Cast Iron
For Outdoor
Use Only
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
WARNING
All surfaces can be hot during use. Use protection as
required to prevent burning.
Outdoor Fireplace
WARNING
Do not use this unit on or near combustible surfaces or
structures such as wood decks, dry leaves or grass, vinyl
or wood siding, etc. SEE OWNER'S MANUAL FOR
IMPORTANT SAFETY INFORMATION.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out in breezy conditions. Adequate fire extinguishing
material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
04501122
04201101
42803996 (05-06-08)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cast Iron and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Broil Cast Iron

Summary of Contents for Char-Broil Cast Iron

  • Page 1 04201101 04501122 Outdoor Fireplace Cast Iron For Outdoor Use Only CAUTION WARNING Do not use this unit on or near combustible surfaces or THIS UNIT IS HEAVY! structures such as wood decks, dry leaves or grass, vinyl DO NOT assemble without a helper.

  • Page 2: Parts List

    STOP! Missing a part? Call Our Help Line No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line.
  • Page 4 Attach the door supports to the side panels Door support with #10-24x1/4” machine screws. (right front - left rear) 55700552 #10-24x1/4” machine screw Side panel Qty: 8 55700550 #10-24x1/4” machine screw Door support (left front - right rear) 55700551 Attach the two side panels to the base using 1/4-20x3/4” hex-head screws and 1/4-20 flange nuts. Base rests on supports at each side panel.
  • Page 5 Attach hood to side panels using #10-24x3/4” hex-head screws and #10-24 flange nuts. Hood NOTE: Tabs on hood fit UNDER top of side 55700554 panels. Next, fully tighten the side #10-24 panel/base screws that were left loose in flange nut #10-24x3/4”...
  • Page 6 If desired, these effects can be reduced by cleaning the surfaces regularly after each use using soap, water and an appropriate metal polish. Painted Steel and Cast Iron Surfaces Comparable to the patina effect of copper and bronze, a natural protective rust coating can form on painted steel and cast iron outdoor fireplaces to create an antiqued finish.
  • Page 7 Please register your grill online at: WWW.GRILLREGISTRATION.COM (If you register online, you do not need to send in this registration card.)

  • Page 8: Limited Warranty

    California only, you may take the product to the retail establishment selling this product in order to obtain performance under this limited warranty. If you wish to obtain performance of any obligation under this limited warranty, you should write to: Char-Broil Consumer Relations P. O. Box 1240...
