Panasonic P2 cam AG-HPX600 Brochure & Specs page 5

Expandability
Proxy Recording, Network Functions, and a Variable Frame Rate.
This Expandable System Lets You Add Only the Functions You Need.
Revolutionary Workflow with
High-Resolution Proxy Video and Network Options
High-Resolution Proxy Video Supported
(With the optional AG-YDX600G Video Encoder Board)
With this option, the AG-HPX600 records proxy files onto SD/SDHC
memory cards or onto P2 cards.* It supports high-quality video (Quick
Time/H.264) and audio formats at a low bit rate. High-quality proxy
files can be used for breaking news and other scenarios that would
benefit from proxy workflows. Moreover, it streamlines the production
workflow by allowing the editor to review the content details during
offline editing.
* Proxy data cannot be recorded when using the Loop Rec or Interval Rec function. Proxy data is
low-resolution video and audio data with time code, metadata, and other management data in a file
format. Use of DCF Technologies under license from Multi-Format, Inc.
Streaming with a Wireless or Wired LAN
(With the optional AJ-SFU601G Upgrade Software
Network
Key and AJ-WM30 Wireless Module)
These options enable use of a wireless or wired
(Ethernet) LAN. Proxy files* can be streamed or viewed
1
via a standard web browser on a PC/Mac, tablet, or
smartphone.* 2 While viewing the streamed files,
metadata can be added to the P2 files. Using a PC/Mac
also enables a cloud-based workflow by uploading and
sharing video data via a network.
*1: The optional AG-YDX600G Video Encoder Board is required to use proxy video.
*2: For the latest information, see "Service and Support" on the Panasonic
website (http://pro-av.panasonic.net/).
The VFR Option for Cinema Production Use
Variable Frame Rate Shooting and 24PsF Output
(With the optional AG-SFU602G Production Package Upgrade
Software Key)
In 720p mode, the frame rate can be set in the range of 1 fps-60 fps,
and in 1080p mode it can be set to 1 fps-30 fps. This allows the use of
undercranking and overcranking to create fast-motion and slow-
motion effects. Either 24p/30p Native mode or over 60p mode can be
selected for recording. In addition, the 24PsF format can be output
from SDI OUT for uncompressed data recording.
Cinema
picture simulated
AJ-WM30
AG-HPX600
Wireless Module
Shown above is a sample
Tablet terminal
such as iPad
Smartphone*
such as iPhone
Wireless LAN
Portable media player*
IEEE802.11b/g
such as iPod Touch
PC such as
Panasonic Toughbook
MacBook Air etc.
Ethernet
of operation style.
1
1
4
