- Page 1 Barcode Scanner Magstripe Decoder & Scanner Programming Manual...
-
Page 2: Table Of Contents
CONTENTS Getting Started ... 2 Setup Procedures ... 3 Setup Flow Chart ...4 Group 0 : Interface Selection... 5 Group 1 : Device Selection for keyboard Interface...6-7 Group 2 : Inter-character Delay...8 Group 3 : Language for Keyboard Interface... 9-10 Group 4 : Terminator...11-12 Group 5... -
Page 3: Getting Started
Installing Keyboard Wedge Scanner To install a keyboard wedge barcode scanner, follow the steps listed below: 1) Make sure that the scanner has the correct Y (U)- cable for the system (a PC or terminal) 2) Turn off the power of the system... -
Page 4: Setup Procedures
Barcode Scanner Setup Procedures 1) Locate a group that contains the parameters to be changed. 2) Scan the "Enter Group #" label. The scanner will sound beeps indicate that setup is in progress 3) Scan the label representing the parameter to be changed 4) Scan the "Exit"... -
Page 5: Setup Flow Chart
Setup Flow Chart ENTER GROUP SELECT ITEMS EXIT Set All Defaults Show Version Note: (*) denotes default setting options marked by ( ) only available upon request. -
Page 6: Group 0: Interface Selection
Group 0: Interface Selection ENTER GROUP EXIT KEYBOARD RS-232 (WAND) (OCIA) (DTMF) Reserved 2 Resered 3 Reserved 4 Note: The interface is pre-set at factory according to the model of the device. -
Page 7: Group 1: Device Selection For Keyboard Interface
Group 1: Device Selection for Keyboard Interface ENTER GROUP EXIT PC/AT, PS/2 50,60,70,80(*) PC/XT PS/2 25, 30 (NEC 9801) (IBM 5550) (PS 55) (NEC N5520) (ACER 7300) (KW105D/ CT-700A/WANG 5120) (WANG 5425) (MAC_SE) (LC-6533) Note: Options marked by ( ) are only available upon request. -
Page 8: Interface
Group 1: Device Selection for Keyboard Interface ENTER GROUP (IBM3196, 3197, 3476, 3477) Reserved R IBM3197 IBM3477 Reserved 6 Reserved 8 EXIT Reserved Q Reserved T IBM 3476 Reserved Reserved Reserved... -
Page 9: Group 2: Intercharacter Delay
Group 2: Intercharacter Delay ENTER GROUP Start Keyboard Setting Scan Enter Group 2 Label -- > Scan Start Keyboard (or RS-232) Setting Label --> Scan two digits labels in Table-Hex --> Scan Exit Label Start RS-232 Setting Keyboard Default Value: 05 RS-232 Default Value : 00 EXIT... -
Page 10: Group 3: Language For Keyboard Interface
Group 3: Language for Keyboard Interface ENTER GROUP EXIT U.S. (*) ENGLAND FRANCE GERMANY ITALY BELGIUM SWEDEN/FINLAND SPANISH DENMARK PORTUGAL SWISS NORWAY... -
Page 11: Group 3 : Language For Keyboard Interface
Group 3: Language for Keyboard Interface ENTER GROUP EXIT CANADA HOLLAND POLAND LATIN JAPAN Reserved Reserved Reserved (IBM THINK-PAD FOR JAPAN) (PANASONIC CF- FOR JAPAN) Note: Options marked by ( ) are only available upon request. -
Page 12: Group 4: Terminator
Group 4: Terminator ENTER GROUP EXIT KEYBOARD NONE SPACE CTRL-C EXEC... -
Page 13: Group 4 : Terminator
Group 4: Terminator ENTER GROUP NONE CR/LF SPACE STX..ETX EXIT RS-232 CR (*) CTRL-C XON.. XOFF... -
Page 14: Group 5: Scan Mode
Scan 3 or 8 Label --> Scan two digit labels in Table-Hex --> Scan Confirm Label in Table-Hex Scan Exit Label Note: Scan mode setting is only available for CCD/LASER type scanner. EXIT 2: Trigger On/ Good Read Off (*) 4: Continuous/... -
Page 15: Group 5 : Scan Mode
Group 5: Scan Mode ENTER GROUP EXIT FLASH OFF(*) FLASH ON Note: Scan mode setting is only available for CCD/ Laser type scanner. -
Page 16: Group 6: Preamble And Postamble
Group 6: Preamble and Postamble ENTER GROUP EXIT Preamble Postamble Preamble & Postamble Setting: Scan Enter Group 6 Label --> Scan Preamble or Postamble Label --> Refer to ASCII Table(page 46), scan two digits in Table-Hex (Page 45) Representing one character, maximum 10 characters can be accepted. -
Page 17: Group 7: Rs-232 Parameters
Group 7: RS-232 Parameters ENTER GROUP EXIT Baud Rate 1200 2400 4800 9600(*) 19200 38400 Data Bit BIT 7 BIT 8 (*) - Page 18 Group 7: RS-232 Parameters ENTER GROUP EXIT Parity : NONE (*) EVEN Handshaking: NONE (*) XON/XOFF Scanner Ready Data Ready ACK/NAK...
-
Page 19: Group 7 : Rs-232 Parameters
Group 7: RS-232 Parameters ENTER GROUP (ACK/NAK Response Time CTS Observation Time:) 100 ms 500 ms 3 sec (*) 10 sec EXIT 300 ms 1 sec 5 sec... -
Page 20: Group 8 : Code 39 / Code 32
Group 8: CODE 39 / CODE 32 ENTER GROUP EXIT Code 39 Disable Enable (*) Standard (*) Full ASCII Transmit Start/End Character Disable (*) Enable Transmit Check Character Disable Enable (*) Verify Checksum Disable (*) Enable... - Page 21 Group 8: CODE 39 / CODE 32 ENTER GROUP EXIT Enable CODE 32 Disable CODE 32 (*) Verify Normal (*) Verify Strick...
-
Page 22: Group 9-1 : Interleaved 2 Of 5
Group 9-1: Interleaved 2 OF 5 ENTER GROUP Enable Transmit Check Character Enable (*) Verify Checksum Enable Barcode Length Setting: Scan Enter Group 9-1 Label --> Scan Length Define Label --> Scan Four Digit Labels in Table Hex (Page 43) --> Scan Confirm Label in Table-Hex -->... -
Page 23: Group 9-2: Industrial 2 Of 5 / Iata
Group 9-2: Industrial 2 OF 5 / IATA ENTER GROUP Enable Transmit Check Character Enable (*) Transmit Check Character Enable Barcode Length Setting: Scan Enter Group 9-2 Label --> Scan Length Define Label --> Scan Four Digit Labels in Table Hex (Page 43) --> Scan Confirm Label in Table-Hex -->... -
Page 24: Group 9-3 : Matrix 2 Of 5
Group 9-3: Matrix 2 OF 5 ENTER GROUP Enable Transmit Check Character Enable (*) Verify Checksum Enable Barcode Length Setting: Scan Enter Group 9-3 Label --> Scan Length Define Label --> Scan Four Digit Labels in Table Hex (Page 43) --> Scan Confirm Label in Table-Hex -->... -
Page 25: Group 9-4: China Postage
Group 9-4: CHINA POSTAGE ENTER GROUP Enable Transmit Check Character Enable (*) Verify Checksum Enable Barcode Length Setting: Scan Enter Group 9-4 Label --> Scan Length Define Label --> Scan Four Digit Labels in Table Hex (Page 43) --> Scan Confirm Label in Table-Hex --> Scan Exit Label User Define Length Setting: Scan Enter Group 9-4 Label... -
Page 26: Group 10 : Code 128
Group 10: Code 128 ENTER GROUP EXIT Disable Enable (*) Enable/Disable Checkdigit Disable Enable (*) (not send checkdigit) UCC/EAN/128 Disable (*) Enable Note: Options marked by ( ) are only available upon request... -
Page 27: Group 11 : Code 11
Group 11: CODE 11 ENTER GROUP EXIT Disable Enable (*) Number of Check Character Two (*) Transmit Check Character Disable (*) Enable Enable/Disable Checkdigit Disable Enable (*) -
Page 28: Group 12 : Code 93
Group 12: Code 93 ENTER GROUP EXIT Disable (*) Enable Verify Checkdigit Disable Enable (*) -
Page 29: Group 13 : Msi-Plessy
Group 13: MSI-PLESSEY ENTER GROUP Enable (*) Verify Checkdigit Enable (*) Enable MOD Enable MOD 10-10 Transmit/Truncate Checkdigit Truncate 1 checkdigit EXIT Disable Disable Enable MOD 10 (*) Enable MOD 11-10 Transmit checkdigit (*) Truncate 1 & 2 checkdigit... -
Page 30: Group 14 : Codabar/Nw7
Group 14: CODABAR / NW7 ENTER GROUP Enable (*) Transmit Start/End Character Enable Start/End Transmit Type ABCD/ABCD abcd/abcd (*) EXIT Disable Disable (*) ABCD/TN*E abcd/tn*e... -
Page 31: Group 15 : Code 4
Group 15: Code 4 ENTER GROUP EXIT Enable Disable (*) -
Page 32: Group 16-1 : Ean-13/Jan-13
Group 16-1: EAN-13/JAN-13 ENTER GROUP Enable (*) ADD-ON 2/5 Enable Transmit Check Character Enable (*) Truncate 1 digit Enable Truncate 2 digit Enable EAN Checkdigit Enable (*) EXIT Disable Disable (*) Disable Disable (*) Disable (*) Disable... -
Page 33: Group 16-2: Upc-A
Group 16-2: UPC-A ENTER GROUP Enable (*) ADD-ON 2/5 Enable Transmit Check Character Enable (*) Truncate Leading Digit Enable UPC-A Convert to EAN-13 Enable EXIT Disable Disable (*) Disable Disable (*) Disable (*) -
Page 34: Group 16-3 : Ean-8/Jan-8
Group 16-3: EAN-8/JAN-8 ENTER GROUP Enable (*) ADD-ON 2/5 Enable Transmit Check Character Enable (*) Truncate Leading Digit Enable EAN-8 Convert to EAN-13 Enable 1 (add zeros in the front of barcode) EXIT Disable Disable (*) Disable Disable (*) Disable (*) Enable 2 (add zeros in the middle of barcode) -
Page 35: Group 16-4: Upc-E
Group 16-4: UPC-E ENTER GROUP Enable (*) ADD-ON 2/5 Enable Transmit Check Character Enable (*) Truncate Leading Digit Enable UPC-E Convert to UPC-A Enable EXIT Disable Disable (*) Disable Disable (*) Disable (*) -
Page 36: Group 16-5: Isbn/Issn
Group 16-5: ISBN/ISSN ENTER GROUP EXIT Enable Disable (*) -
Page 37: Group 17 : General Parameter
Group 17: General Parameters ENTER GROUP Upper Case Universal Buzzer Pitch & Buzzer Duration Setting: Scan Enter Group 17 Label --> Scan Buzzer Pitch or Buzzer Duration Label --> Scan Two Digit Labels in Table-Hex --> Scan Confirm Label in Table-Hex --> Scan Exit Label Power Up Beeping Enable (*) -
Page 38: Group 18: Code Id Setting
Group 18: Code ID Setting ENTER GROUP CODE 39/CODE 32 INDUSTRIAL 2 OF 5 CHINA POSTAGE CODE 93 MSI/PLESSEY EAN-13 UPC-E CODE 4 Note: Refer to ASCII Table, scan two hexadecimal labels in Table Hex to represent one character EXIT INTERLEAVED 2 OF 5 MATRIX 2 OF 5 CODE 128... -
Page 39: Group 19: Wand Type Parameters
Group 19: WAND Type Parameters ENTER GROUP EXIT BAR=LOW BAR=HIGH(*) Scan Speed Lowest Low (*) High Highest Data Format Transmit in Normal Format (*) Transmit in Code 39 Format Transmit in Code 128 Format... -
Page 40: Group 20-1 : Magnetic Parameters
Group 20-1: (Magnetic Parameters) ENTER GROUP Enable (*) Track Order Track 1/3/2 Track 2/3/1 Track 3/1/2 Note: Options marked by ( ) are only available upon request EXIT Disable Track 1/2/3 (*) Track 2/1/3 Track 3/2/1... - Page 41 Group 20-1: (Magnetic Parameters) ENTER GROUP Track Selection Track 1 only Track 3 only Track 2 and 3 ISO (*) Note: Options marked by ( ) are only available upon request EXIT Track 1&2&3 any (*) Track 2 only Track 1 and 2 Track 1 and 2 and 3 (JIS-2)
-
Page 42: Group 20-2 : Magnetic Parameters
Group 20-2: (Magnetic Parameters) ENTER GROUP Start Sentinel: (SS) Tk2 Default: ; End Sentinel: (ES) DLE: Tk2 Default: Null STX: Magnetic Output Data Format: STX - Tk1 Start Sentinel - Tk1 Data - End Sentinel - Tk1 - DLE STX - Tk2 Start Sentinel - Tk2 Data - End Sentinel - Tk2 - DLE STX - Tk3 Start Sentinel - Tk3 Data - End Sentinel - Tk3 - DLE Note: Options marked by ( ) are only available upon request EXIT... -
Page 43: Group 21 : Function Key Emulation
Group 21: (Function Key Emulation) ENTER GROUP Enable Enable Function Key Emulation: Scan Enter Group 21 Label --> Scan Enable Label --> Scan Exit Label To concatenate a function key with input data, please refer to Function Key Table for its hexadecimal representation. For Example: Preamble data with F1 Scan Enter Group 6 Label -->... - Page 44 Function Code for PC XT/AT F1 ($A) F2 ($B) F3 ($C) F4 ($D) F5 ($E) F6 ($F) F7 ($G) F8 ($H) F9 ($I) F10 ($J) F11 ($K) F12 ($L)
- Page 45 Function Code for PC XT/AT Enter ($M) End ($U) ($B) Tab ($N) PgUp ($V) BS ($O) PgDn ($W) Up ($P) Ins ($X) Down ($Q) Del ($Y) Left ($R) Esc (%A) Right ($S) Home ($T)
-
Page 46: Table-Hex : Hexadecimal
Table-Hex : HEXADECIMAL Confirm... -
Page 47: Ascii Table
ASCII TABLE... -
Page 48: Hexadecimal-Decimal Conversion Table
Hexadecimal-Decimal Conversion Table For Example: Hexadecimal Decimal 56 -> H:5 L:3 D5-> H:D L:5... -
Page 49: Pin Assignments
PIN ASSIGNMENTS 10Pin Modular Plug RJ-45 Male WAND 10P10C PWR-CTL GOOD- GOOD- READ READ DATA DATA SW-DET S.O.S TTL Signal Output Function Start of Scan Signal Data Led Indicator Trigger Power Enable VCC+5V DB9F RS-232 DATA PC-CLK KB-CLK KB-DATA 10P10C DB9F Din6M/5M(240 ) Din6M... - Page 50 PIN ASSIGNMENTS Wand Emulation Signal Output Function DB9F Signal Data VCC+5V DB9F Note : "F" stands for a female connector, while "M" stands for a male connector. RS-232 Signal Output Function VCC+5V Note : For PC applications, a cable with DC power jack is required to accept external power input.
- Page 51 Keyboard Signal Output Funcion Din5F PC_Data PC_CLK Vcc+5V KB_CLK KB_Data DIN5M DIN5F USB Signal Output FUNCTION Din5M Mini-Din6M Mini-Din6F USB-A USB PLUG MD6M MD6F...
- Page 52 V20040930...
