Related Manuals for Oregon Scientific BPW128
Summary of Contents for Oregon Scientific BPW128
- Page 1 LOG BOOK Age: Weight: kg/lbs 21.2 22.2 10:05 10:12 mmHg / min...
- Page 2 LEGEND : - FAST INCREMENT LEGENDA : - INCREMENTO RAPIDO - FLASHING - LAMPEGGIANTE BOLD - PRESS BUTTON BOLD - PREMERE IL PULSANTE BOLD BOLD - PRESS AND HOLD BUTTON - TEMERE PREMUTO IL PULSANTE LEGENDE : - AUGMENTATON RAPIDE LEYENDA : - INCREMENTO RÁPIDO - DESTELLANDO...
- Page 3 HOW TO TAKE MEASUREMENT Fig1 Fig1 2sec...
- Page 4 HOW TO RECALL VALUES FROM MEMORY Fig 2 2sec...
-
Page 5: How To Set The Time
HOW TO SET THE TIME Fig 3 mode... - Page 6 Thank you for purchasing the Wrist Blood-Pressure Monitor pressure measuring systems. It is therefore not subject to (BPW128). This unit has been constructed using reliable circuitry calibration regulations and does not bear a calibration stamp. and durable materials. Used properly, this unit will provide years of The CE mark further indicates that this blood pressure monitor satisfactory use.
- Page 7 DESCRIPTION AND FUNCTION OF PARTS A. Liquid Crystal Display (LCD) and protective cover - Large easy-reading display - 5 functional symbols - Systolic [SYS/mmHg], Diastolic [DIA/mmHg], Mean [MAP/mmHg], Pulse [pul/min.]and date & time display. B. Battery compartment Houses two (2) LR03 /AAA/ UM4 size 1.5V batteries Button - For time adjustment.
-
Page 8: Display-Symbol Description
DISPLAY-SYMBOL DESCRIPTION INSTALLING BATTERIES 1. Slide battery cover off. 2. Install battery first. Ensure Symbol Description Explanation correct polarity. Battery Type: 2 Alkaline LR03 (AAA)size Appears when Memory Mark 3. Replace the cover. measurement value is recalled from memory Replace the batteries if: 1. - Page 9 PROPER EQUIPMENT SETUP 1. Remove all watches, jewelry, etc. prior to attaching the wrist monitor. Clothing sleeves should be rolled up and the cuff should be wrapped on bare skin for correct measurements. 2. Apply cuff to left wrist with palm facing up. 3.
-
Page 10: What Is Mean Arterial Pressure
WHAT IS MEAN ARTERIAL PRESSURE BLOOD PRESURE DEFINITIONS (MAP) Information obtained from the World Health Organization (WHO) The Mean Blood Pressure is the average pressure forcing blood through the arteries. It is not the average of the systolic and diastolic Hypertension systolic over 160 blood pressure. - Page 11 HOW TO TAKE MEASUREMENT MEASUREMENT Refer to Fig1 With the individual in a sitting position and with the cuff attached as Note: previously mentioned, a blood pressure reading can be obtained. a. To interrupt the measurement, simply press button. The cuff will deflate immediatey after the button is pressed.
-
Page 12: Automatic Power Off
MAINTENANCE, CLEANING AND CARE AUTOMATIC POWER OFF The device will automatically switches off after about 1 minute. When handled properly, this unit is engineered to give years of However, to conserve battery power, press the button when satisfactory service. finished to turn the unit off. Here are a few product care instructions: - When not in use, store the unit in the protective plastic container provided with your purchase. -
Page 13: Specifications
SPECIFICATIONS SYMBOL DESCRIPTIONS Measuring method : Oscillometric / non-invasive Please observe user’s manual Application : Adults Measurement location : Wrist section of lower arm Protection class BF Circumference (approx. ) 13.5 – 19.5 cm Pressure Measuring range : 30 - 280mmHg DC (Direct current) Pulse Measuring Range : 30 - 200 pulse/min... - Page 14 IMPORTANT ADVICE - RETAIN FOR FUTURE REFERENCE Note: This device is intended for adult use only. Do not use For meaningful comparisons, it is suggested to measure the blood this unit on children without first consulting a physician. pressure under similar conditions. For example, daily measurements should be taken at approximately the same time or as suggested by a medical professional.
