- Page 1 MODEL : ION-PT2 Receipt Printer User’s Manual All specifications are subject to change without notice...
-
Page 2: Table Of Contents
Table of Contents 1. Parts Identifications 2. Setting up the printer 2.1 Unpacking 2.2 Connecting the cables 2.3 Loading the paper roll 3. Control panel and other functions 3.1 Control panel 3.2 Error Indicators 4. Self Test 5. ASCII Print 6. -
Page 3: Parts Identifications
1. Parts Identifications CONTROL PANEL Features LED indicators to indicate printer status and buttons to operate the printer. PRINTER COVER Open this cover to load or replace a paper roll. POWER SWITCH Used to turn on/off power to the printer. PAPER DOOR OPEN BUTTON Push down this button to open the paper door. -
Page 4: Setting Up The Printer
2. Setting Up the Printer 2-1. Unpacking Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. The Printer Interface Cables Paper Roll... -
Page 5: Connecting The Cables
2-2. Connecting the Cables All cables connect to the connector panel on the back of the printer which is shown below: INTERFACE CONNECTOR CASH DRAWER CABLE CONNECTOR POWER CONNECTOR Connects to peripheral For connection to a For connection of the units such as cash host computer. - Page 6 2-2-1. Interface Connector <D-SUB 25 Female Serial> <USB “B” Type> 25Pin Serial Interface Signal Description Output Printer transmit data line RS-232C level Input Printer receive data line RS-232C level 4, 20 Output Printer handshake to host line RS-232C level Input Data Send Ready System Ground USB Interface...
- Page 7 2-2-2. Cash Drawer Connector The printer can operate two cash drawers with a 6 pin RJ-11 modular connector. The driver is capable of supplying a maximum current of 1.0A for 510ms or less when not printing. SIGNAL DESCRIPTION Signal GND Drawer kick-out drive signal 1 Output Drawer open/close signal...
-
Page 8: Loading The Paper Roll
2-3. Loading the Paper Roll Note: Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer cannot detect the paper end correctly. Turn off power switch. 1. - Page 9 5. Note the correct direction that the paper comes off the roll: 6. Pull out a small amount of paper roll as shown. Then, close the cover. 7. Tear off the paper as shown.
-
Page 10: Control Panel And Other Functions
3. Control panel and other functions 3-1. Control panel You can control the basic paper feeding operations of the printer with the FEED button on the control panel. The indicator lights let you to monitor the printer’ s status. Control Panel Feed Button The feed button can be disabled using the ESC c 5 command. -
Page 11: Self Test
4. Self Test The self-test result indicates whether the printer is operating properly. With this information the user can check the following options or status of the printer. Control circuit Printer mechanism Printing quality ROM version Interface setting This test is independent of any other equipment or software. Running the self test 1. Make sure the printer is turned off and the printer cover is closed properly before performing the self test 2. -
Page 12: Ascii Print
5. ASCII Print ASCII PRINT prints a test page with ASCII codes. You can use this function to check printer functionality. The ASCII PRINT test automatically ends and cuts the paper after printing the following: *** Completed *** The printer is ready to receive data as soon as it completes the ASCII PRINT. 6. -
Page 13: Hexadecimal Dump
7. Hexadecimal Dump This feature allows experienced users to see exactly what data is sent to the printer. This can be useful in finding software problems. When you go into the hex dump function, the printer prints all commands and other data in hexadecimal format along with a guide section to help you find specific commands. -
Page 14: Printer Cleaning
9. Printer cleaning If the interior of the printer is dusty, the printing quality can be reduced. In this case, follow the instructions below to clean the printer. Note: 1. Make sure to turn the printer power off prior to cleaning. 2. Wait 10 minutes for the print head to cool before cleaning it as it can get very hot during during use. 3. -
Page 15: Specifications
10. Specifications IMPORTANT! When connecting or disconnecting the power supply from the printer, be sure that the following cautions are observed. Use a power supply (Limited Power Supply) of DC 24V±10% and more than 1.75A. Try to avoid installing the printer in an area where there is electrical noise. Take the appropriate measures to protect against electrostatic AC line noise, etc. -
Page 16: Auto Cutter Specifications
10-2. Auto Cutter Specifications (1) Cutting Frequency Max. 30 cuts per minute (2) Thickness of paper 0.06 ~ 0.08 mm (3) Cutter Life 1.5 million cuts (if the paper thickness is between 65 and 80µm) 10-3. Interface USB (B type) + Serial or Ethernet built-in 10-4. Electrical Characteristics (1) Input Voltage DC 24V ±... -
Page 17: Environmental Requirements
10-5. Environmental Requirements (1) Operating Temperature 5°F to 104°F (5°C to 40°C) Humidity 10% to 90% RH (without condensation) (2) Transport/Storage (no paper) Temperature -20°F to 140°F (-20°C to 60°C) Humidity 10% to 90% RH (without condensation) 10-6. Reliability (1) MCBF 70 million lines (2) Print Head Life 100 million pulses, 150Km... -
Page 18: Command List
11. Command List Command Function REMARKS Horizontal tab Print and line feed Print and carriage return Print and return to standard mode (in page mode) Cancel print data in page mode DLE EOT Real-time status transmission DLE ENQ Real-time request to printer DLE DC4 Generate pulse at real-time ESC FF Print data in page mode... - Page 19 Command Function REMARKS ESC t Select character code table ESC { Turn upside-down printing mode on/off FS p Print NV bit image FS q Define NV bit image GS ! Select character size GS $ Set absolute vertical print position in page mode GS * Define downloaded bit image GS /...
