Warranty Ordering Parts Model IGS-6900 Retain This Manual for Reference 05-26-05 OWNER'S MANUAL IRON GRIP STRENGTH DELUXE UTILITY BENCH IGS-6900 IMPEX FITNESS INC. 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...
BEFORE YOU BEGIN Thank you for selecting the IRON GRIP STRENGTH Deluxe Utility Bench IGS-6900 by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. to provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory.
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
Page 4
WARNING LABEL REPLACEMENT The Warning Label shown here has been placed on the Rear Base. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in the location shown.
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended this machine be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Main Frame (#1) to the Front Stabilizer (#2). Secure it with two M10 x 2 ¾” Carriage Bolts (#21), one Bracket (#15), two Nuts (#28).
Page 7
STEP 2 (See Diagram 2) A.) Slide the Sliding Block (#5) onto the Incline Adjustment Bar (#4). B.) Attach both ends of Incline Adjustment Bar to the open brackets on the Main Frame (#1). Secure each end with one M10 x 2 ½” Carriage Bolt (#22), Ø ¾” Washer (#27), and M10 Aircraft Nut (#28).
Page 8
STEP 3 (See Diagram 3) A.) Attach the lower holes on the Backrest Supports (#7) to the pivot on the Sliding Block (#5). Secure them with one M12 x 5 ¾” Allen Bolt (#19), two one M12 Aircraft Nut (#26). B.) Attach the Seat Support Frame (#6) to the hole on the Backrest Support (#7).
Page 9
STEP 4 (See Diagram 4) A.) Insert the Foam Tube (#10) halfway through the hole on the Main Frame (#1). Push two Foam Rolls (#12) onto the Foam Tube from both ends. Plug the Foam Roll End Caps (#11) into the ends. B.) Place the Seat (#8) onto the Seat Support Frames (#6).
PARTS LIST KEY NO. DESCRIPTION Main Frame Front Stabilizer Rear Stabilizer Incline Adjustment Bar Sliding Block Seat Support Frame Backrest Support Seat Backrest Board Foam Tube Foam Roll End Cap Foam Roll Sliding Block Sleeve 2 ¾” x 2” End Cap Bracket Lock Knob 1 5/8”...
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
