Char-Broil 03505770 Assembly Instructions

Caldera fire bowl

Caldera Fire Bowl

FOR OUTDOOR USE ONLY

Tools needed

for assembly:

Straight or

Phillips screwdriver

Adjustable wrench

CAUTION

Some parts may contain sharp edges – especially as

noted in manual. Wear protective gloves if necessary.

WARNING

NEVER LEAVE FIRE UNATTENDED!

Do not allow small children near flame. Hot embers can

fly out of bowl in breezy conditions. Adequate fire

extinguishing material should be readily available.

Model • 03505770

WARNING

Do not use this unit on a wood deck or on combustible

surfaces such as dry grass, leaves, mulch, etc. Do not

use this unit near heat sensitive or combustible structures

such as vinyl or wood siding.

CAUTION

Read and follow all safety statements, warnings,

assembly instructions and use & care directions before

attempting to assemble.

WARNING

CARBON MONOXIDE HAZARD

Burning charcoal inside can kill you. It gives off carbon

monoxide, which has no odor. NEVER burn charcoal

inside homes, vehicles or tents.

Fire Bowl 03505770 / 42803943 (01-13-04)

Table of Contents

Need help?

Do you have a question about the 03505770 and is the answer not in the manual?

Page 1 Burning charcoal inside can kill you. It gives off carbon fly out of bowl in breezy conditions. Adequate fire monoxide, which has no odor. NEVER burn charcoal extinguishing material should be readily available. inside homes, vehicles or tents. Fire Bowl 03505770 / 42803943 (01-13-04)
Page 2 Customer Service toll free Help Line. Call us and we will gladly ship the part you need FREE OF CHARGE. Parts List - Model 03505770 Description Item 55700419 Bottom Ring Kit 55700420...
Page 3 Make sure legs are on the inside of ring, attach legs to lower ring as shown using 4X from the outside and 4X on the inside. Tighten nuts after all four legs are attached. Repeat this step for areas 2, 3 and 4. Making sure the legs are on the inside of ring, attach legs to upper ring as shown using (4) 1/4 - 20 x 1/2”...
Page 4 Using (3) 10-24 Combo Truss Head Machine Screws from inside the bowl and (3)10-24 Keps Lock Nuts, attach ash catcher to the bottom side of bowl. Tighten all nuts when ash catcher bracket is attached to bowl. Assembly of Ash Catcher Lower bowl onto assembled base Completed view of Caldera Fire Bowl After Assembly...
