POS-X EVO Impact Manual

Mini dot impact printer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL : EVO Impact
Mini Dot Impact Printer
All specifications are subject to change without notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO Impact and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POS-X EVO Impact

Summary of Contents for POS-X EVO Impact

  • Page 1 MODEL : EVO Impact Mini Dot Impact Printer All specifications are subject to change without notice...

  • Page 3: Table Of Contents

    Table of Contents 1. Features 2. Specification 3. Self Test 4. User Switches 5. Command List 5.1. EMULATION EPSON TM-U200 5.2. EMULATION CITIZEN iDP-3540 5.3. EMULATION STAR SP200 6. Interface 6.1. Interface Connector 7. Cash Drawer Connector 8. Electrical Specifications 9.

  • Page 4: Features

    Emulation mode, communications mode, baud rate, serial/parallel handshake, and head printing characteristics are all configured through dip switch settings. ♣Data Buffer The EVO Impact printer has a built-in 16 Kilobyte I/O buffer allowing the host computer to free itself after sending the print data. ♣Reliable communications The EVO Impact supports multiple baud rates, protocols, and handshaking on its parallel &...

  • Page 5: Specification

    2. Specification Printer Specifications MODEL EVO Impact PRINT METHOD 9-pin serial impact dot matrix PRINT DIRECTION Bi-directional (with logical seeking) Epson Mode : 42/35, 40/33, Star Sp200 : 42/35 NO. OF COLUMNS Other Modes : 40/32 FONT SIZE 7 x 9, 9 x 9 dots...
  • Page 6 Overall dimension This equi pment is indoor use and all the communication wiring are limited to inside of the building”...

  • Page 7: Self Test

    If the printer setup needs to be changed, turn the Power Off before changing the setting. The printer will be setup at the factory as follows; Printer is setup as follows: Model : EVO Impact Firmware : Ver X.XX Interface :...

  • Page 8: User Switches

    A Power switch located on the lower left side of the printer is used to turn the printer on/off. Indicators This section explains the different patterns signaled by the two LED indicators located on the top cover of the EVO Impact. LED1 LED2...

  • Page 9: Command List

    5. Command List 5.1. EMULATION EPSON TM-U200 Command Hex Code Description <09>H Horizontal tab <0A>H Print and line feed <0D>H Carriage Return DLE EOT <10>H<04>H<n> Real-time status transmission DLE ENQ <10>H<05>H<n> Real-time request to printer ESC SP <1B>H<20>H<n> Set right-side character spacing ESC ! <1B>H<21>H<n>...

  • Page 10: Emulation Citizen Idp-3540

    5.2. EMULATION CITIZEN iDP-3540 Command Hex Code Description <07>H Drive pulse setting command for 1st drawer <18>H Clear data in buffer <0A>H Paper feed <0C>H<n> Paper feed n lines <0D>H Print command <0E>H Select expanded character mode <0F>H Select normal character mode <11>H Initial set command <12>H...

  • Page 11: Emulation Star Sp200

    5.3. EMULATION STAR SP200 Command Hex Code Description Differed drive command “A” for peripheral unit <07>H (Default setting) <18>H Cancel print data in buffer <0A>H Line feed <0D>H Line feed (same as LF) <0E>H Select expanded character mode <0F>H Cancel expanded character mode <1C>H Immediate drive command “B”...

  • Page 12: Interface

    6. Interface 6-1. Interface Connector <D-SUB 25 Female Serial> <Centronics Parallel> <USB “B” Type> <Ethernet> <USB COMBO> <Wi-fi> Serial Interface SIGNAL DESCRIPTION Output Printer transmit data line RS-232C level Input Printer receive data line RS-232C level 4, 20 Output Printer handshake to host line RS-232C level Input Data Send Ready 1, 7...
  • Page 13 Centronics Parallel Interface SIGNAL DESCRIPTION STROBE- Input Synchronize signal Data received DATA0~7 Input/Output Data bit Transmitted 0~7 ACK- Output Data receiving completed. BUSY Output Impossible to print of data receiving. Output Paper empty SELECT Output Printer status for ON/OFF line AUTO FEED- Input Paper auto feed signal...

  • Page 14: Cash Drawer Connector

    7. Cash Drawer Connector The EVO Impact can operate two cash drawers with a 6 pin RJ-11 modular connector. The driver is capable of supplying a maximum current of 1.0A for 510 ms or less, when not printing. <Cash Drawer Connector>...

  • Page 15: Electrical Specifications

    8. Electrical Specifications The EVO Impact requires a power supply with the following parameters. A linear power Adapter is included in the EVO Impact box. Power Supply Voltage : 24VDC±10% Power Supply Current : 2.5 A <Power Supply Connector>...

  • Page 16: Dip Switch Settings

    9. Dip Switch Settings This table gives the definition for the DIP switch settings. Function Setting Epson TM-U200 Epson TM-U300 Emulation Citizen iDP3540 Star SP200 CR=CR Only Character CR=CR + LF 40/33 Char/Line 42/35 Char/Line Auto Not Install Cutter Install Not Install 2Color Install...
  • Page 17 Function Setting Epson TM-U200 Epson TM-U300 Emulation Citizen iDP3540 Star SP200 CR=CR Only Character CR=CR + LF 40/33 Char/Line 42/35 Char/Line Auto Not Installed Cutter Installed Not Installed 2 Color Installed Not Installed Journal Installed Function Setting Auto Not Install Melody Installed...
  • Page 21 2012. 03. Rev. 1.0...
