Azden 330UPR User Manual
Dual-channel on-camera uhf wireless microphone system
Hide thumbs
Also See for 330UPR:
- Instruction manual (12 pages) ,
- User manual (12 pages) ,
- Instruction manual (12 pages)
Advertisement
Quick Links
1-12-17 Kamirenjaku Mitaka-shi Tokyo 181-8533 Japan
Tel :+81(0)422-55-5115 Fax :+81(0)422-55-0131
E-mail : sales@azden.co.jp URL http://www.azden.co.jp
Printed in Japan 060-35513-01
330 SYSTEM
User's Guide
330UPR • 35BT • 35HT • 35XT
DUAL-CHANNEL ON-CAMERA
UHF WIRELESS MICROPHONE SYSTEM
Advertisement
Related Manuals for Azden 330UPR
Summary of Contents for Azden 330UPR
- Page 1 330 SYSTEM User’s Guide 330UPR • 35BT • 35HT • 35XT DUAL-CHANNEL ON-CAMERA UHF WIRELESS MICROPHONE SYSTEM 1-12-17 Kamirenjaku Mitaka-shi Tokyo 181-8533 Japan Tel :+81(0)422-55-5115 Fax :+81(0)422-55-0131 E-mail : sales@azden.co.jp URL http://www.azden.co.jp Printed in Japan 060-35513-01...
-
Page 2: Configuration Of The Packages
‡G Audio out jack CH1 and CH2(MIC OUT) Livelier microphone EX-553 The 330UPR is supplied with both a mini(stereo) to mini(stereo) and a mini to dual XLR cable. 35XT Plug-in Transmitter For mini jack mirophone inputs: Usethe supplied mini to mini cable. Plug one end fo the cable into the receiver (CH1/CH2 audio out jack) and the other end of the calbe into the microphone input of the video camera. - Page 3 Obtain •gAA•h alkarine batteries 2 pcs. Using Azden recommending re-chargeable batteris, get AC/DC adapter for recharging from Azden and charge batteris for 8 hours to get full charge. To make sure the batteris at full level, check three bar on the LCD is indicated.
- Page 4 Important information When the last bottom bar start flushing, replace the batteries. Licensing of this, or any Azden wireless equipment is the user's responsibility. The ability to e: Auditon transmission •gwireless frequency level•h will be displayed through receive a license depends largely on the user's classification, application and frequency.
- Page 5 In addition to the battery, inside the battery compartment you will find: 330UPR Receiver (13) MIC Input LEVEL Control After installing new batteries, mount the receiver to your video camera with the supplied This control enables you to adjust the input level of the microphone.
- Page 6 (19) POWER (26) MIC LEVEL Control Switches the transmitter “ON” or “OFF”. The MIC LEVEL control enables you to adjust the audio level of the microphone. Using the supplied tool, turn the dial clockwise to increase, or counterclockwise to decrease the (20) AUDIO microphone’s audio level.
