Para obtener instrucciones en Español, diríjase a la página 5.
VM9114
VM9114 Head Unit
Single DIN Sleeve
Wiring Harness
Parking Brake Sensor Extension Wire
Mounting Hardware
You will need these tools and supplies to install your VM9114:
Torx type, fl at-head and Philips screwdrivers
Wire cutters and strippers
Tools to remove existing radio (screwdriver, socket wrench set or other tools)
Electrical tape
Crimping tool
Volt meter/test light
Crimp connections
18 gauge wire for power connections
16 – 18 gauge speaker wire
WARNING! Never install this unit where operation and viewing could interfere with safe driving
conditions.
Pour des instructions en Francais, référez-vous à la page 9.
VM9114
Multimedia Receiver
What's in the Box

Tools and Supplies

1
Instruccionnes de Instalación
Instructions d'installation
160 Watts
A / V
INPUT
Cosmetic Trim Ring
3.5mm to 3.5mm Media Adaptor Cable
Owners Manual
Installation Guide
Installation Guide
EJECT

Advertisement

Table of Contents

   Also See for Jensen VM9114

   Related Manuals for Jensen VM9114

   Summary of Contents for Jensen VM9114

  • Page 1: Tools And Supplies

    Wiring Harness Owners Manual Parking Brake Sensor Extension Wire Installation Guide Mounting Hardware Tools and Supplies You will need these tools and supplies to install your VM9114: • Torx type, fl at-head and Philips screwdrivers • Wire cutters and strippers •...
  • Page 2: Disconnecting The Battery

    To prevent a short circuit, be sure to turn off the ignition and remove the negative (-) battery cable prior to in- stallation. NOTE: If the VM9114 is to be installed in a car equipped with an on-board drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. Under these conditions, use extra caution during installation to avoid causing a short circuit.
  • Page 3: Final Installation

    NOTE: When replacing a fuse, be sure to use correct type and amperage to avoid damaging the radio. The VM9114 uses one 15 amp fuse, located in the black fi lter box in-line with the main wire harness. Final Installation After completing the wiring connections, turn the unit on to confi...
  • Page 4: Wiring Diagram

    Ignition Switch GREY/BLACK - FRONT R PURPLE + BATTERY + PURPLE/BLACK - YELLOW REAR R BATT FUSE (15A) Battery GREEN + GREEN/BLACK - BLACK REAR L BATTERY Ground Need Help? For technical assistance, call the Jensen customer support line at 1-800-323-4815.
