Stainless Stainless 04201101 04501139 Steel Steel Outdoor Outdoor Fire Basin Fire Basin For Outdoor Use Only CAUTION WARNING Do not use this unit on a wood deck or on combustible THIS UNIT IS HEAVY! surfaces such as dry grass, leaves, mulch, etc. Do not use this unit near heat sensitive or combustible structures DO NOT assemble without a helper.
STOP! Missing a part? Call Our Help Line No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line.
Page 3
Assemble rails to legs using sixteen #10-24x1/2” screws. Attach short rails to bottom (looped end) of legs; long rails to top of legs. Top long rail #10-24x1/2” screw Qty: 16 Short bottom rail Attach ash container to bottom of fire basin using four #10-24x1/2”...
Page 4
Place fire basin into base. Attach firescreen lift bolt to firescreen with one 1/4-20 hex-keps nut. Firescreen lift bolt 1/4-20 hex-keps nut Qty: 1 Firescreen...
If you notice any of these surface conditions before the outdoor fireplace is used, contact the Char-Broil Service Center for a free replacement of the defective component. Manufacturing defects are covered under Char-Broil's 90 Day Limited Warranty.
