Colour Plasma Display Monitor
Model PW1
37PD5000
55PD5000
55PMA550E
CMP5500
System Name
37PD5200
READ THE INSTRUCTIONS INSIDE CAREFULLY.
KEEP THIS USER'S MANUAL FOR FUTURE REFERENCE.
For future reference, record the serial number of your monitor.
SERIAL NO.
The serial number is located on the rear of the monitor.
This monitor is
VESA DPMS.
The
® emblem does not represent EPA endorsement of any product or
service.
As an
® Partner, Hitachi,Ltd. has determined that this product meets
the
® guidelines for energy efficiency.
55PMA500
® compliant when used with a computer equipped with
USER'S MANUAL
MANUEL UTILISATEUR
BEDIENUNGSANLEITUNG
Advertisement
Table of Contents
Related Manuals for Hitachi 37PD5000
Summary of Contents for Hitachi 37PD5000
-
Page 1: System Name
® compliant when used with a computer equipped with VESA DPMS. ® emblem does not represent EPA endorsement of any product or service. As an ® Partner, Hitachi,Ltd. has determined that this product meets ® guidelines for energy efficiency. USER'S MANUAL MANUEL UTILISATEUR BEDIENUNGSANLEITUNG... - Page 2 NOTE: REMARQUE: HINWEIS:...
- Page 3 USER'S MANUAL Thank you very much for purchasing the HITACHI Plasma Display Monitor. Before using your monitor, please carefully read the "SAFETY INSTRUCTIONS" and this "USER'S MANUAL" so you will know how to operate the monitor properly. Keep this manual in a safe place. You will find it useful in the future.
-
Page 4: Features
Important Please read this User's Manual thoroughly, especially the Safety Instructions on Page 4 to 7. Mis-use may cause damage to your plasma monitor, which could shorten its lifespan, or cause injury to yourself. Should you encounter any difficulty in the set-up or operation of your monitor, firstly refer to the Troubleshooting guide at the rear of this manual. -
Page 5: Table Of Contents
CONTENTS FEATURES ...2 SAFETY INSTRUCTIONS ...4 COMPONENT NAMES ...8 Main Unit...8 Remote control ...9 Loading Batteries ...9 Handling the Remote Control ...9 INSTALLATION INSTRUCTIONS ...10 Installation...10 Anti-tumble measures...10 Connecting to a PC ...11 Mounting the Speaker Unit ...12 Power Cord Connection ...12 OPERATING INSTRUCTIONS ...13 Turning Power On and Off ...13 Input Switching ...14... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS This Plasma monitor has been designed and manufactured to meet international safety standards, but like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. Before using this product, please read and understand the Safety Instructions thoroughly to ensure correct usage, and follow all the instructions. About the Symbols Various symbols are used in this manual, the user’s manual and on the product itself to ensure correct usage, to prevent danger to the user and others, and to prevent property damage. - Page 7 WARNING Be cautious of the power cord connection. Incorrect connection of the power cord could result in fire or electrical shock. • Do not touch the power cord with a wet hand. • Check that the connecting portion of the power cord is clean (with no dust), before using. Use a soft and dry cloth to clean the power plug. •...
- Page 8 SAFETY INSTRUCTIONS(continued) CAUTION Be careful in moving the monitor. Neglect could result in an injury or damage. • Do not move the monitor during use. Before moving, disconnect the power plug and all external connections. • You are advised to move the monitor with two persons. •...
- Page 9 • Prevention of an obstacle to Radio receivers This monitor has been designed pursuant to the international EMI standards. This is to prevent a problem to Radio receivers. - Keep the monitor away from Radio. - Adjust Radio antennas in order for the monitor not to receive interference. - The antenna cable of Radio should be kept away from the monitor.
-
Page 10: Component Names
COMPONENT NAMES Main Unit Panel Control panel • Adjustment buttons are located on the bottom. • The back cover is provided with indications to distinguish the adjustment buttons. VOLUME UP/DOWN RECALL button buttons ( SELECT button) ADJUST SIZE button buttons) ( SELECT button) SUB-POWER button •... -
Page 11: Remote Control
Remote control POWER OFF button POWER ON button MUTE button RGB/VIDEO buttons PinP button AUTO button MENU button OK button ID button Loading Batteries 1. Open the battery cover. • Slide back and remove the battery cover in the direction of the arrow. 2. -
Page 12: Installation Instructions
INSTALLATION INSTRUCTIONS Installation • If you have purchased the model without the stand attached: When installing the monitor, use the optional Desk-top Stand (CMPAD16N···55"). The Desk-top Stand has been used for the illustrations in this manual. WARNING Use one of the special mount units to install this product. A mount of insufficient strength or inadequate design can cause overturning or dropping and result in fire, electrical shock or injury. -
Page 13: Connecting To A Pc
Read SAFETY INSTRUCTIONS ( proceeding to these steps: • Choose an appropriate site and install the product on a level table where the stand is secure. • Install the monitor to have ready access to a power socket available. • Make sure that the power switch of this device is turned off. Connecting to a PC (1) Make sure that the display signal of the personal computer to be used is compatible with the specifications of this device. -
Page 14: Mounting The Speaker Unit
INSTALLATION INSTRUCTIONS (continued) Mounting the Speaker Unit (option) Refer to the instruction manual concerning mounting of the optional speaker unit. Power Cord Connection Connect the power cord, after completing all other connections.···37" Connect the power cord, after completing all other connections.···55" Connect the power cord to this device. -
Page 15: Operating Instructions
OPERATING INSTRUCTIONS (37") Indicating lamp Main power switch (37") スピーカー端子 (6 12W) (55") SUB-POWER button POWER OFF button POWER ON button RGB 1 RGB 2 MUTE AUTO PinP SIZE RECALL MENU ID SET Turning Power On and Off (55") To turn the monitor power ON, press the main power •... -
Page 16: Input Switching
OPERATING INSTRUCTIONS (continued) VOLUME UP/DOWN buttons MUTE button RGB buttons RGB 1 RGB 2 MUTE AUTO PinP SIZE MENU Input Switching • Input can be switched by pressing the RGB1, RGB2, buttons of the remote control. Input can be switched in the sequence of RGB1 ➔ •... -
Page 17: Size Switching
SIZE button Size Switching Each time the SIZE button of the remote control or the monitor is pressed, the screen display area will change in sequence and the status will be displayed at the bottom of the screen. Normal Full Zoom1 Real Zoom3... -
Page 18: Automatic Adjustment Of Screen Position And The Clock
OPERATING INSTRUCTIONS (continued) RGB 1 RGB 2 MUTE AUTO PinP SIZE AUTO button MENU MENU button ID button Automatic Adjustment of Screen Position and the Clock Adjustment of the screen to a position suitable for the PC signal and the clock adjustment can be performed automatically by pressing the AUTO button of the remote control. -
Page 19: Picture Menu
PICTURE MENU Picture Audio Timer Function MENU Setup Language Select Selected characters Narrows the gap between Contrast brightness and darkness. Black is subdued for Brightness increased overall darkness. Colour Darkens colours. Enhances red and weakens green. Picture Enhancement Cool Normal Colour Temperature Colour Temp. -
Page 20: Audio Menu
OPERATING INSTRUCTIONS (continued) AUDIO MENU MENU Selected characters Movie Audio Mode Treble Suppresses treble. Bass Suppresses bass. Balance Suppresses right-side sound. SRS TruBass Matrix Surround Perfect Volume Reset (off the function) TIMER MENU MENU Selected characters Off Timer On Timer Picture Audio Timer... -
Page 21: Function Menu
FUNCTION MENU MENU Selected characters Screen Saver 60Min. Screen Wipe Black Side Panel Video Power Save Freeze Mode Default Zoom Reset (off the function) Normal Panel Life Mode Display ID Number Inverse Standby White 120Min. Gamma Picture Audio Timer Function Setup Language Select... -
Page 22: Setup Menu
OPERATING INSTRUCTIONS (continued) SETUP MENU Picture Audio Timer Function MENU Setup Language Select OK Set Selected characters Auto Adjust* Moves the horizontal position to left. Horizontal Position Moves down the vertical position. Vertical Position Reduces the dot clock frequency (shrinks the right side). -
Page 23: Language Menu
LANGUAGE MENU Picture Audio Timer MENU Function Setup Language Select OK Set Select a language by M L SELECT buttons and press the OK button. OTHER FEATURES Automatic Store Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below. Menu Display Registration condition... -
Page 24: Signal Check
OTHER FEATURES (continued) Signal Check Changes in the signal status are displayed on the screen as they arise. Status When Mode Display is set to ON, A guide is displayed for the input the input signal is switched or terminal and the horizontal and when the RECALL button is vertical sync frequency. -
Page 25: Image Retention Of Plasma Display
IMAGE RETENTION OF PLASMA DISPLAY There are different characteristics that result in panel image retention depending on how the plasma display is used. Situations and effective usage methods related to ghosting are provided below. Image retention characteristics of a plasma display The image retention phenomenon of a plasma panel occurs due to partial phosphor degradation arising from partial character and figure display. -
Page 26: Troubleshooting
TROUBLESHOOTING Symptoms That Seemingly Appear to be Failures Make the checks suggested below depending on the symptoms observed. If the symptoms remain uncorrected, contact your dealer. WARNING Customer servicing can be hazardous. Symptom • No picture with the power-indicating lamp off. - Page 27 Symptom • The temperature of the display panel surface is high. • There are locations on the screen that are different from the periphery (*). *Points that do not light, points with brightness different from that of the periphery, points with color different from that of the periphery, etc.
-
Page 28: Actions To Correct Abnormal Displays
TROUBLESHOOTING (continued) Actions to Correct Abnormal Displays Depending on the kind of system equipment used, images may not be displayed normally. In this case, make the adjustments suggested below. (only for RGB2) Text displayed across the screen appears vertically streaked, with some characters blurred (figure 1). Symptom 1 The display image appears flowing (figure 2) (RGB input). -
Page 29: Product Specifications
PRODUCT SPECIFICATIONS Product specifications and designs are subject to change without notice. Display Approx. 37 inches (814 (H) x 445 (V) mm, diagonal 930mm) dimensions Panel Resolution 1024 (H) x 1024 (V) pixels Net dimensions 940 (W) x 573 (H) x 99 (D) mm (excluding Speakers/Stand) Net weight 29.0kg... -
Page 30: Recommended Signal List
PRODUCT SPECIFICATIONS (continued) Signal Input (continued) DVI terminal (DVI-D) Input signal T.M.D.S. Data2- T.M.D.S. Data2+ T.M.D.S. Data2/4 Shield T.M.D.S. Data4- T.M.D.S. Data4+ DDC Clock DDC Data No Connect T.M.D.S. Data1- T.M.D.S. Data1+ T.M.D.S. Data1/3 Shield T.M.D.S. Data3- Frame GND T.M.D.S. Data3+ Recommended Signal List With Digital RGB signal input (RGB1 input) Signal mode... - Page 31 With Analog RGB signal input (RGB2 input) Signal mode Signal Name Resolution 640 X 400 640 X 480 W-VGA 864 X 480 640 X 480 640 X 480 640 X 480 800 X 600 800 X 600 800 X 600 800 X 600 800 X 600 1024 X 768...
-
Page 32: Supplement
SUPPLEMENT... -
Page 33: Optional Video Unit Function
Optional Video Unit Function Additional functions when the optional video unit is installed are as follows: ( INSTALLATION INSTRUCTIONS Connecting to a Video Imaging Device (1) Make sure that the power switch of the monitor is turned off. (2) Make sure that the power switch of the imaging device is turned off. (3) Use a commercially available cable and connector to connect the signal input terminal on the rear panel of this device and the signal output terminal of the imaging device. - Page 34 OPERATING INSTRUCTIONS Input Switching • Input can be switched by pressing the AV1, AV2, AV3, AV4, RGB1 or RGB2 buttons of the remote control. Input can be switched in the sequence of AV1➔AV2 ➔ • AV3 ➔ AV4 ➔ RGB1 ➔ RGB2 by pressing the INPUT SELECT button of the monitor.
- Page 35 Vertical picture position can be adjusted for [Panoramic], [Zoom] , [C14:9L] and [14:9Zoom] mode as follows. 1. Press SIZE button and SELECT buttons during picture size display. 2. Position display will appear. 3. Adjustment range of each picture size are as shown below. [Panoramic] [Zoom] [C14:9L] and [14:9Zoom]...
-
Page 36: Displaying Multi Picture
OPERATING INSTRUCTIONS (continued) PinP button RGB 1 RGB 2 MUTE AUTO PinP SIZE MENU 2 Pictures (Split) Input terminal AV1~AV4 Main SECAM PAL, SECAM ~AV4 NTSC3.58/4.43 576i, 576p 480i, 480p 1080i/50 1080i/60 720p/60 RGB1 RGB2 Component NOTE • Even if the input of the horizontal / vertical synchronizing signal (or video signal) stops in the MULTI PICTURE display, the mode will not change to power save mode. - Page 37 PICTURE MENU Picture Audio Timer MENU Function Setup Language Select Picture Picture Mode Dynamic Contrast Brightness Colour Sharpness Colour Temperature Normal Contrast Mode Normal Reset Reset Select Return Picture Picture Mode Dynamic Contrast Brightness Colour Sharpness Colour Temperature Normal Contrast Mode Normal Reset Reset...
- Page 38 OPERATING INSTRUCTIONS (continued) PICTURE MENU (continued) Selected characters Picture Mode Narrows the gap between Contrast brightness and darkness. Black is subdued for Brightness increased overall darkness. Colour Darkens colours. Sharpness Soft Enhances red and weakens green. Cool Colour Temperature Contrast Mode Reset (off the function) Film Mode...
- Page 39 Selected characters Colour Management Magenta Magenta is weakened. Red is weakened. Yellow Yellow is weakened. Green Green is weakened. Cyan Cyan is weakened. Blue Blue is weakened. Colour Decoding Darkens red only. Green Darkens green only. Colour Darkens colours. Enhances red and weakens green.
-
Page 40: Colour System
OPERATING INSTRUCTIONS (continued) SETUP MENU Picture Audio Timer MENU Function Setup Language Select OK Set Selected characters System Colour System System 1 System 2 Video Input Auto AV2 (1st step) Auto AV2 (2nd step) Setup System Colour System Video Input Audio Input Scart Output RGB1... - Page 41 Selected characters Audio Input Stereo Scart Output DVI-PC RGB1 RGB2 (1st step) Auto RGB2 (2nd step) OTHER FEATURES Automatic Store Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below. Menu Display Registration condition Picture Picture Mode...
- Page 42 TROUBLESHOOTING Symptoms That Seemingly Appear to be Failures Make the checks suggested below depending on the symptoms observed. If the symptoms remain uncorrected, contact your dealer. WARNING Customer servicing can be hazardous. Symptom • The screen becomes dark and the images cannot be seen during VCR special playback (fast forward, rewind).
- Page 43 Signal Input RGB terminal (D-sub 15-pin connector) Input signal R (P G or sync on green (Y) B (P No connection No connection R.GND (P , GND) G.GND (Y, GND) B.GND (P , GND) No connection No connection [SDA] H. sync or H/V composite sync V.sync.
- Page 44 PRODUCT SPECIFICATIONS (continued) Recommended Signal List With Digital RGB signal input (RGB1 input) Signal mode Signal Name Resolution 640 X 400 640 X 480 W-VGA 864 X 480 640 X 480 640 X 480 640 X 480 800 X 600 800 X 600 VESA 800 X 600...
-
Page 45: Optional Tuner Unit Function
Optional Tuner Unit Function The optional tuner unit can operate when installed with the optional video unit. Additional functions when the optional tuner unit is installed are as follows: ( COMPONENT NAMES Remote control (provided for the optional tuner unit) This type of remote control would be provided for the optional tuner unit as the substitute for the one shown in page POWER ON / OFF button PICTURE MODE button... - Page 46 COMPONENT NAMES (continued) Remote control (provided for the optional tuner unit) (continued) PICTURE MODE You may recall the picture mode by pressing this button. Each time pressed, picture mode is changed in following sequence. Dynamic Natural INPUT SELECT Press this button to change input mode.
-
Page 47: Teletext Function
SUBTITLE button TEXT button MODE button INDEX button TV / TEXT button CANCEL button TELETEXT FUNCTION Buttons on Remote Control TEXT Press this to use the TELETEXT services. Press this to return to the TV mode when in the TELETEXT mode. TV / TEXT This switches the receiver between the TV mode and the TELETEXT mode. -
Page 48: Connecting Antenna
INSTALLATION INSTRUCTIONS Connecting Antenna Make sure that the power switch of the monitor is turned off. Speaker (R) (exp) antenna Precautions when connecting the antenna • Please use a coaxial cable which is free from interference to connect the antenna. Avoid using a parallel flat feeder wire as interference may occur, causing reception to be unstable and stripe noise to appear on the screen. - Page 49 OPERATING INSTRUCTIONS The functions of the buttons located on the bottom of the monitor change as shown below: INPUT SELECT button (OK button) PROGRAM UP/DOWN button SELECT button) VOLUME UP/DOWN buttons ADJUST buttons) SUB-POWER button • ( ) indicates the function while the MENU is displayed on the screen. Input Switching •...
- Page 50 OPERATING INSTRUCTIONS (continued) Displaying MULTI PICTURE If the MULTI PICTURE button on the remote control is pressed, multi pictures will display. And then three types of the screen can be selected by pressing the MULTI MODE button on the remote control. The multi picture mode will change in the following sequence each time the MULTI MODE button is pressed.
- Page 51 2 Pictures (Split) Input terminal AV1~AV4, ANT NTSC3.58 Main SECAM NTSC4.43 PAL, SECAM ~ AV4 NTSC3.58/4.43 576i, 576p 480i, 480p 1080i/50 1080i/60 720p/60 RGB1 RGB2 Component 4 Pictures Input terminal AV1~AV4, ANT NTSC3.58 Main SECAM NTSC4.43 PAL, SECAM ~ AV4 NTSC3.58/4.43 576i, 576p 480i, 480p...
-
Page 52: Picture Freezing
OPERATING INSTRUCTIONS (continued) D / N I / II A / B MENU D V D RGB1 Picture Freezing When the FREEZE button on the remote control is pressed, the screen transfers into the freeze mode. • There are two types of freezing screen mode, Split and Strobe. These are possible to select at the “Freeze Mode”... - Page 53 SETUP MENU [During TV mode] Picture Audio Timer MENU Function Setup Language Select OK Set Setup Auto Tuning Country Austria Belgium Croatia Czech Republic Denmark Finland France Germany Search Select Return Setup Auto Tuning Manual Tuning Fine Tuning Sort Auto Off Select Return Setup...
- Page 54 OPERATING INSTRUCTIONS (continued) SETUP MENU (continued) Selected characters Auto Tuning (Page1) Country Search Manual Tuning Position Search (C--) (S--) (--MHz) Descrambler Name Sound System Colour System Skip Decreasing the frequency Fine Tuning data for the main tuner Sort (A Line of position List) Auto Off [During VIDEO signal input] 1 item is added to the Menu shown in the page...
-
Page 55: Other Functions
OTHER FUNCTIONS A2 / NICAM / Sound Multiplex • The CH I / II button is only useful for NICAM and sound multiplex signals. Otherwise pressing this button will have no effect. BILINGUAL / DUAL sound broadcast When bilingual program is received, sound mode display appears in yellow as shown on right. - Page 56 Pioneer Panasonic Toshiba Philips Samsung Sony Example To operate HITACHI DVD player, press and hold the RECALL button, followed by the RECALL button MODE button INDEX button TV / TEXT button CANCEL button NOTE • Not all models of the listed brands can be operated using this remote control.
- Page 57 TROUBLESHOOTING Symptoms That Seemingly Appear to be Failures Make the checks suggested below depending on the symptoms observed. If the symptoms remain uncorrected, contact your dealer. WARNING Customer servicing can be hazardous. Symptom snowy picture - poor sound multiple images - sound O.K intermittent interference no picture or sound Possible reason...
- Page 58 PRODUCT SPECIFICATIONS This table shows the specifications when the optional video unit and tuner unit have been inserted. Display Approx. 37 inches (814 (H) x 445 (V) mm, diagonal 930mm) dimensions Panel Resolution 1024 (H) x 1024 (V) pixels Net dimensions 940 (W) x 573 (H) x 99 (D) mm (excluding Speakers/Stand) Net weight...
- Page 59 Plasma screen and on the bottun of the AVC. Also, record where and when you purchased this T.V. This information will help any future queries you may have and should be used in all correspondence with Hitachi service centres. MODEL...
- Page 60 Box 77 S-164 94 Kista SWEDEN Tel: +46 (0) 8 562 711 00 Fax: +46 (0) 8 562 711 13 Email: csgswe@hitachi-eu.com HITACHI EUROPE LTD (Norway) AB STRANDVEIEN 18 1366 Lysaker NORWAY Tel: 67 5190 30 Fax: 67 5190 32 Email: csgnor@hitachi-eu.com...
