EVO-RP1
::: Receipt Printer User's Manual :::
All specifications are subject to change without notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO-RP1-U and is the answer not in the manual?

Questions and answers

Summary of Contents for POS-X EVO-RP1-U

  • Page 1 EVO-RP1 ::: Receipt Printer User’s Manual ::: All specifications are subject to change without notice...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. Parts Identifications 2. Setting up the printer 2.1 Unpacking 2.2 Connecting the cables 2.3 Loading the paper 2.4 Dip switch setting 3. Control panel and other functions 3.1 Control panel 3.2 Error Indicator 4. Self Test 5.
  • Page 4: Parts Identifications

    1. Parts Identifications POWER SWITCH Used to turn on/off power to the printer. PRINTER COVER Open this cover to load or replace paper. CONTROL PANEL Features LED indicators to indicate printer status and switches to operate the printer. COVER OPEN PUSH...
  • Page 5: Setting Up The Printer

    INTERFACE CONNECTOR INTERFACE CONNECTOR (USB) 2. Setting Up the Printer 2-1. Unpacking Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. The Printer PERIPHERAL DRIVE CONNECTOR POWER CONNECTOR...
  • Page 6: Connecting The Cables

    Power Adaptor Interface Cable 2-2. Connecting the Cables All cables connect to the connector panel on the back of the printer which is shown below:...
  • Page 7: Interface Connector

    INTERFACE CONNECTOR (USB) host computer. For connection to a host computer. Before connecting any of the cables, make sure that both the printer and the computer are turned off. 2-2-1. Interface Connector POWER CONNECTOR For connection of the AC adapter.
  • Page 8 Printer transmit data line Printer transmit data line System Ground DESCRIPTION Printer transmit data line RS-232C level Printer receive data line RS-232C level Printer handshake to host line RS-232C level Data Send Ready System Ground DESCRIPTION Input Synchronize signal Data received...
  • Page 9: Cash Drawer Connector

    Data IN - 2-2-2. Cash Drawer Connector The printer can operate two cash drawers with a 6 pin RJ-11 modular connector. The driver is capable of supplying a maximum current of 1.0A for 510ms or less when not printing. Output Data receiving completed.
  • Page 10: Loading The Paper

    2-3. Loading the Paper Roll Notes: Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer cannot detect the paper end correctly. 1. Turn off power switch.
  • Page 11 5. Note the correct direction that the paper comes off the roll: 6. Pull out a small amount of paper as shown. Then, close the cover.
  • Page 12: Dip Switch Setting

    7. Tear off the paper as shown. 2-4. DIP SWITCH SETTING The printer is set up at the factory to be appropriate for almost all users. It does, however, offer some settings for users with special requirements. It has DIP switches that allow you to change communication settings, such as handshaking and parity check, as well as print density.
  • Page 13: Serial Interface

    38400BPS ☞ CAUTION: Turn off the printer while removing the DIP switch cover to prevent an electric short, which can damage the printer. 1. Make sure the printer is turned off and unplugged. 2. Remove the DIP switch cover by taking off as shown in the illustration below.
  • Page 14 DIP SWITCH 3. Set the switches using a pointed tool, such as tweezers or a small screwdriver. 4. Replace the DIP switch cover. The new settings take effect when you turn on the printer. ☞ CAUTION: When the paper cutter is jammed, the top cover might be stuck closed. In this case, repeat power on and off several times.
  • Page 15 3. Turn screw with a screwdriver until paper is released from the cutter.
  • Page 16: Control Panel And Other Functions

    3. Control panel and other functions. 3-1. Control panel You can control the basic paper feeding operations of the printer with the button on the control panel. The indicator lights let you to monitor the printer’ s status. Control Panel Button The button can be disabled by the ESC c 5 command.
  • Page 17: Self Test

    To use the hex dump feature, follow these steps: 1. After you make sure that the printer is off and Dip s/w 1-2 are set to ON, turn on the printer. 2. Run any software program that sends data to the printer. The printer prints “Hexadecimal Dump”...
  • Page 18: Specifications

    6. Specifications Important! When connecting or disconnecting the power supply from the printer, be sure that the following cautions are observed. Use a power supply (Limited Power Supply) of DC 24V±10% and more than 2.5A. Be careful about installing the printer in an area where there is electrical noise.
  • Page 19 (9) Overall dimensions...
  • Page 20: Auto Cutter Specifications

    6-2. Auto Cutter Specifications (1) Cutting Frequency (2) Thickness of paper (3) Cutter Life 6-3. Interface RS232 Serial Interface, Centronics Parallel Interface(IEEE1284), USB Interface, Ethernet Interface(10Mbps) 6-4. Electrical Characteristics (1) Input Voltage (2) Current Consumption (3) Power Connector Max. 30 cuts per minute 0.065 ~ 0.1mm 1.5 million cuts (if the paper thickness is between 65 and 80µm)
  • Page 21: Environmental Requirements

    6-5. Environmental Requirements (1)Operating Temperature 5°C to 40°C Humidity 10% to 90% RH (without condensation) (2)Transport/Storage (except paper) Temperature -20°C to 60°C Humidity 10% to 90% RH (without condensation) 6-6. Reliability (1)MCBF 50 million lines (based on an average printing rate of 12.5% with paper thickness in the range 65µm to 75µm) 35 million lines (based on an average printing rate of 12.5% with paper thickness in the range 76µm to 150µm)
  • Page 22: Command List

    Print and return to standard mode(in page mode) Cancel print data in page mode DLE EOT Real-time status transmission DLE ENQ Real-time request to printer DLE DC4 Generate pulse at real-time ESC FF Print data in page mode ESC SP...
  • Page 23 Print downloaded bit image GS B Turn white/black reverse printing mode on/off GS H Select printing position of HRI characters GS I Transmit printer ID GS L Set left margin GS P Set horizontal and vertical motion units GS V...
