- Page 1 85Mbps HomePlug...
- Page 2 Easy Start Guide © Copyright 2007 All rights reserved. No part of this document may be reproduced, republished, or retransmitted in any form or by any means whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying, recording, information recording, or through retrieval systems without the express written permission.
-
Page 3: Table Of Contents
Easy Start Guide Contents About the Product ...................... 4 Package Contents ..................4 Device Design ....................5 Getting Started......................6 Planning your Network ................7 Local Network ......................7 Gaming Network.......................7 Entertainment Network....................8 Media Network ......................8 Remove/Disable Conflicts ................9 TCP/IP........................9 Internet Properties....................10... -
Page 4: About The Product
The package contains the following items: • 1 HomePlug Turbo for Single Pack or 2 HomePlug Turbo’s for Twin Pack • 1 Network cable for Single Pack or 2 network cables for Twin Pack • Resource CD • Easy Start Guide Page 4 of 19... -
Page 5: Device Design
Easy Start Guide Device Design HomePlug Turbo has three LED indicators and an Ethernet port. Label Status Description/ Function On/Off Power is on/off. On/Off Another HomePlug is detected/not detected PL-ACT Flashes Data is being transmitted. On/Off Ethernet is connected/not connected. -
Page 6: Getting Started
Easy Start Guide Getting Started Setting up the device is easy. The flowchart below provides an outline of the steps you need to go through. Some steps are required while some are optional. There are brief descriptions beside each step to help you along. Detailed instructions are provided in the subsequent pages. -
Page 7: Planning Your Network
Easy Start Guide Planning your Network Here are ideas on how you can use HomePlug Turbo. Local Network Share Internet connection with any computer wherever it is in the house. Gaming Network Connect your gaming console into the Internet and compete with other online players. -
Page 8: Entertainment Network
Easy Start Guide Entertainment Network Watch and listen to your media files using your entertainment system. Media Network Realize your high-tech lifestyle by converging your IP devices into a single network. Page 8 of 19... -
Page 9: Remove/Disable Conflicts
Easy Start Guide Remove/Disable Conflicts You may need to check the TCP/IP and Internet properties to make sure there are no conflicts with the way devices in the network are identified. TCP/IP HomePlug Turbo’s IP Address should be obtained automatically. -
Page 10: Internet Properties
Easy Start Guide Internet Properties To set the Internet Properties: 1. Select Start > Run. This opens the Run dialog box. 2. Enter control inetcpl.cpl and then click OK. This opens the Internet Properties dialog box. 3. Click Connections tab. -
Page 11: About Powerpacket Utility
Easy Start Guide About PowerPacket Utility PowerPacket Utility is a Windows-based software application used to manage and monitor the activity of HomePlug devices. System Requirements Your computer must meet the following requirements: • Windows Operating System: Windows 98SE, Windows Me, Windows 2000 Windows XP, or Windows Vista •... -
Page 12: Main
Easy Start Guide Main The Main tab displays local and remote HomePlug devices that are active in the network. The top portion displays the local device which pertains to the HomePlug that is directly connected to the computer. The bottom portion displays a table of all remote HomePlugs with their Device Name, Password, Quality, Rate, and MAC Address. - Page 13 Easy Start Guide To connect to a local HomePlug: 1. Select a HomePlug listed in Local Devices on your computer. 2. Click Connect. After connection, a message showing the HomePlug MAC Address is displayed on top of the Connect button.
-
Page 14: Privacy
Easy Start Guide 3. Enter the Password. The Device Password is printed on the sticker label on the HomePlug itself. 4. Click OK. To scan for HomePlugs: • Click Scan. By default, PowerPacket Utility scans devices from time to time. - Page 15 Easy Start Guide To change the Private Network Name of a local HomePlug: Note… You will not be able to change the Private Network Name of a local HomePlug if it is not in a connected status in the Main tab.
-
Page 16: Quality Of Service
Easy Start Guide Quality of Service Quality of Service (QoS) is a feature that allows you to determine which application will be given a guaranteed priority over other applications. QoS is not enabled by default. To enable QoS: 1. Select an application in the QoS tab •... -
Page 17: Diagnostics
Easy Start Guide Diagnostics Diagnostics displays details about the system as well as the other HomePlug devices within the network. It is divided into two sections – System Information and Remote Device History. System Information displays software applications and hardware devices connected with the local computer. -
Page 18: About
Easy Start Guide About About displays the software version and preferences. The Autoscan preference is enabled by default. About Page 18 of 19... -
Page 19: Safety Instructions
Easy Start Guide Safety Instructions For your safety, be sure to read and follow all warning notices and instructions. Do not open the device. Opening or removing the device cover can expose you to dangerous high voltage points or other risks. Only qualified service personnel can service the device.
