What's in the Box
VM9125 Head Unit
Left and Right Double DIN
Mounting Brackets
Double DIN Half Sleeve Install
Bracket
Two Custom Cosmetic Trim Rings
Parking Brake Wire
Hardware Bag
Speaker Output Harness
Power Input Harness
Accessory Harness
Installation Guide
WARNING! Never install this unit where operation and viewing could interfere with
safe driving conditions.
VM9125
You will need these tools and supplies
to install your VM9125:
• Torx type, flat-head and Philips
screwdrivers
• Wire cutters and strippers
• Tools to remove existing radio (screw
driver, socket wrench set or other
tools)
• Electrical tape
• Crimping tool
• Volt meter/test light
• Crimp connections
• 18 gauge wire for power connections
• 16 – 18 gauge speaker wire
Tools and Supplies
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jensen VM9125
Summary of Contents for Jensen VM9125
- Page 1 What’s in the Box Tools and Supplies VM9125 Head Unit You will need these tools and supplies Left and Right Double DIN to install your VM9125: Mounting Brackets • Torx type, flat-head and Philips Double DIN Half Sleeve Install screwdrivers Bracket •...
-
Page 2: Optional Equipment
NOTE: If the VM9125 is to be installed in a car equipped with an on-board drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. Under these conditions, use extra caution during installation to avoid causing a short circuit. - Page 3 Installation Using Half-Sleeve Step 1-b 1. Install half-sleeve in the dashboard. a. Install adapter if necessary (optional). b. Install half-sleeve into adapter or dashboard (use only the supplied screws). Do not force the sleeve into the opening or cause it to bend or bow. WARNING! Only connect the unit to a 12-volt power supply with proper grounding.
-
Page 4: Wiring Diagram
Need Help? For technical assistance, call the Jensen customer support line at 1-800-323-4815. Need Help? For technical assistance, call the Jensen customer support line at 1-800-323-4815.
