HDD PLAYER
HDA-5460
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Phone 03-9769-0000
ALPINE ELECTRONICS GmbH
Kreuzerkamp 7, 40878 Ratingen,
Germany
Phone 02102-4550
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway,
Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris
Nord II, B.P. 50016, 95945 Roissy
Charles de Gaulle Cedex, France
Phone 01-48638989
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava) - APDO 133,
Spain
Phone 945-283588
Designed by ALPINE Japan
Printed in China (S)
68P50520Y92-O
EN
FR
ES
ES
IT
SE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDA-5460 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpine HDA-5460

Summary of Contents for Alpine HDA-5460

  • Page 1 Veuillez lire avant d'utiliser cet appareil. • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. 1-1-8 Nishi Gotanda, 6-8 Fiveways Boulevarde Keysborough, (RCS PONTOISE B 338 101 280)

  • Page 3: Table Of Contents

    ENGLISH Contents Operating Instructions Information WARNING HDD Mechanism ..........13 About MP3/WMA .......... 13 WARNING ..........2 My DJ File List ..........14 CAUTION ........... 2 In Case of Difficulty ........15 PRECAUTIONS ......... 3 Specifications ..........17 Getting Started Initial System Start-Up ........

  • Page 4: Warning

    Failure to do so may cause personal injury or damage to the DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing. ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

  • Page 5: Precautions

    (+140 F) and –10 C (+14 F) before turning your unit on. Maintenance If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing. On Handling HDD Follow the following instructions while using HDD.

  • Page 6: Getting Started

    Getting Started Turning Power On and Off When connecting to Ai-NET Head Unit: Turn on the head unit power. The power of the main unit is linked and turned on. For details, refer to the head unit operation manual. To turn off the power, turn OFF the head unit power.

  • Page 7: Removing And Inserting Hdd

    Removing and Inserting HDD HDD can be removed and edited in a computer. For HDD editing in a computer, refer to the installation manual or on line help of Digital Media Manager. Check the unit power is turned off. If the unit power is turned on, be sure to turn off the unit power.

  • Page 8: Hdd Operations

    HDD Operations Scanning Programs You can search a track by listening to the beginning of the track. Press and hold MENU for at least 2 seconds to UP/DOWN select the Play mode. Turn the Rotary encoder to select the SCAN mode and then press the Rotary encoder.

  • Page 9: Repeat Play

    Repeat Play Search a Track The track you like or want to remember can be played back You can search for a track to play through its Artist name/Album repeatedly. name/Song name. Press and hold MENU for at least 2 seconds to Press MENU to select the menu mode.

  • Page 10: Deleting An Hdd Track

    Deleting an HDD Track Selecting DJ Sound (My DJ Function) You can delete an HDD track. The deleted file cannot be recovered. The tracks can be collected and played in random sequence based on the genre tag information of MP3 file. Press MENU in the HDD mode to select the menu mode.

  • Page 11: Other Functions

    Other Functions Setting Time/Calendar Press MENU in the HDD mode to select the menu mode. DISP UP/DOWN Move the UP/DOWN key upward or downward to select the Setup mode. Turn the Rotary encoder to select the CALENDAR mode and then press the Rotary encoder.

  • Page 12: Switching Display Pattern

    Switching Display Pattern Checking Copyright Information You can select the display pattern to your favorite. Press MENU in the HDD mode to select the menu Press DISP to select the desired display pattern. mode. Move the UP/DOWN key upward or downward to Content select the Information mode and then press the Main display...

  • Page 13: (Cda-9815 Only)

    Operation (CDA-9815 only) Download data to the head unit On Alpine owner website you can access the automobile audio setting Downloading is operated not from the main unit (HDA-5460) but data varying with types of cars and systems. With CDA-9815 from the head unit (CDA-9815).

  • Page 14: Head Unit Operations

    (When IVA-D900 is combined) Head Unit Operations Press SOURCE/POWER in the head unit. The operations of the main unit can be performed from the head unit Turn the Rotary encoder in the head unit to even when CDA-9815/CDA-9811/IVA-D900 are combined. select the MM DRIVER mode and then press the Refer to the following table for the functions that can be operated.

  • Page 15: Information

    About MP3/WMA Information CAUTION Except for private use, duplicating audio data (including MP3/ HDD Mechanism WMA data) or distributing, transferring, or copying it, whether for free or for a fee, without permission of the copyright holder is strictly prohibited by the Copyright Act and by international treaty. The tracks are categorized in the ARTIST/ALBUM.

  • Page 16: My Dj File List

    Terminology Folder File Name Description ¥MyDj_MP3Files¥ World_1.MP3 World Bit rate World_2.MP3 This is the “sound” compression rate specified for encoding. The World_3.MP3 higher the bit rate, the higher the sound quality, but also the larger World_4.MP3 the files. World_5.MP3 Sampling rate World_6.MP3 This value shows how many times per second the data is sampled World_7.MP3...

  • Page 17: In Case Of Difficulty

    - The indicator will disappear when the temperature if the unit is at fault. Otherwise, make sure the rest of your system is returns to within operation range. properly connected or consult your authorized Alpine dealer. No function or display. NO DISC •...
  • Page 18 • An error occurred in downloading i-Personalize data. 2 If this does not resolve the problem, transfer the data - Access the ALPINE Web site again and download the i- contained in the “Memory Stick” to a personal computer Personalize data.

  • Page 19: Specifications

    Specifications EXPIRED HDD SECTION • A track having a playback expiration was played. / A track HDD Capacity: 16GB having a restriction not supported by this unit was played. Compression Method of - Unplayable files can be erased from the “Memory Stick.” Playback Signal: ????? •...

  • Page 20: Installation And Connections

    When connecting the HDA-5460 to the fuse box, installations or ground connections. Using such parts could make sure the fuse for the intended circuit of the HDA-5460 disable control of the vehicle and cause fire etc. has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle.

  • Page 21: Installation

    Connect each input lead coming from an amplifier Installation or equalizer to the corresponding output lead coming from the left rear of the HDA-5460. Connect all other leads of the HDA-5460 according to details Metal plate described in the CONNECTlONS section.

  • Page 22: Basic Connections

    Basic Connections Ignition Key Battery Ai-NET Ai-NET Head unit (CDA-9815/ NORM EQ/DIV CDA-9813/ CDA-9811 etc.) CD Changer (Sold Separately) Speakers Left Amplifier etc. Right 1 The label is attached on the bottom of the unit.
  • Page 23 Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.

  • Page 24: System Examples

    Head unit System switch CDA-9815/CDA-9813/CDA-9811 etc. applicable to Ai- NET (optional) Ai-NET HDA-5460 To Ai-NET NORM EQ/DIV input To Ai-NET output System Example 2: Connection to MINI BUS head unit supporting AUX IN MINI BUS head unit supporting AUX IN (CDM-9803, etc.)
