Copper Chimney
Copper Chimney
For Outdoor
Use Only
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
Outdoor Fireplace
WARNING
Do not use this unit on a wood deck or on combustible
surfaces such as dry grass, leaves, mulch, etc. Do not
use this unit near heat sensitive or combustible structures
such as vinyl or wood siding.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out in breezy conditions. Adequate fire extinguishing
material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
04501116
04201101
42803983 (07-12-04)
Advertisement
Related Manuals for Char-Broil Copper Chimney Copper Chimney
Summary of Contents for Char-Broil Copper Chimney Copper Chimney
- Page 1 04201101 04501116 Outdoor Fireplace Copper Chimney Copper Chimney For Outdoor Use Only CAUTION WARNING Do not use this unit on a wood deck or on combustible THIS UNIT IS HEAVY! surfaces such as dry grass, leaves, mulch, etc. Do not use this unit near heat sensitive or combustible structures DO NOT assemble without a helper.
-
Page 2: Parts List
STOP! Missing a part? Call Our Help Line No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line. - Page 4 Attach the two side panels to the base using Side panel #10-24x1/2” screws and #10-24 flange nuts. 55700540 Tabs on tops of panels should face inward. Tabs facing inward #10-24x1/2” screw #10-24x1/2” screw (black) Qty: 6 Base #10-24 55700511 flange nut (black) Qty: 6 #10-24 flange nut...
- Page 5 Attach the door frame to the two side panels using #10-24x1/2” screws and #10-24 flange nuts. Hinge sockets should be on the outside. #10-24 flange nut #10-24x1/2” screw (black) Qty: 6 Hinge sockets on outside #10-24 flange nut (black) Qty: 6 Door frame 55700539 #10-24x1/2”...
- Page 6 Insert door hinge rods into hinge sockets on door Left door frame. Latch hole is in lower right corner of left 55700545 door. Assemble latch and latch handle to left door as shown below using a #10-24x1/2” screw and #10-24 flange nut.
- Page 7 Assemble the chimney front and rear walls and #10-24x1/2” hex-head screw (silver) two chimney side walls using #10-24x1/2” hex- head screws (silver) and #10-24 flange nuts (silver). Chimney rear wall 55700544 #10-24x1/2” #10-24 hex-head screw flange nut (silver) (silver) Qty: 8 Qty: 8 #10-24 Chimney...
- Page 8 Place chimney hood cap into opening in Chimney hood cap chimney. 29000167 Attach the two ash drawer handles to the front of the ash drawer using #10-24 flange nuts. Slide drawer into front of fireplace. #10-24 flange nut (black) Qty: 4 Ash drawer 55700547 #10-24 flange nut...
-
Page 9: Use And Maintenance
If you notice any of these surface conditions before the outdoor fireplace is used, contact the Char-Broil Service Center for a free replacement of the defective component. Manufacturing defects are covered under Char-Broil's 90 Day Limited Warranty. -
Page 10: Limited Warranty
Limited Warranty The manufacturer warrants the product for replacement or repair of parts and/or workmanship for a period of 90 days. Paint is not warranted and will require touchup. These limited warranties are made exclusively to the original customer presenting proof of purchase. These warranties are limited to non-commercial residential use only. - Page 11 Please register your grill online at: WWW.GRILLREGISTRATION.COM (If you register online, you do not need to send in this registration card.)
- Page 12 W.C. Bradley Co. • Columbus, GA 31902 Printed in China...
