AG-HPX600 SPECIFICATIONS
General Specification
Supply Voltage:
DC 12 V (DC 11 V to 17 V)
Power Consumption:
18 W (main unit only)
22 W (with AG-YDX600G and AG-YA600G)
Operating Temperature:
0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity:
10% to 85% (no condensation)
Keeping Temperature:
−20 °C to 60 °C (−4 °F to 140 °F)
Weight:
Approx. 2.8 kg (6.2 lb) excluding battery and accessories
Dimensions (W x H x D):
144 mm x 267 mm x 350 mm
(5-21/32 inches x 10-1/2 inches x 13-25/32 inches)
excluding prominent parts
Camera Section
Pick-up Device:
2/3-type MOS x 1
Lens Mount:
2/3-type bayonet type
ND Filter:
4 position (Clear, 1/4ND, 1/16ND, 1/64ND)
Gain Selection*
:
−3 dB, 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 18 dB
1
(18 dB: USER SW allocation)
Color Temperature Settings: ATW, ATW LOCK, Ach, Bch,
Preset 3200 K/Preset 5600 K/VAR (2400K to 9900K )
Shutter Speed:
SYSTEM MODE = 59.94 Hz
(Preset)
•60i/60p mode: 1/60 (OFF) sec., 1/100 sec., 1/120 sec.,
1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec.
•30p mode: 1/30 (OFF) sec., 1/50 sec., 1/60 sec.,
1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec.
•24p mode: 1/24 (OFF) sec., 1/50 sec., 1/60 sec.,
1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec.
SYSTEM MODE = 50 Hz
•50i/50p mode: 1/50 (OFF ) sec., 1/60 sec., 1/120 sec.,
1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec.
•25p mode: 1/25 (OFF ) sec., 1/50 sec., 1/60 sec.,
1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec.
Shutter Speed:
SYSTEM MODE = 59.94 Hz
(Slow)
•60i/60p mode:
•30p mode:
•24p mode:
SYSTEM MODE = 50 Hz
•50i/50p mode:
•25p mode:
Shutter Speed:
SYSTEM MODE = 59.94 Hz (SYNC SCAN TYPE = sec)
(Syncro Scan)
•60i/60p mode:
•30p mode:
•24p mode:
SYSTEM MODE = 50 Hz (SYNC SCAN TYPE = sec)
•50i/50p mode:
•25p mode:
Shutter Open Angle:
SCENE FILE VFR = OFF
SCENE FILE VFR = ON*
SCENE FILE VFR = ON*
Frame Rates*
:
•1080: 1/2/4/6/9/12/15/18/20/21/22/24/25/26/27/28/30
2
(59.94 Hz mode)
(frames per second) 17 steps
•720: 1/2/4/6/9/12/15/18/20/21/22/24/25/26/27/28/
30/32/34/36/40/44/48/54/60 (frames per second)
25 steps
Frame Rates*
2
:
•1080: 1/2/4/6/9/12/15/18/20/21/22/23/24/25
(50 Hz mode)
(frames per second) 14 steps
•720: 1/2/4/6/9/12/15/18/20/21/22/23/24/25/26/27/
28/30/32/34/37/42/45/48/50 (frames per second)
25 steps
Sensitivity*
3
:
F12 (2000 lx, 3200 K, 89.9% reflect, 1080/59.94i)
F13 (2000 lx, 3200 K, 89.9% reflect, 1080/50i)
Video S/N*
:
59 dB (standard)
3
Digital Zoom:
x 2, x 4
Memory Card Recorder Section
Recording Media:
P2 card
System Formats:
1080/59.94i, 1080/23.98PsF*
480/59.94i, 1080/50i, 720/50p, 576/50i
Recording Video Signal:
1080/59.94i, 1080/29.97p, 1080/29.97pN,
1080/23.98p, 1080/23.98pA, 1080/23.98pN,
1080/50i, 1080/25p, 1080/25pN,
720/59.94p, 720/29.97p, 720/29.97pN,
720/23.98p, 720/23.98pN,
720/50p, 720/25p, 720/25pN,
480/59.94i, 480/29.97p, 480/23.98p, 480/23.98pA,
576/50i, 576/25p
Recording Formats:
AVC-Intra100/AVC-Intra50/DVCPRO HD/
DVCPRO 50/DVCPRO/DV formats switchable
1/15 sec., 1/30 sec.
1/15 sec.
1/12 sec.
1/12.5 sec., 1/25 sec.
1/12.5 sec.
1/60.0 sec. to 1/249.8 sec.
1/30.0 sec. to 1/249.8 sec.
1/24.0 sec. to 1/249.8sec.
1/50.0 sec. to 1/250.0 sec.
1/25.0 sec. to 1/250.0 sec.
3 deg to 360 deg, 0.5 deg step select
(FRAME RATE 12p or more)
2
3 deg to 360 deg, 0.5 deg step select
2
(Less than FRAME RATE 12p)
3 deg to 22.5 deg, 0.5 deg step select
45 deg, 90 deg, 180 deg, 360 deg
2
, 720/59.94p,
Recording/Playback Time*
: AVC-Intra100/DVCPRO HD:
4
with a 64 GB P2 card
AVC-Intra50/DVCPRO 50:
DVCPRO/DV:
Recording/Playback Time*
4
: AVC-Intra100/DVCPRO HD:
with a 32 GB P2 card
AVC-Intra50/DVCPRO 50:
DVCPRO/DV:
Recording/Playback Time*
4
: AVC-Intra100/DVCPRO HD:
with a 16 GB P2 card
AVC-Intra50/DVCPRO 50:
DVCPRO/DV:
Digital Video Specification
Recorded Video Signals:
AVC-Intra100/DVCPRO HD:
Y: 74.1758 MHz, P
Y: 74.2500 MHz, P
DVCPRO 50: Y: 13.5 MHz, P P
DVCPRO: Y: 13.5 MHz, P
Quantizing:
AVC-Intra100/AVC-Intra50: 10 bit
DVCPRO HD/DVCPRO 50/DVCPRO/DV: 8 bit
Video Compression:
AVC-Intra100/AVC-Intra50:
MPEG-4 AVC/H.264 Intra Profile
DVCPRO HD: DV-Based Compression (SMPTE 370M )
DVCPRO 50/DVCPRO: DV-Based Compression (SMPTE 314M)
DV: DV Compression (IEC 61834-2)
Digital Audio Specification
Recording Audio Signal:
AVC-Intra100/AVC-Intra50: 48 kHz, 16 bit, 4CH
DVCPRO HD/DVCPRO 50: 48 kHz, 16 bit, 4CH
DVCPRO/DV: 48 kHz, 16 bit, 2CH/4CH switchable
Headroom:
20 dB/18 dB switching via menu
Video Input/Output
SDI OUT/IN (OP )*
5
:
BNC×1
HD SDI: 0.8 V [p-p], 75 Ω SD SDI: 0.8 V [p-p], 75 Ω
MON OUT:
BNC×1, HD SDI/SD SDI/VBS (Analog Composite)
can be switched on SmatUI
HD SDI: 0.8 V [p-p], 75 Ω / SD SDI: 0.8 V [p-p], 75 Ω /
VBS: 1.0 V [p-p], 75 Ω
HDMI OUT:
HDMI x 1 (HDMI TypeA terminal),
VIERA Link not supported
Audio Input/Output
AUDIO IN:
XLR (3 pin) x 2
LINE/MIC switchable, high impedance,
LINE: 0 dBu, MIC:−50 dBu/−60 dBu (switching via menu)
MIC +48 V ON/OFF (switchable)
MIC IN:
XLR (3 pin) x 1
+MIC/+48 V switchable,
−40 dBu/−50 dBu/−60 dBu (switching via menu)
WIRELESS IN:
25 pin, D-SUB, −40 dBu 2CH supported
AUDIO OUT:
Pin jack × 2 (CH1/CH2), Output: 316 mV, 600 Ω
PHONES OUT:
ø3.5 mm stereo mini jack × 1
Speaker:
20 mm diameter × 1
Other Input/Output
GENLOCK IN:
BNC × 1, 1.0 V [p-p], 75 Ω
TC IN/OUT:
IN: BNC × 1, 0.5 V [p-p] to 8V [p-p], 10 kΩ
OUT: BNC × 1, 2.0 V ±0.5 V [p-p], low impedance
(IN/OUT switching via menu)
DC IN:
XLR × 1, 4 pin, DC 12 V (DC 11.0 V to 17.0 V )
DC OUT:
4 pin, DC 12 V (DC 11.0 V to 17.0 V ), Max. 1.5 A
REMOTE:
10 pin
LENS:
12 pin
VF:
20 pin
LAN*
6
:
100BASE-TX/10BASE-T
USB 2.0 (HOST ):
Type-A, 4 pin USB ver 2.0 Standard
USB 2.0 (DEVICE ):
Type-B, 4 pin USB ver 2.0 Standard
USB 2.0 (HOST )*
:
Type-A, 4 pin USB ver 2.0 Standard
6
for Wireless Module AJ-WM30
Included Accessories
Shoulder strap, Mount cap*
, CD-ROM
7
*1: When SHOOTING MODE is NORMAL on SYSTEM SETUP MENU, –3 dB setting is treated as 0dB and
18dB setting can not be active. *2: AG-SFU602 Upgrade Software Key is required. *3: When SHOOTING
MODE is LOW LIGHT on SYSTEM SETUP MENU *4: Time shown above is when you record a series of 1 shot
onto P2 card. Depending on numbers of shots you record, time will get shorter than the number shown
above. *5: Mounting the optional AG-YA600G HD/SD SDI Input Board makes this system SDI Input.
(SDI OUT/IN switching via menu) *6: When Upgrade Software Key AG-SFU601 is installed, the network
function of cable LAN and wireless LAN becomes effective. *7: It is attached to the main body.
Weight and dimensions shown are approximate. Specifications are subject to change without notice.
As of August, 2012
approx. 64 min.
approx. 128 min.
approx. 256 min.
approx. 32 min.
approx. 64 min.
approx. 128 min.
approx. 16 min.
approx. 32 min.
approx. 64 min.
/P
: 37.0879 MHz (59.94 Hz )
B
R
/P
: 37.1250 MHz (50 Hz )
B
R
/P
: 6.75 MHz
B
R
/P
: 3.375 MHz
B
R
6
