix (20-7EH) Disable Check-sum verification * Enable - 57 -...
  • Page 58 Start configuration End configuration ITEM OPTION * Disable Check-sum transmission Enable Truncate Leading (Default : 00) Ref: Appendix (00-50H) Truncate Ending (Default : 00) Ref: Appendix (00-50H) Min. code length (Default : 00) Ref: Appendix (00-50H) Max. code length (Default : 50H) Ref: Appendix (00-50H) Insert group selection (Default : 00)

  • Page 59: Telepen

    3.16 Telepen Start configuration End configuration ITEM OPTION * Disable Read Enable Code ID setting (Default:V) Ref: Appendix (20-7EH) Disable Check-sum verification * Enable Only Numnic Data Format *Full ASCII - 59 -...
  • Page 60 Start configuration End configuration ITEM OPTION * Disable Check-sum transmission Enable Truncate Leading (Default : 00) Ref: Appendix (00-40H) Truncate Ending (Default : 00) Ref: Appendix (00-40H) Min. code length (Default : 00) Ref: Appendix (00-40H) Max. code length (Default : 40H) Ref: Appendix (00-40H) Insert group selection (Default : 00)

  • Page 61: Gs1 Data Bar

    3.17 GS1 Data Bar (RSS) Start configuration End configuration ITEM OPTION Enable RSS-14 *Disable Enable RSS-14 LIMITED *Disable Enable RSS-14 EXPANDED *Disable Enable RSS TO UPC/EAN *Disable - 61 -...

  • Page 62: Function Key Emulation & Function Code

    3.18 Function Key Emulation Start configuration End configuration ITEM OPTION * Disable Function Key Enable Code 39 format Full ASCII Code 39 To scan a function key barcode label, Full ASCII Code 39 must be enabling. Please refer to Full ASCII Code 39 Table to produce the function key barcode label.
  • Page 63 PAGE UP($E) F5($U) PAGE DOWN($F) F6($V) BS($H) F7($W) TAB($I) F8($X) HOME($K) F9($Y) END($L) F10($Z) ENTER($M) ESC(%A) INSERT($N) F11(%B) DELETE($O) F12(%C) - 63 -...
  • Page 64 Appendix A – - 64 -...
  • Page 65 Char. Char. “ & ‘ < > - 65 -...
  • Page 66 Char. Char. ‘ - 66 -...
  • Page 67 Table-Hex HEXADCIMAL Confirm configuration End Configuration - 67 -...
  • Page 68 Function Key Table NULL DOWN LEFT RIGHT PAGE UP PAGE DOWN HOME ENTER INSERT DELETE - 68 -...
  • Page 69 DEFAULT CHECK VERSION Version: 3.1 - 69 -...
