❶ Dolby Digital Out
- PCM : Converts to PCM(2CH) audio.
- Bitstream : Outputs Dolby Digital via the digital out
put.Select Bitstream when connecting to a
Dolby Digital Decoder.
❷ MPEG-2 Digital Out
- PCM : Converts to PCM(2CH) audio.
- Bitstream : Converts to MPEG-2 Digital Bitstream
(5.1CH or 8CH). Select Bitstream when using the
Digital Audio Output.
❸ Dynamic Compression
- On : To select dynamic compression.
- Off : To select the standard range.
❹ PCM Down Sampling
- On : Select this when the Amplifier connected to the
player is not 96KHz compatible. In this case, the
96KHz signals will be down converted to 48KHZ.
- Off : Select this when the Amplifier connected to the
player is 96KHz compatible. In this case, all signals
will be output without any changes.
Note
Even when PCM Down sampling is Off
• Some discs will only output down sampled
audio through the digital outputs.
• To make the Setup menu disappear, press the
MENU button.
❺ Output Channel
- 2 Ch : Select this when using 2 channel connection only.
- 5.1Ch : Select this when using 5.1Ch channel connec
tion.
Manufactured under license from Dolby
Laboratories. "Dolby" and the double-D symbol
are trademarks of Dolby Laboratories.
"DTS" and "DTS Digital Out" are trademarks of
Digital Theater Systems, Inc.

Surround Sound Speaker Setup

1. With the unit in Stop mode, press the MENU button.
2. Press the �/� buttons to select Setup, then press the �
or ENTER button.
3. Press the �/� buttons to select Audio Setup, then press
the � or ENTER button.
4. Press the �/� buttons to select Speaker Setup, then
press the � or ENTER button.
5. Press the �/�/�/� buttons to select the desired item,
then press the ENTER button to set the speaker.
Note
To make speaker setup menu appear, Select output
channel to 5.1Ch.
26
Note
To make the setup menu disappear, press the MENU
button.
The default settings : FRONT L, R (Small),
CENTER (Small), SURROUND (Small).
Select the size of the speakers to be connected.
❶ Front (FL, FR)
- Large: Normally select this.
- Small: When the sound distorts or the suround
sound effects are difficult to hear, select this.
This activates the Dolby Digital bass redirec
tion circuitry and outputs the bass frequencies
of the speaker from the subwoofer.
❷ Center
- None: If you do not connect a center speaker,
select this.
- Large: Normally select this.
- Small: When the sound distorts, select this.
This activates the Dolby Digital bass redirec-
tion circuitry and outputs the bass frequencies
of the center speaker from other speakers.
❸ Surround (SL, SR)
- None: If you do not connect a center speaker,
select this.
- Large (Rear/Side): Normally select either of
these according to the rear speaker's position.
- Small (Rear/Side): When the sound ditorts or
the surround sound effects are dificult to hear,
select either of these according to the rear
speaker's position.
This activates the Dolby Digital bass rediretion
circuitry and outputs the bass frequencies of
the rear speaker from other speakers.
Setting up Test
The test output signals come clockwise starting
from the Front Speaker(L).
Adjust Channel Balance so that speakers output
equally in your room.
FRONT(L) ➝ CENTER ➝ SUBWOOFER ➝
FRONT(R) ➝ SURROUND(R) ➝ SURROUND(L)
AUDIO SETUP
Dolby Digital Out :PCM
MPEG-2 Digital Out :PCM
Dynamic Compression:On
PCM Down Sampling :On
Output Channel :5.1CH
Speaker Setup
�
Enter Return Menu
SPEAKER SETUP
Small
Small Small
On
Test
User
Small Small
