Tools needed for assembly: Phillips screwdriver • Adjustable wrench
WARNING
Do not use this unit on a wood deck or on combustible
surfaces such as dry grass, leaves, mulch, etc. Do not
use this unit near heat sensitive or combustible structures
such as vinyl or wood siding.
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out of ring in breezy conditions. Adequate fire
extinguishing material should be readily available.
Arch Fireplace
MODEL 03505788 • Assembly Instructions
FOR OUTDOOR USE ONLY!
CAUTION
THIS UNIT IS HEAVY!
DO NOT assembly without a helper.
CAUTION
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
Arch Fireplace 03505788 / 42803959 (07-23-03)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Char-Broil 03505788
Summary of Contents for Char-Broil 03505788
- Page 1 Burning charcoal inside can kill you. It gives off carbon fly out of ring in breezy conditions. Adequate fire monoxide, which has no odor. NEVER burn charcoal extinguishing material should be readily available. inside homes, vehicles or tents. Arch Fireplace 03505788 / 42803959 (07-23-03)
-
Page 2: Parts List
STOP! Missing a part? Call Our Help Line No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line. -
Page 3: Do This First
Attach the two side panels to the firebox using three #10-24x1/2” Side panel machine screws and three #10-24 keps nuts on each side. It may be helpful to have someone hold components in place as you attach screws and nuts. Side panel Side... - Page 4 Attach the base to the firebox using five 1/4-20x6” machine screws, 1/4-20 keps nuts, and spacers. Insert the five screws into holes in the top of the firebox. Slide the spacers onto the screws. Fit the base onto the ends of the screws and secure with keps nuts.
- Page 5 Place the log rack onto the firebox. Log rack legs fit into holes in floor of firebox. Log rack To attach front and rear screens (screens are identical), place bottom lip of screens over outer edges of firebox, and lean screens against side panels.
- Page 6 Place the top cap into the opening in the Top cap fireplace top. Your fireplace is now ready to use.
-
Page 7: Hardware List
HARDWARE LIST Hardware is shown actual size. You may have spare hardware after assembly is complete. #10-24x1/2” U-Clip #10-24 Keps Nut 1/4-20 Keps Nut Machine Screw Qty. 4 Qty. 6 Qty. 5 Qty. 10 1/4-20x6” Machine Screw • Qty. 5 Limited Warranty The manufacturer warrants the product for replacement or repair of parts and/or workmanship for a period of 90 days. - Page 8 W.C. Bradley Co. Columbus, GA 31902...
