Summary of Contents for NETGEAR ProSafe Premium WNDAP660

  • Page 1 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Reference M anua l 350 East Plumeria Drive San Jose, CA 95134 October 2012 202-10984-01 v2.0...
  • Page 2: Revision History

    NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. Other brand and product names are registered trademarks or trademarks of their respective holders.
  • Page 3: Table Of Contents

    WNDAP660 ........
  • Page 4 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Chapter 3 Wireless Configuration and Security Wireless Data Security Options ....... . . 42 Security Profiles .
  • Page 5 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Configure Ethernet LLDP ........105 Configure Hotspot Settings.
  • Page 6: Chapter 1 Introduction

    Introduction This chapter introduces the NETGEAR® ProSafe® Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 and describes some of the key features. The chapter includes the following sections: • About the ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 •...
  • Page 7: What Is In The Box

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 transmit radio chains and three receive radio chains, also referred to as 3x3 multiple input, multiple output (MIMO), can increase wireless throughput considerably. The wireless access point provides wireless connectivity to multiple wireless network devices within a fixed range or area of coverage—interacting with a wireless network interface card...
  • Page 8: System Requirements

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 System Requirements Before installing the wireless access point, make sure that your system meets these requirements: • A 10/100/1000 Mbps local area network device such as a hub or switch •...
  • Page 9: Key Features

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • DHCP server and client. The DHCP server of the wireless access point can provide a dynamic IPv4 or IPv6 address to wireless clients. The wireless access point can also act as a client and obtain an IPv4 or IPv6 address from a DHCP server on the LAN.
  • Page 10 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • QoS. Quality of Service (QoS) support lets you configure parameters that affect traffic flowing from the wireless access point to the client station and traffic flowing from the client station to the wireless access point: The QoS settings let you prioritize traffic, such as voice and video traffic, so that packets do not get dropped.
  • Page 11: B/G/N And 802.11A/N Standards-Based Wireless Networking

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • VLAN security profiles. Each security profile is automatically allocated a VLAN ID when the security profile is modified. 802.11b/g/n and 802.11a/n Standards–Based Wireless Networking The wireless access point provides a bridge between wired Ethernet LANs and 802.11b/g/n- and 802.11a/n-compatible wireless LAN networks.
  • Page 12: Top Panel

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Top Panel The LEDs of the wireless access point are described in the following figure and table: Figure 1. Table 1. Top panel LEDs Item Description Power/Test Off Power is off.
  • Page 13: Rear Panel

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 1. Top panel LEDs (continued) Item Description WLAN Wireless 802.11b/g/n (2.4 GHz) LAN is not ready, or no wireless activity is detected. On or blinking (green) Wireless 802.11b/g/n (2.4 GHz) LAN is ready, or wireless activity is detected.
  • Page 14: Bottom Panel With Product Label

    The first time that you connect to the wireless access point while it is connected to the Internet, you have the option to register your product. At any time, you can register your product from the web management interface, or you can go to the NETGEAR website for registration at https://my.netgear.com/registration/login.aspx.
  • Page 15 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 4. Click Register. A new screen displays in your browser: Figure 5. Enter the information in the blank fields. The serial number, model number, and date of purchase are entered automatically.
  • Page 16 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 6. Complete the registration form. Click submit. Introduction...
  • Page 17: Chapter 2 Installation And Basic Configuration

    Installation and Basic Configuration This chapter describes how to install and configure the wireless access point for wireless connectivity to your LAN. This basic configuration enables computers with 2.4 GHz 802.11b/g/n and 5 GHz 802.11a/n wireless adapters to connect to the Internet or access printers and files on your LAN.
  • Page 18: Ethernet Cabling Requirements

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Note: Failure to follow these guidelines can result in significant performance degradation or inability to connect wirelessly to the wireless access point. For complete performance specifications, see Appendix A, Supplemental Information.
  • Page 19: Hardware Requirements For Computers On Your Lan

    To connect to the wireless access point on your network, each computer needs to have an 802.11b/g/n or 802.11a/n wireless adapter installed. NETGEAR recommends using the wireless access point with computers that have the NETGEAR N600 Wireless Dual Band USB Adapter (WNDA3100) installed.
  • Page 20: Install And Configure The Wireless Access Point

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Install and Configure the Wireless Access Point Install and configure your wireless access point in the order of the following sections: Connect the Wireless Access Point to a Computer Log In to the Wireless Access Point...
  • Page 21 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Ethernet cable Ethernet port Figure 7. Turn on your computer. Connect the power adapter to the wireless access point. Tip: The wireless access point supports Power over Ethernet (PoE) with power redundancy.
  • Page 22: Log In To The Wireless Access Point

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 WLAN LED. The 2.4 GHz WLAN LED is lit or blinks green when the wireless LAN (WLAN) is ready. WLAN LED. The 5 GHz WLAN LED is lit or blinks green when the wireless LAN (WLAN) is ready.
  • Page 23: Configure Basic General System Settings And Time Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 9. The bottom right corner of all screens that allow you to make configuration changes show the Apply and Cancel buttons, and on several screens the Edit button. Figure 10.
  • Page 24 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Configure the settings as explained in the following table: Table 2. Basic general system settings Setting Description Access Point Name This unique name is the wireless access point NetBIOS name. The name is printed on the rear label of the wireless access point.
  • Page 25: Configure The Ipv4 Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 3. Time system settings (continued) Setting Description NTP Client Enable the Network Time Protocol (NTP) client to synchronize the time of the wireless access point with an NTP server. By default the Enable radio button is selected.
  • Page 26 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 13. Configure the IPv4 settings as explained in the following table: Table 4. IPv4 settings Setting Description DHCP Client By default, the Dynamic Host Configuration Protocol (DHCP) client is disabled. If...
  • Page 27: Configure The Optional Dhcpv4 Server

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Configure the Optional DHCPv4 Server The wireless access point provides a built-in DHCPv4 server for wireless clients only, which can be especially useful in small networks. When the DHCP server is enabled, the wireless access point provides preconfigured TCP/IP configurations to all connected wireless stations.
  • Page 28: Configure The Basic Wireless Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 5. DHCP server settings for IPv4 (continued) Setting Description Ending IPv4 Address Enter the last address in the range of IPv4 addresses to be assigned to DHCP clients. The default address is 192.168.1.50.
  • Page 29 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Note: The radio wave icon ( ) displays next to the enabled wireless mode (b, bg, or ng). Figure 15. Specify the wireless mode in the 2.4 GHz band by selecting one of the following radio buttons: •...
  • Page 30 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Specify the remaining wireless settings as explained the following table: Table 6. Basic 2.4 GHz band wireless settings Setting Descriptions Wireless Network Name Enter a 32-character (maximum) service set identifier (SSID); the characters are (SSID) case-sensitive.
  • Page 31 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 6. Basic 2.4 GHz band wireless settings (continued) Setting Descriptions 11b and 11bg modes Data Rate From the drop-down list, select the transmit data rate of the only wireless network. The default setting is Best. For a list of all...
  • Page 32 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 16. Specify the wireless mode in the 5 GHz band by selecting one of the following radio buttons: • 11a. 802.11n-compliant devices can connect to the access point because they are backward compatible.
  • Page 33 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Specify the remaining wireless settings as explained the following table: Table 7. Basic 5 GHz band wireless settings Setting Descriptions Wireless Network Name Enter a 32-character (maximum) service set identifier (SSID); the characters are (SSID) case-sensitive.
  • Page 34: Test Basic Wireless Connectivity

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 7. Basic 5 GHz band wireless settings (continued) Setting Descriptions 11a mode only Data Rate From the drop-down list, select the transmit data rate of the wireless network. The default setting is Best. For a list of all...
  • Page 35: Mount The Wireless Access Point

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 NETGEAR recommends that you complete the following tasks before you deploy the wireless access point in your network: • Configure wireless security and other wireless features as described in Chapter 3, Wireless Configuration and Security.
  • Page 36 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Note: wireless access point Do not place the in a false ceiling space facing up.  To install the wireless access point using the ceiling installation kit: Verify the package contents of the ceiling installation kit.
  • Page 37 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Attach the mounting plate to the clamp. Connect the cables to the wireless access point. Attach the wireless access point to the mounting plate. Installation and Basic Configuration...
  • Page 38: Wall Installation

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Attach the cover to the wireless access point. Wall Installation The best location for wall installation is at the center of your wireless coverage area, and within line of sight of all mobile devices. Make sure the top (the dome side) of the wireless access point is directed toward the users and not the wall.
  • Page 39 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Screws and wall supports Mounting plate Detach the mounting plate from the wireless access point. Attach the mounting plate to the wall. Connect the cables to the wireless access point.
  • Page 40 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Attach the wireless access point to the mounting plate. Attach the cover to the wireless access point. Installation and Basic Configuration...
  • Page 41: Desk Installation

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Desk Installation  To install the wireless access point on a desk: Attach the rubber feet to the holes in the bottom of the wireless access point. Rubber feet Installation and Basic Configuration...
  • Page 42: Chapter 3 Wireless Configuration And Security

    Wireless Configuration and Security This chapter describes how to configure the wireless features of the wireless access point. The chapter includes the following sections: • Wireless Data Security Options • Security Profiles • Configure RADIUS Server Settings • Restrict Wireless Access by MAC Address •...
  • Page 43 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Unlike wired network data, your wireless data transmissions can extend beyond your walls and can be received by anyone with a compatible adapter. For this reason, use the security features of your wireless equipment. The wireless access point provides highly effective security features that are covered in detail in this chapter.
  • Page 44: Security Profiles

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • WPA and WPA-PSK (TKIP). Wi-Fi Protected Access (WPA) data encryption provides strong data security with Temporal Key Integrity Protocol (TKIP) encryption. The very strong authentication along with dynamic per-frame rekeying of WPA makes it virtually impossible to compromise.
  • Page 45 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 To set up a security profile, select its network authentication type, data encryption, wireless client security separation, and VLAN ID: • Network authentication The wireless access point is set by default as an open system with no authentication.
  • Page 46: Before You Change The Ssid, Wep, And Wpa Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Before You Change the SSID, WEP , and WPA Settings For a new wireless network, print or copy the following forms and fill in the settings. For an existing wireless network, the network administrator can provide this information. Be sure to set the country or region correctly as the first step.
  • Page 47 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Form for 802.11a/an Modes Print this page and store the security information in a safe place: • SSID: The service set identifier (SSID) identifies the wireless local area network. You can customize it by using up to 32 alphanumeric characters.
  • Page 48: Configure And Enable Security Profiles

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Configure and Enable Security Profiles To configure and enable a security profile, you need to enable the associated radio: • For 802.11b/bg/ng modes, the 2.4 GHz radio needs to be enabled (see Configure 802.11b/bg/ng Wireless Settings...
  • Page 49 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 19. The following table explains the fields of the Profile Settings screen: Table 8. Profile settings Setting Description Profile Name The unique name of the wireless security profile that makes it easy to recognize the profile.
  • Page 50 Enter a unique name of the wireless security profile that makes it easy to recognize the profile. The default names are NETGEAR, NETGEAR-1, NETGEAR-2, and so on, through NETGEAR-7. You can enter a value of up to 32 alphanumeric characters.
  • Page 51 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 9. Profile definition settings (continued) Setting Description Broadcast Wireless Select the Yes radio button to enable the wireless access point to broadcast its Network Name (SSID) SSID, allowing wireless stations that have a null (blank) SSID to adopt the wireless access point’s SSID.
  • Page 52 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 10. Profile authentication settings (continued) Setting Description Network Authentication WPA & WPA2 with Configure the RADIUS server setting. TKIP + AES and Data Encryption Radius encryption is the default encryption.
  • Page 53 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 WARNING: If you use a wireless computer to configure wireless security settings, you are disconnected when you click Apply. Reconfigure your wireless computer to match the new settings, or access the wireless access point from a wired computer to make further changes.
  • Page 54 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 22. Table 11. WEP encryption settings Setting Descriptions Data Encryption Select the encryption key size from the drop-down list: • 64-bit WEP. Standard WEP encryption, using 40/64-bit encryption. •...
  • Page 55 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 23. Configure WPA with RADIUS, WPA2 with RADIUS, and WPA & WPA2 with RADIUS WPA, WPA2, and WPA & WPA2 security requires RADIUS-based 802.1x authentication, so you also need to define RADIUS server settings. For information about RADIUS servers, see Configure RADIUS Server Settings on page 57.
  • Page 56 AES encryption if you want to use the 11n rates and speed. Advanced Encryption Standard (AES) is the standard encryption method used with WPA2. Note: Although some wireless clients might support AES with WPA, the WNDAP660 wireless access point does not support WPA with AES. TKIP + AES The TKIP + AES encryption method is supported both for WPA and WPA2.
  • Page 57: Configure Radius Server Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • WPA-PSK & WPA2-PSK Figure 29. Table 13. Settings for WPA-PSK, WPA2-PSK, and WPA-PSK & WPA2-PSK Setting Descriptions Data Encryption TKIP Temporal Key Integrity Protocol (TKIP) is the standard encryption method used with WPA.
  • Page 58 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660  To configure the RADIUS server settings: Select Configuration > Security > Advanced > Radius Server Settings. The Radius Server Settings screen displays. Figure 30. Specify the settings as explained in the following table: Table 14.
  • Page 59 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 14. RADIUS server settings for IPv4 and IPv6 (continued) Setting Descriptions Secondary IPv4 Address or Enter the IP address of the secondary RADIUS server for Authentication Server IPv6 Address authentication.
  • Page 60: Restrict Wireless Access By Mac Address

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Restrict Wireless Access by MAC Address For increased security, you can restrict access to an SSID by allowing access to only specific computers or wireless stations based on their MAC addresses. You can restrict access to only trusted computers so that unknown computers cannot connect wirelessly to the wireless access point.
  • Page 61: Schedule The Wireless Radios To Be Turned Off

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Click Refresh to refresh the Available Wireless Stations table. The wireless access point places the MAC addresses of the attached wireless stations in this table. Populate the Trusted Wireless Stations table by one of the following methods: •...
  • Page 62: Configure Basic Wireless Quality Of Service

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 32. Specify the settings as explained in the following table: Table 15. Wireless radio on/off settings Setting Description Wireless On-Off Select the On radio button to enable the timer. By default, the Off radio button is selected.
  • Page 63 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 WMM defines the following four queues in decreasing order of priority: • Voice. The highest priority queue with minimum delay, which makes it ideal for applications like VoIP and streaming media.
  • Page 64: Chapter 4 Management And Monitoring

    Management and Monitoring This chapter describes how to use the management and monitoring features of the wireless access point. The chapter includes the following sections: • Enable Remote Management • Upgrade the Wireless Access Point Software • Manage the Configuration File or Reset to Factory Defaults •...
  • Page 65 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 34. Specify the settings as explained in the following table: Table 16. SNMP settings Setting Description SNMP Select the Enable radio button to allow the SNMP network management software, such as HP OpenView, to manage the wireless access point through SNMPv1/v2 protocol.
  • Page 66: Secure Shell And Telnet Management

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Secure Shell and Telnet Management  To configure remote console features: Select Maintenance > Remote Management > Remote Console. The Remote Console screen displays: Figure 35. Enable or disable the remote console features: •...
  • Page 67: Upgrade The Wireless Access Point Software

    The software of the wireless access point is stored in flash memory and can be upgraded as NETGEAR releases new software. You can download upgrade files from the NETGEAR website. If the upgrade file is compressed (.zip file), you first need to extract the image (.rmt) file before sending it to the wireless access point.
  • Page 68: Web Browser Upgrade Procedure

    Web Browser Upgrade Procedure  To use a web browser to upgrade the wireless access point firmware: Download the new software file from the NETGEAR website and save it to your hard disk. If necessary, unzip the new software file.
  • Page 69: Tftp Server Upgrade Procedure

     To use a TFTP server to upgrade the wireless access point firmware: Download the new software file from the NETGEAR website and save it to your hard disk. Place the software file in your TFTP server location. (You do not need to unzip the file.) If available, read the release notes before upgrading the software.
  • Page 70: Manage The Configuration File Or Reset To Factory Defaults

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Verify that the new software file has been installed by selecting Monitoring > System. The System screen displays (see Figure 46 on page 78). The firmware version is shown in the Access Point Information section of the screen.
  • Page 71: Restore The Configuration

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Restore the Configuration IMPORTANT: During the restoration process, do not try to go online, turn off the wireless access point, shut down the computer, or do anything else to the wireless access point until it finishes restarting! ...
  • Page 72 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Note: After you have restored the factory default settings on the wireless access point: * All custom configurations are lost. * The login password is password. * The default LAN IP address is 192.168.0.100.
  • Page 73: Reboot The Wireless Access Point Without Restoring The Default Configuration

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Use the Reset Button to Restore Factory Default Settings To restore the factory default settings when you do not know the login user name, login password, or IP address, you need to use the Reset button on the rear panel of the wireless...
  • Page 74: Change The Administrator Password

    Change the Administrator Password The default password is password. NETGEAR recommends that you change this password to a more secure password. You cannot change the administrator login name (admin).
  • Page 75: Manage User Accounts

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Manage User Accounts The admin user account is the default user account, which you cannot delete. However, you can add other user accounts, modify them, and delete them. Users for whom you set up an account can access the web management interface with read-only or read-write privileges.
  • Page 76: Enable The Syslog Server

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Click Apply to save your settings.  To change the name for a user account: On the User Accounts screen, in the lower part of the screen, select the user from the Existing Users drop-down list.
  • Page 77: Monitor The Wireless Access Point

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 45. Specify the settings as explained in the following table: Table 18. Syslog settings Setting Description Enable Syslog Select the check box to enable the syslog option. By default, the syslog option is disabled.
  • Page 78 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660  To view the System screen: Select Monitoring > System. Figure 46. Management and Monitoring...
  • Page 79 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 The following table explains the fields of the System screen: Table 19. System screen fields Setting Description Access Point Information Access Point Name The NetBIOS name. For information about how to change the default name, see Configure Basic General System Settings and Time Settings on page 23.
  • Page 80: Monitor Wireless Stations

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 19. System screen fields (continued) Setting Description DHCP Client Enabled indicates that the current IP address was obtained from a DHCPv6 server on your LAN network. Disabled indicates a static IP configuration.
  • Page 81 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 47. To update the list, click Refresh. If the wireless access point is rebooted, the wireless station data is lost until the wireless access point rediscovers the devices. To force the wireless access point to look for associated devices, click Refresh.
  • Page 82 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 The following table explains the fields of the Wireless Stations Details screen: Table 20. Wireless stations details fields Setting Description MAC Address The MAC address of the wireless station. BSSID The BSSID that the wireless station is using.
  • Page 83: View The Activity Log

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 View the Activity Log You can view the wireless access point’s activity logs onscreen and save the logs.  To display the activity log and save it: Select Monitoring > Logs. The Logs screen displays: Figure 49.
  • Page 84 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 50. To update the statistics information, click Refresh. The following table explains the fields of the Statistics screen: Table 21. Statistics fields Setting Description Wired Ethernet Packets The number of packets received and transmitted over the Ethernet connection since the wireless access point was restarted.
  • Page 85: Enable Rogue Ap Detection And Monitor Access Points

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 21. Statistics fields (continued) Setting Description Wireless 802.11b, Wireless 802.11bg, or Wireless 801.11ng Wireless 802.11a or Wireless 802.11na Note: The section heading depends on the configured wireless mode. Unicast Packets The number of unicast packets received and transmitted over the wireless connection since the wireless access point was restarted.
  • Page 86 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660  To enable and configure rogue AP detection: Select Configuration > Security > Advanced > Rogue AP. The Rogue AP screen displays. (The following figure shows examples in the Known AP List and Unknown AP List.)
  • Page 87: View And Save Access Point Lists

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660  To import a file with a precompiled list of access points into the Known AP List: Take one of the following actions: • Select the Replace radio button to let the imported list of access points replace the existing Known AP List.
  • Page 88 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 The following table explains the fields of the Unknown AP List screen: Table 22. Unknown AP List fields Setting Description MAC Address The MAC address of the unknown AP. SSID The SSID that the unknown AP is using.
  • Page 89: Configure Wireless Intrusion Detection And Prevention

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 The following table explains the fields of the Known AP List screen: Table 23. Known AP List fields Setting Description MAC Address The MAC address of the known AP. SSID The SSID that the known AP is using.
  • Page 90 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 24. IDS/IPS policies and policy rules Policy Description Policy Rule Threshold Notification Authentication flood • Attack. Multiple authentication requests (5 or more) that use Trap spoofed MAC addresses of legitimate clients are sent to the wireless access point.
  • Page 91 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 24. IDS/IPS policies and policy rules (continued) Policy Description Policy Rule Threshold Notification Disassociation flood • Attack. Multiple disassociation frames (5 or more) that use the Trap spoofed MAC address of the wireless access point are sent to a legitimate client.
  • Page 92 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 24. IDS/IPS policies and policy rules (continued) Policy Description Policy Rule Threshold Notification CTS flood • Attack. Multiple clear-to-send (CTS) frames (60 or more) are Trap sent to the wireless access point.
  • Page 93 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 24. IDS/IPS policies and policy rules (continued) Policy Description Policy Rule Threshold Notification Ad-hoc network • Detection. A group of wireless access points are part of an Trap detected ad hoc network that might broadcast the same SSID as the secured wireless network.
  • Page 94 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 24. IDS/IPS policies and policy rules (continued) Policy Description Policy Rule Threshold Notification Device probing for • Detection. Multiple probe requests (30 or more) are sent to Trap access points collect information about the wireless access point for possible future attacks.
  • Page 95: Configure Wireless Intrusion Detection And Prevention Mail Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Specify the detection policy by making a selection from the IDS/IPS Detection Policy drop-down list: • Mild. The wireless access point scans for attacks every 10 seconds. • Moderate. The wireless access point scans for attacks every 5 seconds. This is the default setting.
  • Page 96: Monitor Traps, Counters, And Ad Hoc Networks

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 25. IDS/IPS mail settings (continued) Setting Description The port number of the outgoing email SMTP server of your ISP. The default Port Number port number is 25. This server requires...
  • Page 97: Ad Hoc Networks

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 The following table explains the fields of the Traps screen: Table 26. Traps fields Setting Description Attack Name The name of the attack that corresponds to a policy in Table 24 on page 90.
  • Page 98 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Attack Counter  To display the number of occurrences per attacks: Select Monitoring > IPS/IDS > Counters. The Counters screen displays. Figure 58. To update the information onscreen, click Refresh.
  • Page 99: Chapter 5 Advanced Configuration

    Advanced Configuration This chapter describes how to configure the advanced features of the wireless access point. The chapter includes the following sections: • Configure IPv6 Settings and Optional DHCPv6 Server Settings • Configure Spanning Tree Protocol, 802.1Q VLAN, and Link Layer Discovery Protocol •...
  • Page 100 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 WARNING: If you enable the DHCP client, the IP address of the wireless access point changes when you click Apply, causing you to lose your connection to the wireless access point. You then need to use the new IP address to reconnect to the wireless access point.
  • Page 101: Configure The Optional Dhcpv6 Server

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 28. IPv6 settings (continued) Setting Description Default Gateway Enter the IPv6 address of the ISP gateway to which the wireless access point connects. Dynamic IPv6 Address The dynamic IPv6 address that is assigned by the DHCPv6 server on your network.
  • Page 102 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 60. Configure the settings as explained in the following table: Table 29. DHCP server settings for IPv6 Setting Description Select the DHCPv6 Server Enable radio button to enable the DHCP server. Use the default settings or specify the pool of IPv6 addresses to be assigned by setting the starting IPv6 address and ending IPv6 address.
  • Page 103: Configure Spanning Tree Protocol, 802.1Q Vlan, And Link Layer Discovery Protocol

    Configure STP and VLANs STP provides network traffic optimization in locations where multiple wireless access points are active by preventing path redundancy. NETGEAR recommends that you enable STP if you have more than one active wireless access point at your location.
  • Page 104 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Note: Select the Untagged VLAN check box only if the hubs and switches on your LAN support the 802.1Q VLAN protocol. Likewise, change the untagged VLAN value only if the hubs and switches on your LAN support the 802.1Q VLAN protocol.
  • Page 105: Configure Ethernet Lldp

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Specify the settings as explained in the following table: Table 30. STP and VLAN settings Setting Description Spanning Tree Protocol Spanning Tree Protocol Select the Enable radio button to enable STP to prevent path redundancy. By default, the Disable radio button is selected.
  • Page 106: Configure Hotspot Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 62. Select the Disable radio button. By default, the Enable radio button is selected. Click Apply to save your settings. Configure Hotspot Settings If the wireless access point functions as a public access point and you want it to capture and redirect all HTTP requests (over TCP, port 80), set up a hotspot server to redirect the requests to the specified URL and manage the clients.
  • Page 107: Configure Advanced Wireless Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 63. To enable HTTP redirection, select the Enable radio button. By default, the Disable radio button is selected. In the Redirect URL field, enter the URL of the web server to which you wish to redirect HTTP requests.
  • Page 108 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 64. Optional: To configure advanced wireless settings for the 802.11a/na modes, click the 802.11a/na tab. Specify the settings as explained in the following table: Table 31. Advanced wireless settings...
  • Page 109 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 31. Advanced wireless settings (continued) Setting Description Fragmentation Length (256–2346) Enter the maximum packet size that is used for the fragmentation of data packets. Packets that are larger than the specified fragmentation length are broken up into smaller packets before being transmitted.
  • Page 110 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 31. Advanced wireless settings (continued) Setting Description Client Isolation From the drop-down list, select one of the following options: • Enable. Communication between wireless clients that are associated to different virtual access points (VAPs) is blocked.
  • Page 111: Configure Advanced Quality Of Service Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Configure Advanced Quality of Service Settings For most networks, the default Quality of Service (QoS) queue settings work well. For information about how to configure basic QoS, see Configure Basic Wireless Quality of Service on page 62.
  • Page 112 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 65. Optional: To configure advanced QoS for the 802.11a/na modes, click the 802.11a/na tab. Specify the settings as explained in the following table: Table 32. EDCA settings Setting Description...
  • Page 113: Configure Quality Of Service Policies

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 32. EDCA settings (continued) Setting Description Max. Burst Enter the maximum burst value that specifies the maximum burst length (in microseconds) allowed for packet bursts on the wireless network. A packet burst is a collection of multiple frames transmitted without header information.
  • Page 114 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • EtherType. Indicates the EtherType field in Ethernet-II frame header. • Source MAC. Indicates the source MAC address in Ethernet-II frame header. • Destination MAC. Indicates the destination MAC address in Ethernet-II frame header.
  • Page 115 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Specify a classification for the QoS policy as explained in the following table. Note: Depending on your selection from the Match Frame Fields drop-down list, Match Classifications appears either as a drop-down list from which you need to make a selection or a field in which you need to enter information.
  • Page 116 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 33. QoS classification settings (continued) Setting Description Match Frame 802.1P From the Match Classifications drop-down list, select the CoS priority Fields and Match value against which the information in the IP header needs to be...
  • Page 117 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 33. QoS classification settings (continued) Setting Description Match Frame Source IP In the Match Classifications field, enter the source IP address against Fields and Match which the information in the IP header needs to be matched.
  • Page 118 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Note: Rate limiting for the wireless interface is an optional setting that applies to all traffic on the wireless interface. Unlike classification rate limiting, which you can specify for each classification, rate limiting for the wireless interface needs to be specified only once.
  • Page 119: Configure Wireless Bridging

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Configure Wireless Bridging • Configure a Point-to-Point Wireless Network • Configure a Point-to-Multipoint Wireless Network • Configure the Wireless Access Point to Repeat the Wireless Signal Using Point-to-Multipoint Bridge Mode The wireless access point supports a wireless distributing system (WDS) that lets you build large bridged wireless networks.
  • Page 120 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Wireless PC card in a notebook computer Wireless PC card in a notebook computer Point-to-point Point-to-point bridge mode bridge mode Router Hub or switch Figure 67.  To configure a point-to-point wireless network:...
  • Page 121 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 e. If you want to enable wireless client association while the wireless access point functions as a point-to-point bridge, select the Enable Wireless Client Association check box. f. Click Edit to configure the security profile settings. The Edit Security Profile screen displays: Figure 69.
  • Page 122 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 36. Point-to-point bridge profile and authentication settings (continued) Setting Description Network Open System Although you can use the bridge communication without any Authentication and authentication and encryption, NETGEAR recommends that Data Encryption you use WEP if you do select an open system.
  • Page 123: Configure A Point-To-Multipoint Wireless Network

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 A computer on either LAN segment should be able to connect to the Internet or share files and printers of any other computers or servers connected to LAN Segment 1 or LAN Segment 2.
  • Page 124 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 71. b. Optional: To display the Bridging screen for the 802.11a/na modes, click the 802.11a/na tab. c. Select the Enable Wireless Bridging check box. The Local MAC Address field is a nonconfigurable field that shows the MAC address of the wireless access point.
  • Page 125 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 g. Specify the settings as explained in the following table: Table 37. Point-to-multipoint bridge profile and authentication settings Setting Description Profile Definition Profile Name Enter a profile name that is easy to remember. The default names for the four security profiles are NETGEAR-WDS-1, NETGEAR-WDS-2, NETGEAR-WDS-3, and NETGEAR-WDS-4.
  • Page 126 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 For example, first configure security profile NETGEAR-WDS-1 with the MAC address of AP2, and then configure security profile NETGEAR-WDS-2 with the MAC address of AP3 (see Figure 70 on page 123).
  • Page 127: Configure The Wireless Access Point To Repeat The Wireless Signal Using Point-To-Multipoint Bridge Mode

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Note: You can extend this multipoint bridging configuration by adding additional wireless access points that are configured in point-to-point mode for each additional LAN segment. Furthermore, you can extend the range of the wireless network with NETGEAR wireless antenna accessories.
  • Page 128 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660  To configure the wireless access point to repeat the wireless signal: Configure the security profiles on the wireless access point (AP2 in the previous figure): a. Select Configuration > Wireless Bridge. The Bridging screen displays (see the following figure).
  • Page 129 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Figure 75. g. Specify the settings as explained in the following table: Table 38. Wireless signal repeating profile and authentication settings Setting Description Profile Definition Profile Name Enter a profile name that is easy to remember. The default names for the four security profiles are NETGEAR-WDS-1, NETGEAR-WDS-2, NETGEAR-WDS-3, and NETGEAR-WDS-4.
  • Page 130 Step h for any other security profile that you want to edit. For example, first configure security profile NETGEAR-WDS-1 with the MAC address of AP1, and then configure security profile NETGEAR-WDS-2 with the MAC address of AP3 (see Figure 73 on page 127).
  • Page 131 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Verify the following for all wireless access points: • All APs are on the same LAN, that is, the LAN IP addresses of all APs are in the same network as the LAN devices.
  • Page 132: Chapter 6 Troubleshooting

    Troubleshooting This chapter provides information about troubleshooting the wireless access point. After each problem description, instructions are given to help you diagnose and solve the problem. For the common problems listed, go to the section indicated. • Is the wireless access point on? Go to Basic Functioning on page 133.
  • Page 133: Basic Functioning

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Basic Functioning • Verify the Correct Sequence of Events at Startup • No LEDs Are Lit on the Wireless Access Point • The Active LED or the LAN LED Is Not Lit •...
  • Page 134: The Active Led Or The Lan Led Is Not Lit

    If it is plugged directly into the wall, verify that it is not a switched outlet. • Make sure that you are using the correct NETGEAR power adapter that is supplied with your wireless access point. The Active LED or the LAN LED Is Not Lit There is a hardware connection problem.
  • Page 135: You Cannot Access The Internet Or The Lan From A Wireless-Capable Computer

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 You Cannot Access the Internet or the LAN from a Wireless-Capable Computer There is a configuration problem.  Check these items: • You might not have restarted the computer with the wireless adapter to allow TCP/IP changes take effect.
  • Page 136: When You Enter A Url Or Ip Address A Time-Out Error Occurs

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • Make sure that your browser has Java, JavaScript, or ActiveX enabled. If you are using Internet Explorer, click Refresh to be sure that the Java applet is loaded. •...
  • Page 137: Test The Lan Path To Your Wireless Access Point

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Test the LAN Path to Your Wireless Access Point You can ping the wireless access point from your computer to verify that the LAN path to your wireless access point is set up correctly.
  • Page 138: Test The Path From Your Computer To A Remote Device

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Test the Path from Your Computer to a Remote Device After verifying that the LAN path works correctly, test the path from your computer to a remote device. From the Windows toolbar, click the Start button, and select Run.
  • Page 139: Use The Packet Capture Tool

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Use the Packet Capture Tool You can capture wireless packets to analyze traffic patterns with a network traffic analyzer tool. The captured packet flow can show if traffic is flowing correctly to its destinations or if packets are dropped.
  • Page 140: Appendix A Supplemental Information

    Supplemental Information This appendix provides factory default settings and technical specifications for the ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660. The appendix includes the following sections: • Technical Specifications • Factory Default Settings Technical Specifications Table 39. Technical specifications...
  • Page 141 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 39. Technical specifications (continued) Feature Description 802.11ng MCS index and Data rates for a 40 MHz channel width and a long guard interval (800 ms): data rates 0 / 13.5 Mbps, 1 / 27 Mbps, 2 / 40.5 Mbps, 3 / 54 Mbps, 4 / 81 Mbps, 5 / 108 Mbps, (continued) 6 / 121.5 Mbps, 7 / 135 Mbps, 8 / 27 Mbps, 9 / 54 Mbps, 10 / 81 Mbps,...
  • Page 142 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 39. Technical specifications (continued) Feature Description 802.11a/na • 5.180–5.240 GHz (US, lower frequencies) operating frequencies • 5.260–5.320 GHz (US, middle frequencies) • 5.180–5240 GHz (CE [EU], lower frequencies) •...
  • Page 143: Factory Default Settings

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Factory Default Settings You can use the Reset button located on the rear of the wireless access point to reset all settings to their factory defaults. This is called a hard reset.
  • Page 144 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 40. Default configuration settings (continued) Feature Description Hotspot Disabled Secure Telnet Disabled Time zone USA-Pacific NTP client Enabled Custom NTP server Disabled Port speed 10/100/1000 Ethernet MAC address See bottom label...
  • Page 145 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 40. Default configuration settings (continued) Feature Description Wireless modes 11ng 11na Wireless network names (SSIDs) NETGEAR_11ng NETGEAR_11na Broadcast network names (SSIDs) Enabled Radio frequency channels 11ng: Auto 11na: Auto...
  • Page 146 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Table 40. Default configuration settings (continued) Feature Description WMM powersave Enabled AP EDCA parameters (QoS settings) Table 32 on page 112. Station EDCA parameters (QoS settings) QoS policies None Wireless bridging...
  • Page 147: Appendix B Command-Line Reference

    Command-Line Reference The wireless access point can be configured through either the command-line interface (CLI), a web browser, or a MIB browser. The CLI allows viewing and modification of the configuration from a terminal or computer through a Telnet or SSH connection. Keyword Description ------------------------------------------------------------------------------...
  • Page 148 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | |-smtp-server-authentication --SMTP server status | | |-username --Username of the Administrator/superuser | | |-password --Password of the Administrator/superuser | | |-send-notifications --Administrator/superuser mail address | |-interface> --Select wireless lan interface | | |-wlan>...
  • Page 149 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | |-ssid --Network name (1-32 chars) | | | | | | |-status --Profile status | | | | | | |-vlan-id --VLAN id | | | | | | |-wep-pass-phrase...
  • Page 150 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | |-delete-outgoing-QoSpolicy --Delete outgoing QoS policy | | | | | | | | | | | |-4> --4th security profile | | | | | | |-authentication...
  • Page 151 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | |-key3 --Wireless wep key 3 | | | | | | |-key4 --Wireless wep key 4 | | | | | | |-keyno --Key number...
  • Page 152 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | |-vlan-id --VLAN id | | | | | | |-wep-pass-phrase --Wireless wep passphrase key | | | | | | |-wepkeytype --Wireless wep key type...
  • Page 153 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | | |-authentication --Authentication type | | | | | | | |-encryption --Data encryption | | | | | | | |-name --Profile name...
  • Page 154 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | |-5GHz> --5.0 GHz wireless LAN interface setting | | | | |-aggregation-length --Aggregated packet size | | | | |-ampdu --Aggregated MAC Protocol Data Unit | | | | |-beacon-interval...
  • Page 155 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | |-delete-incoming-QoSpolicy --Delete incoming QoS policy | | | | | | |-delete-outgoing-QoSpolicy --Delete outgoing QoS policy | | | | | | | | | | | |-2>...
  • Page 156 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | |-key2 --Wireless wep key 2 | | | | | | |-key3 --Wireless wep key 3 | | | | | | |-key4 --Wireless wep key 4...
  • Page 157 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | |-status --Profile status | | | | | | |-vlan-id --VLAN id | | | | | | |-wep-pass-phrase --Wireless wep passphrase key | | | | | | |-wepkeytype...
  • Page 158 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | | | | | | | | | | |-ids-ips-profile> | | | | | |-ips-status --IDS/IPS (Intrusion detection & prevention system) status | | | | | |-ips-detection-policy --IDS/IPS (Intrusion detection &...
  • Page 159 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | | | | |-wep-pass-phrase --Wireless wep passphrase key | | | | | | | |-wepkey --Wireless wep key | | | | | | | |-wepkeytype...
  • Page 160 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | |-default-gateway --IPv6 address of default gateway | | |-dhcp-client --Enable dhcpv6 client | | |-dns-server --IPv6 address of DNS server | | |-network-integrity-check | |-log> --Syslog setting | | |-syslog-status...
  • Page 161 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | |-read-community --SNMP ReadCommunity | | |-snmp-status --SNMP status | | |-trap-community --SNMP ReadCommunity | | |-trap-server --SNMP TrapServer IP address | | |-write-community --SNMP WriteCommunity --Enable spanning tree protocol | |-spanning-tree | |-time>...
  • Page 162 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 | | | | |-trusted-stationlist --Trusted station list | | | | |-knownaplist --Known access point list | | | | |-unknownaplist --Unknown access point list | | | | |-ids-ips-statistics...
  • Page 163: Appendix C Notification Of Compliance

    European Union (1999/5/EC). This equipment meets the following conformance standards: EN300 328 (2.4 GHz), EN301 489-17, EN301 893 (5 GHz), EN60950-1 For complete DoC please visit the NETGEAR EU Declarations of Conformity website at http://support.netgear.com/app/answers/detail/a_id/11621/. EDOC in Languages of the European Community...
  • Page 164 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Español [Spanish] Por medio de la presente NETGEAR Inc. declara que el Radiolan cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική [Greek] ΜΕ...
  • Page 165 We, NETGEAR, Inc., 350 East Plumeria Drive, San Jose, CA 95134, declare under our sole responsibility that the ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 complies with Part 15 Subpart B of FCC CFR47 Rules. Operation is subject to the following two conditions: •...
  • Page 166: Industry Canada

    ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 • This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. • For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules.
  • Page 167 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Avertissement Les dispositifs fonctionnant dans la bande 5150 - 5250 MHz sont réservés uniquement pour une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.
  • Page 168: Index

    Index Numerics Arbitration Inter-Frame Spacing (AIFS) interval associated identifier (AID) 11a and 11na wireless modes association flood and table overflow 11b, 11bg, and 11ng wireless modes associations, wireless clients 2.4 GHz antenna, connectors for attacks 2.4 GHz or 5 GHz operation detecting and preventing 64-bit, 128-bit, and 152-bit WEP monitoring...
  • Page 169 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 monitoring data rates 802.11a mode – burst rate, QoS policies 802.11b/bg modes bytes, received and transmitted – specifications for all modes Ethernet connection date and time, troubleshooting wireless connection deauthentication broadcast attack...
  • Page 170 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 Ethernet packets and bytes, received and transmitted installation order extended service set (ESS) interface rate limiting and burst rate Extensible Authentication Protocol EAPOL) attacks interference external antennas internal antenna, disabling...
  • Page 171 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 lease mail sender DHCPv4 NTP server DHCPv6 profiles QoS policies LEDs SNMP communities behavior users described wireless access point troubleshooting wireless network (SSID for 802.11a/na modes) legacy 802.1X (wireless security) wireless network (SSID for 802.11b/bg/ng modes)
  • Page 172 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 RADIUS servers received signal strength indicator (RSSI) SNMP manager, traps redirecting HTTP requests syslog server Reduced Interframe Space (RIFS) transmission power adapter specifications region, wireless location power redundancy registering product...
  • Page 173 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 software statistics backing up WMM QoS factory defaults traffic classes, QoS policies restoring from backup file transmission opportunity (TXOP) limit upgrading transmission output power version, viewing 2.4 GHz radio source port, QoS policies...
  • Page 174 ProSafe Premium 3 x 3 Dual-Band Wireless-N Access Point WNDAP660 video traffic 2.4 GHz band advanced QoS 5 GHz band WMM QoS monitoring virtual access points (VAPs) wireless network name (SSID) broadcasting virtual carrier attack broadcasting and security VLANs broadcasting for 802.11a/na modes DHCPv4 server VLAN ID broadcasting for 802.11b/bg/ng modes...

Table of Contents
